beauty by
DM 9050
Professional Laser Epilation Pen
Quick Setup Guide
Keep this user manual in a convenient place
for quick and easy reference.
The product names in this guidebook are trademarks or registered trade
marks of each specific manufacturer. In the interest of providing superior
equipment, Avance reserves the right to modify or amend equipment speci‐
fications without notice or obligation.
Advertisement
Table of Contents
Summary of Contents for Avance DM 9050
- Page 1 DM 9050 Professional Laser Epilation Pen Quick Setup Guide Keep this user manual in a convenient place for quick and easy reference. The product names in this guidebook are trademarks or registered trade marks of each specific manufacturer. In the interest of providing superior equipment, Avance reserves the right to modify or amend equipment speci‐ fications without notice or obligation. ...
- Page 2 DM9050 Features and Controls A. Key Lockout: This feature is required by law on all high‐power laser devices. The first step in the correct sequence to power‐up your laser is to turn this lock clockwise using the special key included in your kit. The light system status LED (E) will be green when the power system is off and red when the power system is on. B. Function Select: F1 provides standard treatments with full intensity. F2 offers less intense but more frequent pulses for increased comfort. Both settings deliver the same amount of energy over time (Jcm /s). C. Laser Status LED: A flashing light indicates that the laser is active. D. Pulse Counter: Allows you to keep track of the number of pulses de‐ livered during a treatment session. E. System Status LED: This light will indicate system status (neutral or live). Green is neutral and red is live. F. Laser Jack: Provides power to the diode laser module. G. Carbon Dye: This is an ‘atomized’ form of molecular carbon which easily penetrates deeply into the follicle shaft. The dye adds pigment which gives a receptor for the photon/heat exchange reaction. (Required for treatment of blond and gray hair.) DermalPlast: A topical anesthetic that improves skin cooling and re‐ duces discomfort during treatment. (Recommended for all skin types.) 2 ...
-
Page 3: Important Notice
beauty by Post‐Treatment Gel: A soothing gel that aids recovery of the skin and improves results. Apply thinly after each treatment for best results. H. High‐Precision Tweezers: For extraction of follicle prior to carbon dye application. Trigger Switch: This red button should be activated by way of the I. operator’s thumb. It will initiate laser pulses from the laser module. J. Eyewear: This is an essential part of the treatment process. Direct or reflective laser radiation can seriously injure the eye. Both the techni‐ cian and the patient must use the protective eyewear while the laser is enabled. Eyewear is intended for accidental exposure only. Never stare directly into a laser beam. Laser Beam Trigger Switch Important Notice To preserve the life of your laser it is required that you allow a 2 sec‐ ond pause between each 1‐2 second emission (4‐9 pulses). Failure to comply with this usage requirement may cause permanent damage to your laser diode by heat buildup, which would not be covered by warranty. Using the laser module correctly will result in a life expectancy of the device ex‐ ceeding 1,000,000 pulses which is approximately 1‐2 years of daily use. ... - Page 4 Laser Startup Procedure Before plugging your laser head into the power system, be sure the key switch is off (LED will show green). Failure to adhere to the A start‐up procedure may cause irreversible damage to your laser head (which would not be covered by warranty). A. Plug the laser module accessory into the power system. B Place the laser head in a secure position POINTED AWAY from you and the patient. B. Power up your module by using your key lockout switch C (turn to the “enabled” setting). The system status light (C) will turn red, and a bright LED will begin flashing. ...
- Page 5 beauty by Photo‐Reactive Dye Application Using a cotton‐tipped applicator, completely cover the treatment area with the special dye included in your kit. Massage the dye into the follicle pore with a firm downward circular motion. Repeat 2‐3 times to satu‐ rate the follicle pore. Use an ethyl alcohol based wipe (isopropyl alcohol will not dissolve the dye) to lightly clean the excess from the surface of the skin. At this point ...
-
Page 6: Treatment Procedure
Treatment Procedure Select desired function (F1 or F2). F1 offers full power pulses, with longer pauses between, while F2 offers lower power, more frequent pulses for increased comfort. For skin types IV and above, select F2. Shine the red dot on the highlighted hair follicle. Adjust the distance of the laser head from the tissue to create a pin‐ point ... - Page 7 beauty by and effective on hair growth which occurs from the areola of both sexes. Again, care must be taken in these areas due to the increased level of neu‐ ral sensitivity. Post‐Treatment: The skin surrounding the treatment area may experience short‐term erythmia (reddening) which will subside within 12 hours. Should the treatment area show signs of excess scabbing you may wish to reduce the overall treatment time or intensity. The application of a post‐ treatment ...
- Page 8 (melanocytes) to well over 100 degrees Celsius. Human tissue cannot survive at this temperature; the complete destruction of the follicle was virtually instanta‐ neous. The scientific term for this process is called thermolysis. Laser light with the wavelength of 600 to 900 nm (nanometer) passes through human tissue with very little loss of intensity. The Avance DM9050 Epilator produces a precise wavelength of 808 nm, which is proven to pro‐ vide the greatest tissue penetration while limiting the loss of energy to natural pigments found in the skin. Avance employs a long‐pulse laser, one of the most effective and sophisti‐ cated systems in the world. Long‐pulsed lasers use a series of short pulses ...
- Page 9 Type 6 should not undergo laser hair removal unless used in conjunction with skin bleaching due to the high risk of burning and hypo/hyper pigmen‐ tation issues. Warnings and Advisories The Avance DM9050 Epilator produces laser radiation which can be harmful to the eyes. Always wear protective eyewear while operating this equipment. Laser radiation has the capability to burn the skin if the technician does not closely observe the patient’s reaction to the procedure. Advisory: Laser hair removal results in full destruction of the hair follicle and is irreversible. Always plan ahead before undertaking detail work such as eyebrow shaping or hairline contour‐ ing. Patch test a small area (no larger than 1X1 inch square) before full application. Allow 24 ...
-
Page 10: Troubleshooting
Troubleshooting Should you encounter technical problems with your Avance DM6050 Laser Epilator, refer to the following guide for potential problems and their solu‐ tions. Problem Solution Check whether plugged into a The unit doesn’t turn on working electrical socket. Check all connections. Plug and Unit is plugged into the wall, all accessories are correctly inserted unplug each one being sure all into the unit but no laser output is contacts are sound. ... -
Page 11: Important Safety Information
beauty by Important Safety Information Read all safety and operating instructions before connecting or using this equipment. To protect against electrical shock, DO NOT use this equipment near water. DO NOT immerse unit, plug transformer while standing in water, or spray with any liquids. As with many electrical appliances, this unit carries a live charge even while unplugged. DO NOT dismantle this unit (there are haz‐ ardous voltages inside). DO NOT place this unit near an open flame or cooking/heating devices (e.g., stoves, heat registers, radiators, etc.). If an extension cord is used, it should be appropriately rated for voltage, power, and frequency as indicated on the back of the unit. ... -
Page 12: Replacement Parts And Supplies
Replacement Parts and Supplies Laser Eyewear PL‐213‐1100 $99.95 each LM9050 Replacement Laser LM‐225‐9050 $699.95 each Carbon Dye (50ml) SP‐213‐2500‐50mL $29.95 each DermalPlast (50ml) SP‐213‐3500‐50mL $29.95 each Post‐Treatment Gel (50ml) SP‐213‐4500‐50mL $29.95 each All prices in USD. Delivery F.O.B. Prices subject to change without notice. To order online, visit our website: http://www.centre‐biotechnique‐avance.com/ For technical assistance beyond what this manual provides, please e‐mail admin@centre‐biotechnique‐avance.com Please allow 24 hours for processing. Avance Beauty Toronto, Ontario UL8529001 © 2012 Avance Beauty Printed in USA ...
