Recommended Tools Needed for Installation
·
Power drill
·
Wire stripper and cutter (10 to 14 gauge)
·
Screwdrivers (#2 Phillips, ¼" Flat Tip)
·
Voltage Meter or non-contact voltage detector
·
Backup lighting during installation (optional)
·
Tape measure (optional)
Parts List(s)
·
Transfer Switch w/ conduit whip & wiring
·
5* - Wire connector nuts (*10 Wire Connector Nuts for HTS15-MAN-2)
·
4 - Sheet metal screws
·
4 - Drywall anchors/screws
Safety Symbols & Notices
Journeyman-Pro (Heezy LLC) are not responsible for any damage or injury caused by the installation of this
transfer switch.
Danger indicates an imminently hazardous situation that, if not avoided, could result in death or
serious injury.
Warning indicates a potentially hazardous situation that, if not avoided, could result
in death or serious injury.
Caution indicates a potentially hazardous situation that, if not avoided, may result in
minor or moderate injury.
Improper installation of the transfer switch could cause damage or personal injury by electrocution or
fire. Installation must be performed by a qualified electrician, or others knowledgeable of electrical systems, in
compliance with all applicable electrical codes.
Transfer switches covered in this manual should not be used for any appliances or systems that
may exceed the capacity of the product. All transfer switches meet the NEC (National Electrical Code) for 2011.
Transfer switches are required for use with portable generators by Article 702 of the 2011 National Electrical Code.
Options for installation, usually the most convenient location for powering the transfer switch is the
best option for most installations. We also recommend locating the transfer switch as close to the
back-up power source as possible. It's recommended to first wire it as it is received (to switch the
neutral) before trying to bypass the neutral switching.
These options are in 3 Sections;
Installing at Circuit Breaker Panel/Load Center (required for HTS15-MANv2)
A.
Installing at System or Appliance
B.
Bypassing Neutral Switching (optional)
C.
Generator Transfer Switch Install Guide
Models: HTS15-MANv1 & HTS15-MANv2
Installation Instructions
Advertisement
Summary of Contents for JourneyMan HTS15-MANv1
- Page 1 4 - Drywall anchors/screws Safety Symbols & Notices Journeyman-Pro (Heezy LLC) are not responsible for any damage or injury caused by the installation of this transfer switch. Danger indicates an imminently hazardous situation that, if not avoided, could result in death or serious injury.
- Page 2 If installing at the circuit breaker panel, always turn off “MAIN BREAKER” this is usually at the top of the breaker panel. Even with the main power switch turned off, the wires on the utility side of the main breaker are still live and contact with them can cause serious injury or death! *HTS15-MANv2 the dual circuit transfer switch should be installed at the circuit breaker panel, the #1 Circuit (LEFT side facing switch) will include the GROUND...
- Page 3 A. Installing at Circuit Breaker Panel/Load Center Mounting the Transfer Switch 1. Position the transfer switch so that its bottom center is about 18 inches from your circuit breaker load center or to where the flexible conduit whip should be lined up with a 1/2” knockout hole. 2.
- Page 4 B. Installing at System or Appliance Mounting the Transfer Switch 1. Position the transfer switch so that the flexible conduit whip will be lined up with a 1/2” knockout hole. 2. Anchor the transfer switch to the wall/unit with at least two Powers wall anchors, if mounting to drywall or wood no pre-drilling is necessary, if mounting on masonry, brick etc.
- Page 5 until the wires start twisting and push the connected wires back into the wiring compartment. 5. Find the BLACK wire from the transfer switch and the BLACK wire connected to the appliance, Insert both wires into a wire nut connector. Tighten the connection and push the connected wires back into the wiring compartment.
- Page 6 30 Days of purchase and receive 100% of your purchase price. Our “No BS” Lifetime Warranty will cover the repair of all functional aspects of your Journeyman-Pro Product for the life of the product. Naturally, our warranty does not cover labor to install or remove any products, shipping or freight charges, degradable materials components or abusive or negligent use.
