NCR VOYIX 7779 Quick Start Manual

8" and 10" tablet
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
NCR Voyix 7779 8" and
10" Tablet
Quick Start Guide
Release 1.2
BCC5-0000-5753
Issue C
© 2024 NCR Voyix. All rights reserved. Confidential and proprietary information of NCR Voyix.
Use and disclose solely pursuant to company instructions.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7779 and is the answer not in the manual?

Questions and answers

Summary of Contents for NCR VOYIX 7779

  • Page 1 NCR Voyix 7779 8" and 10" Tablet Quick Start Guide Release 1.2 BCC5-0000-5753 Issue C © 2024 NCR Voyix. All rights reserved. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.

  • Page 2: Copyright And Trademark Information

    The product described in this document is a licensed product of NCR Voyix Corporation. NCR Voyix 7779 8" and 10" Tablet is a trademark of NCR Voyix Corporation in the United States and/or other countries. Other product names mentioned in this publication may be trademarks or registered trademarks of their respective companies and are hereby acknowledged.

  • Page 3: Preface

    This book is written for customers, system integrators, support personnel, and customer engineers. Note This document is NCR Voyix proprietary information and is not to be disclosed or reproduced without consent. Safety Requirements This device has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules.

  • Page 4: Lithium Battery Warning

    Improper or insufficient maintenance Improper use or unauthorized modifications of the product. Inadequate location or surroundings. For detailed warranty arrangements please consult your contract documents. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.

  • Page 5: Table Of Contents

    Drop, dust and water resistance Environmental Requirements Buttons and Interfaces Front side Top side Right and bottom side Rear side Getting Started Battery and Power Management Charging the battery Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 6 Replacing the battery Removing the battery Installing the battery Maximizing battery life Troubleshooting Safety Information Battery and charging safety Radio frequency safety Antenna Positions Front Rear Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.

  • Page 7: Revision Record

    Dec 2021 Updated the technical specifications Sep 2024 Combined 8" and 10" in one PDF Release 1.2 (10" Tablet - Alder Lake) Updated to Voyix template Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.

  • Page 8: Product Overview

    Product Overview The NCR Voyix 7779 Tablet is a hybrid POS terminal/mobile device. It has the flexibility to quickly and efficiently serve customers in various ways such as line busting, tableside ordering, and video training for store personnel. The 8-inch tablet uses Intel® Atom E3940 Quad Core CPU (2M cache, 1.8GHz), and the 10-inch tablet uses Intel®...

  • Page 9: Technical Specifications

    4GB DDR4 memory, 64GB eMMC v5.0 storage Storage Micro SDXC slot for up to 2TB expanded storage Micro SDXC slot for up to 2TB expanded storage Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.

  • Page 10: Drop, Dust And Water Resistance

    Drop, dust and water resistance Resistance Parameter Specification Drop 1 meter (3 feet), drop tested Dust and Water IP65 certified, water and dust ingress protection Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.

  • Page 11: Environmental Requirements

    Environmental Requirements The NCR Voyix 7779 Tablet is designed to operate within the temperature and humidity ranges shown below. Avoid continuous operation near the lowest or highest limits, and in locations where temperature or humidity changes beyond the environmental restrictions.

  • Page 12: Buttons And Interfaces

    This section provides information about the buttons and interfaces on the following parts of the tablet: "Front side" on the next page "Top side" on page 14 "Right and bottom side" on page 15 "Rear side" on page 17 Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.

  • Page 13: Front Side

    Indicates the tablet charging status. For more information, refer to "Battery and Power Management" on page 19. Windows Button Returns the user to the start menu using a capacitive touch. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.

  • Page 14: Top Side

    Press and hold it to shut down the device. Press the button twice to enable sleep mode. Volume Key Controls the volume of the tablet. Left side—reduces the volume Right side—increases the volume Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.

  • Page 15: Right And Bottom Side

    A feature that can connect the tablet to an optional dock. MicroSDXC card slot Memory card slot for file storage. MicroUSB interface A port for charging the tablet. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 16 USB 2.0 port A port for connecting a USB thumb drive or peripheral. Audio jack 3.5 mm jack for microphone and speaker connector. Stereo speakers Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.

  • Page 17: Rear Side

    Captures high-resolution images and video. Mechanical fixing points behind covers Allow hand or shoulder strap to be attached to the tablet. Battery lid Covers the replaceable battery. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.

  • Page 18: Getting Started

    Getting Started To start using the NCR Voyix 7779 Tablet, follow these steps: 1. Connect the tablet to the power supply. Note Ensure that the battery is fully charged before disconnecting the tablet from the power supply. For more information about battery and power management, refer to "Battery and Power Management"...

  • Page 19: Battery And Power Management

    Battery and Power Management The NCR Voyix 7779 Tablet comes with a replaceable battery. The battery can be charged from 0% to 90% in approximately 2 hours, and to 100% in approximately 3 hours. The tablet features a charging indicator LED on the upper right-hand corner of the screen. The following table provides information about the tablet charging indicator.
  • Page 20 2. Insert the USB cable to the power unit. 3. Plug the power unit to a standard AC power outlet. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.

  • Page 21: Replacing The Battery

    Always use a soft material (cloth, foam) to protect the display screen when placing the tablet face down. 2. Using a finger, unsnap the battery lid starting from the corner slot on the lid. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 22 4. While holding the first battery release tab, lift the battery partially from the corner. Caution Do not pull the battery too hard to avoid damaging the second battery release tab. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.

  • Page 23: Installing The Battery

    Installing the battery To install the battery into the tablet, follow these steps: 1. Position the battery at a maximum angle of 30° against the tablet back. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 24 2. Place the battery in the slot. Ensure that the hooks on the side have clicked to secure the battery in place. 3. Install the battery lid to cover the battery. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.

  • Page 25: Maximizing Battery Life

    Maximizing battery life Depending on the settings and actual usage patterns, the NCR Voyix 7779 Tablet has the following battery life: Model Battery life 8-inch model Up to 6 hours continuous operation 10-inch model Up to 7.5 hours continuous operation To maximize the battery life of the Tablet, refer to the following recommendations: Close unused applications and data connections.

  • Page 26: Troubleshooting

    If the device freezes, do a hard reset. To perform a hard reset, press and hold the power button for approximately 14 seconds or until the device turns off. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.

  • Page 27: Safety Information

    Keep the unit and accessories away from small children. Switch off the device before boarding an aircraft. Switch off the device in areas with a potentially explosive atmosphere. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.

  • Page 28: Battery And Charging Safety

    Use only the correct battery type for the tablet. To avoid the risk of explosion, do not replace the battery with an incorrect type. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.

  • Page 29: Radio Frequency Safety

    Radio frequency safety Some NCR Voyix 7779 Tablets have 3G functionality. These devices are equipped with antennas to support this functionality. The NCR Voyix 7779 Tablet meets guidelines for exposure to radio waves (SAR, Specific Absorption Rate) when kept in a close distance to the body.
