Hygge Aluminum Louvers Pergola 3x3m Installation Manual

Wall mounted
Hide thumbs

Advertisement

Quick Links

Download this manual
Installation Guide
For 3x3m Pergola
Wall Mounted

Advertisement

loading
Need help?

Need help?

Do you have a question about the Aluminum Louvers Pergola 3x3m and is the answer not in the manual?

Questions and answers

Summary of Contents for Hygge Aluminum Louvers Pergola 3x3m

  • Page 1 Installation Guide For 3x3m Pergola Wall Mounted...
  • Page 2 Goggles & Gloves Ladder Pistol drill Spirit level Utility knife Helmet Tape measure Monkey wrench...
  • Page 4 INSTRUCTIONS...
  • Page 5 CARTON)
  • Page 6 CARTON 1/5(POSTS AND LOOSE PARTS) Reference Parts Quantity Reference Parts Quantity Reference Parts Quantity SO-1 5×6 WO-1 5×19 LO-1 10×80 EO-3 TO-1 8×100 EO-4 lock nut UO-2 6×35 XO-1 6×35 6×45...
  • Page 7 Reference Parts Quantity Reference Parts Quantity ZO-1 ZO-7 ZO-2 ZO-8 ZO-3 ZO-9 ZO-4 ZO-10 ZO-5 10mm CARTON 2/5(BEAMS ) Reference Parts Quantity BO-1 CO-1 CO-2 Connecting Bar(FO) & Brush Inside!
  • Page 8 CARTON 3/5(LOUVERS ) Reference Parts Quantity CARTON 4/5(LOUVERS ) Reference Parts Quantity GO-1 CARTON 5/5(LED AND ELETRIC) Reference Parts Quantity Transformer LED Controller LED-3...

  • Page 9: Assembly Guidelines

    ASSEMBLY GUIDELINES Step 1: Frame & Electric Step 2: Assembling louvers Step 3: Install louvers & Connection...
  • Page 10 Step 1 : Frame & Electric CO-2 BO-1 CO-1...
  • Page 11 Step 1: Frame & Electric Parts Remove the end caps from the beam...
  • Page 12 Step 1: Frame & Electric BO-1 CO-1 CO-2 LED-3 Insert LED strips into the channel inside gutters. Note the direction of strips before installation and make sure it's always 'male plug' meet with 'famale plug'. female female BO-1 CO-2 CO-1 LED-3 BO-1 LED-3...
  • Page 13 Step 1: Frame & Electric Transformer LED Controller Installation of Electric parts E-W2 INPUT OUTPUT...
  • Page 14 Step 1: Frame & Electric Put transfomer and ight controller into cavity of side beam ( CO-2) . Please NOT put them into main beam ( BO / BO-1 ). CO-2 BO-1 CO-2 CO-1...
  • Page 15 Step 1: Frame & Electric Parts CO-2 Transformer XO-1 & Controller 6×35 Tools ZO-1 Input cable ZO-2 NOTE: Route the input wire throught the post before you fix the bottom plate JO. CO-2 XO-1...
  • Page 16 Step 1: Frame & Electric Parts XO-1 6×35 Tools ZO-1 ×2 ZO-2 Post installation diagram XO-1 ZO-2 3. Tighten ZO-1...
  • Page 17 Step 1: Frame & Electric Parts BO-1 BO-1 EO-3 WO-1 5×19 EO-4 TO-1 8×100 Tools ZO-7 Complete the installation of aluminum alloy on the wall BO-1 EO-3 EO-3 BO-1 BO-1 WO-1 EO-4 EO-4 WO-1 EO-4 EO-3 ZO-7 BO-1 BO-1 WO-1...
  • Page 18 BO-1 BO-1 Marker Pen...
  • Page 19 M8X150 Impact bit BO-1 BO-1 TO-1...
  • Page 20 Step 1: Frame & Electric Parts CO-1 CO-2 CO-2 CO-1 WO-1 5×19 Tools ZO-3 ZO-4 ZO-7 Connect beams to columns BO-1 CO-2 CO-1 ZO-7 ZO-4 ZO-8 BO-1 CO-1 CO-2 CO-1 CO-2 WO-1...
  • Page 21 Step 1: Frame & Electric Parts Tools ZO-3 ZO-4 Connect beams to columns CO-2 CO-1 2. Tighten ZO-3 ZO-4...
  • Page 22 Step 1: Frame & Electric Connect LED strips to each other as a circle and connect the ends to the lighting controller. Note that there are 'male' and 'famal' plugs. female female plugs. emale emale amal' plu emale plu emale plu amal' plu emale plu emale...
  • Page 23 Step 1: Frame & Electric 1-10 The remote is paired with the LED by default. 2/ Check if the indicator light on the remote is working properly. If there are no abnormalities after the check as above, please pair the remote with the LED in line with the below steps.
  • Page 24 Step 2: Assembling louvers LO-1 ×1 GO-1 LO-1 ×18...
  • Page 25 Step 2: Assembling louvers Parts 6×35 LO-1 lock nut Tools ZO-3 ZO-5 10mm ZO-4 Louver sealing plate ×18 ZO-3 ZO-5 Louver sealing plate ×19 LO-1 ZO-5 ZO-3 LO-1...
  • Page 26 Step 2: Assembling louvers Parts GO-1 SO-1 LO-1 5×6 Tools ZO-9 ZO-10 Connect end caps with the louvre GO-1...
  • Page 27 Completion Diagram LO-1 ×1 GO-1 ZO-9 ZO-9 SO-1 SO-1 Completion Diagram LO-1 ×18 ZO-9 ZO-9 SO-1 SO-1...
  • Page 28 Step 3: Install louvers & Connection...
  • Page 29 Step 3: Install louvers & Connection Fasten rubber plugs on both ends of the louvers GO-1...
  • Page 30 LO-1 GO-1 GO-1 LO-1 BO-1 LO-1 GO-1 LO-1 LO-1 GO-1 BO-1...
  • Page 31 Step 3: Install louvers & Connection Parts 1. Install other louvers on the beam and make the louver flat 2. Cover the screw head with plastic caps...
  • Page 32 Step 3: Install louvers & Connection Parts 6×45 OO Separate Tools ZO-1 ZO-2 Complete the connection of the MAIN louver...
  • Page 33 Step 3: Install louvers & Connection Parts UO-2 Install the connecting bar UO-2 UO-2...
  • Page 34 Step 3: Install louvers & Connection Parts 10×80 Cover the screw head with plastic caps...
  • Page 35 Please check all footing dimension are correct, then fix all base plates. 12MM...
