OMNILINK SYSTEMS OM500 BEACON
User Guide
Version OM500B
Last Updated 02/09/2022
OVERVIEW
Omnilink's OM500 beacon is designed to be used in conjunction with Omnilink's OM500 Series offender
tracking devices. The beacon allows the Omnilink OM500 series tracking devices to obtain location data
using Wi-Fi radio frequency. Beacons are generally used in highly impaired locations where GPS and Wi-
Fi location are not available. Beacons can also be used in dense residential areas and high-rise residential
structures to reduce participant's movements vertically and horizontally. When the OM500 tracking
device comes within range of the paired beacon, the tracking device starts to locate via Wi-Fi technology.
The OM500 tracking device will attempt to get a non-beacon location point based on impaired rate while
in range of the beacon to verify the beacon is in the correct location. The beacon has multiple alerts to
notify the supervising agency if the beacon has been moved or unplugged from the electrical source.
ORDERING BEACONS
The first time you order OM500 Beacons, you should contact your account manager to ensure you have
the proper contract addendums in place. Beacons can be ordered by submitting an Omnilink Sales Order
nmx-ordersandreturns@sierrawireless.com
form, by emailing
or by contacting your account manager.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Sierra Wireless OMNILINK OM500
Summary of Contents for Sierra Wireless OMNILINK OM500
- Page 1 Omnilink’s OM500 beacon is designed to be used in conjunction with Omnilink’s OM500 Series offender tracking devices. The beacon allows the Omnilink OM500 series tracking devices to obtain location data using Wi-Fi radio frequency. Beacons are generally used in highly impaired locations where GPS and Wi- Fi location are not available.
-
Page 2: Pairing Procedures
PAIRING PROCEDURES 1. Before an Omnilink OM500 Beacon can be used, it must be charged for a minimum of two (2) hours. The beacon has an internal battery that needs to be charged before being paired with an OM500 Series tracking device. -
Page 3: Troubleshooting
point in the offender’s zone before you clear the beacon movement and beacon no power alerts to confirm the beacon is actually at the offender’s residence. If no new beacon motion alerts and beacon no power alerts are generated for 30min, beacon mode will be enabled automatically. 12. -
Page 4: Isedc Compliance
i. Hold the device in inverted orientation ii. Press and release the button 6 times within 10 seconds. The first press should result in a short beep indicating the orientation is sufficiently close to inverted. The final press should result in another beep indicating the unit will now reboot. iii. - Page 5 (2) this device must accept any interference, including interference that may cause undesired operation of the device. Changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. FCC COMPLIANCE §15.105(b) This device is to be used solely by law enforcement agencies in conjunction with Omnilink’s OM500 Series offender tracking devices and must be professionally installed.
