ASSEMBLY INSTRUCTIONS
FOR
MOSLEY DIPLOMAT 2
2 METER ANTENNA
MODEL DI 2
TO CUSTOMIZE YOUR DIPLOMAT 2 FOR
A 5/8 WAVE
150 to 170 MCs
OMNI- DIRECTIONAL
SEE REVERSE SIDE OF INSTRUCTIONS
ANTENNA
The high performance of your MOSLEY Antenna can only be achieved if the
antenna is assembled in accordance with the instructions supplied. Substitutions
of material or modification of design will materially lessen this performance.
Advertisement
Related Manuals for Mosley DIPLOMAT 2
Summary of Contents for Mosley DIPLOMAT 2
- Page 1 SEE REVERSE SIDE OF INSTRUCTIONS ANTENNA The high performance of your MOSLEY Antenna can only be achieved if the antenna is assembled in accordance with the instructions supplied. Substitutions of material or modification of design will materially lessen this performance.
- Page 2 DESCRIPTION The Mosley Diplomat 2 is a two meter 5/8 wave omnidirectional antenna with a gain of 3.4 db compared to 1/4 wave ground plane. It features a VSWR of 1.5/1 or better, and is matched for 52 ohm coaxial cable. Mounting fits up to 1-1/2" O.D. mast.
- Page 3 INDUCTANCE .8 !h. FIG. 2B FIG. 2A DIPLOMAT 2 The diplomat 2 antenna does not provide a complete ground at low frequencies and DC. USE ON FREQUENCY Such a ground may be added by installing a 144 TO 170 MHz SOLDER choke coil as shown in FIG.
- Page 4 TO CUSTOMIZE YOUR DIPLOMAT 2 FOR 150 to 170 MCs The vertical element and each of the radial elements must be cut to new lengths. 1. Select the desired frequency. 2. To determine what t~e exact height of the vertical element should be in inches, locate the frequency desired on the left side of Chart No.
