DayTronic 3340A Instruction Manual

Frequency conditioner
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MODEL
3340A
FREQUENCY CONDITIONER
INSTRUCTION MANUAL
Manuals 3140A + 3200 + 3300
with options
3000
Instrument Series
SB.5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3340A and is the answer not in the manual?

Questions and answers

Related Manuals for DayTronic 3340A

Summary of Contents for DayTronic 3340A

  • Page 1 SB.5 MODEL 3340A Manuals 3140A + 3200 + 3300 with options FREQUENCY CONDITIONER INSTRUCTION MANUAL 3000 Instrument Series...
  • Page 2 No part of this document may be reprinted, reproduced, or used in any form or by any electronic, mechanical, or other means, including photocopying and recording, or in any information storage and retrieval system, without permission in writing from Daytronic Corporation. All specifications are subject to change without notice.
  • Page 3 Model 3140A Instruction Manual, v. SB.5 Pub. No. 3140AM.5, Issued 10/96 Part No. 91122 MODEL 3140A FREQUENCY CONDITIONER INSTRUCTION MANUAL Daytronic Corporation Dayton, OH • Tel (800) 668-4745 www.daytronic.com...
  • Page 4 The Model 3140A is also available in two other forms. The Model 3240A contains a Digital Indicator to display the analog output. The Model 3340A is identical to the 3240A, except that it also includes high-low limit monitoring. See separate Model 3200/3300 and Model 3300 Instruction Manuals.
  • Page 5 IMPORTANT: The unit is shipped with two spacer washers on the securing screws of the rear-panel I/O Connector. When panel-mounting the unit, you MUST REMOVE THESE WASHERS, so that the printed-circuit board may move for- ward about 1/8" during Step f, below. a.
  • Page 6 b. Remove the front bezel (four fillister-head screws fasten it to the metal housing--see Fig. 2). c. Make the panel cutout and drill the screw clearance holes shown in Figs. 1C and 2. The front bezel can be used as a template to define the rectangular cutout and to locate the clearance holes.
  • Page 7 AC POWER CONNECTION: Connect the supplied power cable to a 105-135 V-AC, 50-400 Hz source (for "F" versions, 210-260 V-AC; for "B" versions, there is no external power connection). This is a three-conductor cord, plug- ing into the AC power connector at the rear of the unit; the offset pin connects to earth ground.
  • Page 8 RANGE SELECTION: To access the internal bank of ten numbered range- selection switches, remove the 3140A's front panel (two screws near each edge--see Fig. 2). To select the desired full-scale frequency range, place in the ON (i.e., downward) position the switches indicated in Table 2, below.
  • Page 9 Then turn the INPUT SENSITIVITY control clockwise until a stable output is observed. FOR MODELS 3240A AND 3340A ONLY: 1A. POWER-UP and ZERO ADJUSTMENT: as in Steps 1 and 2, above. 2A. SCALE SELECTION: Determine the full-scale output of the transducer in terms of the desired unit of measurement.
  • Page 10 3A. SPAN ADJUSTMENT: Apply an input signal with a frequency equal to the rated full-scale output of the transducer. Then adjust the Coarse and Fine SPAN controls to produce a readout on the indicator of the value de- termined in Step 2A, above--that is, of the full-scale transducer output in terms of the desired unit of measurement (e.g., 728.2 cfm).

  • Page 11: Digital Indicator

    SB.5 MODEL 3200 / 3300 DIGITAL INDICATOR INSTRUCTION MANUAL 3000 Instrument Series...
  • Page 12 Model 3200/3300 Instruction Manual, v. SB.5 Pub. No. 3200/3300M.5, Issued 10/96 Part No. 91130 MODEL 3200 / 3300 DIGITAL INDICATOR INSTRUCTION MANUAL Daytronic Corporation Dayton, OH • Tel (800) 668-4745 www.daytronic.com...
  • Page 13 2 Specifications ........... . 4 PLEASE NOTE: Sections 6 and 7, Figures 6 and 7, and Table 3 have been removed from this manual. If you need information regarding specific 3200/3300 components and circuitry, please contact the Daytronic Service Department at (937) 293-2566.
  • Page 14 Daytronic Corporation INSTRUCTION MANUAL 3200/3300 SERIES DIGITAL INDICATOR 1. DESCRIPTION The 3000 Instrument Series is a family of premium signal conditioning instru- ments that includes models to accomodate virtually all types of transducers and signal sources commonly encountered in electro-mechanical testing and control operations.
  • Page 15 "3000" Digital Indicator Table 1. 3000 Series Model Numbering 3000 Series instruction manual system is designed to provide the user with the following documentation: (1) a separate instruction manual for each type of Signal Conditioner purchased; (2) an instruction manual covering only the Digital Indicator section of a 3000 Series instrument, but applicable to any Form 2 or Form 3 instruments;...
  • Page 16 Daytronic Corporation of a 3000 Series instrument, but applicable to any Form instrument. It is the purpose of this manual to cover the Digital Indicator section of all Form 2 and Form 3 instruments. The Digital Indicator section of any Form 2 or Form 3 instrument consists of a...

  • Page 17: Installation

    "3000" Digital Indicator Table 2. Specifications Orange LED’s, six digits with polarity sign, 0.4 inch height. Display: MDS is either unlit or reads a 1 and contains the polarity sign. LSD is a dummy zero which can be programmed to be lit or unlit (rear-panel switch).
  • Page 18 Daytronic Corporation against the panel with the desired legend or character situated in place. Rubbing the legend or character with a ball-point pen will cause the legend to be transferred onto the panel. The legend can be protected from scratches which may occur during calibration/operation of the instrument by lightly spraying it with Krylon #1306 Workable Fixative.
  • Page 19 "3000" Digital Indicator A. ±20000 Range B. ±10000 Range C. ±5000 Range Figure 2. Full-Scale Displays for Three Ranges...

  • Page 20: Operation

    Daytronic Corporation power cord is ground. To maintain the safety ground when operating the instrument from a two-contact outlet, use a three-prong to two-prong adaptor and connect the green pigtail on the adaptor to ground. To prepare the instrument for operation, connect the power cable to a 105-135 volt ac, 50-400 Hz power source.

  • Page 21: Block Diagram Description

    "3000" Digital Indicator the display is flashing an overrange condition has occurred. Con- sequently, the displayed value may be invalid. The 20000 range is digitally limited to 19995. When an overrange occurs on this range, the display will flash all zeros. 4.
  • Page 22 Daytronic Corporation a Reference Integrate cycle. Each cycle has a time base in which a certain amount of clock pulses occur. The clock used is a 100-kHz crystal oscillator. The Auto-Zero cycle is used to bring the output of the integrator to zero and lasts 10,000 counts.
  • Page 23 "3000" Digital Indicator Figure 4. A/D Converter Timing Diagram...
  • Page 24 Daytronic Corporation twice as long as the Signal Integrate cycle, the analog input voltage required to give a full-scale reading is exactly equal to 2 V REF . Consequently, on the 20000 range, the V REF is 1 volt and the V SIG is 2 volts for full scale. On the 10000 range, the two cycles can be equal;...
  • Page 25 "3000" Digital Indicator high, the B SELECT input to the Bit Selector is pulled low through the NOR gate connected to the port. The A SELECT input is also low since it is either held hard low through the Range switches on the 5000 range or it is connected to D1 through the Range switches on the 10000 and 20000 ranges (when D5 is high D1 must be low).
  • Page 26 Figure 5. Block Diagram...

  • Page 27: Verification Of Normal Operation

    The user may also contact the factory Service Department or the local Daytronic Representative for assistance. One of the two techniques can be used to rapidly determine whether the Digital Indicator is malfunctioning or whether the problem is in the Signal Conditioner, transducer, or transducer cabling.
  • Page 28 Model 3300 Instruction Manual, v. SB.5 Pub. No. 3300M.5, Issued 10/96 Part No. 91131 MODEL 3300 HI-LO LIMITS INSTRUCTION MANUAL Daytronic Corporation Dayton, OH • Tel (800) 668-4745 www.daytronic.com...
  • Page 29 This page intentionally blank.

  • Page 30: Table Of Contents

    3 Limit Output Connector Functions/Pin Nos......8 PLEASE NOTE: Sections 6 and 7, Figures 8 and 9, and Table 4 have been removed from this manual. If you need information regarding specific 3330 components and circuitry, please contact the Daytronic Service Department at (937) 293-2566.
  • Page 31 NOTE The Model 3300 may operate in either of two modes: Latching Limits (LL), where limit logic outputs are held until application of an external Reset action, or Output Disable (OD), where limit logic outputs are non-latching being automatically disabled as soon as the Violation condition ceases.

  • Page 32: Description

    Daytronic Corporation INSTRUCTION MANUAL 3300 SERIES HI-LO LIMITS 1. DESCRIPTION The 3000 Instrument Series is a family of premium signal conditioning instru- ments that includes models to accomodate virtually all types of transducers and signal sources commonly encountered in electro-mechanical testing and control operations.

  • Page 33: 3000 Series Model Numbering

    "3000" Hi-Lo Limits Table 1. 3000 Series Model Numbering The 3000 Series instruction manual system is designed to provide the user with the following documentation: (1) a separate instruction manual for each type of Signal Conditioner purchased; (2) an instruction manual covering only the Digital Indicator section of a 3000 Series instrument, but applicable to any Form 3 instru- ment.

  • Page 34: Installation

    Daytronic Corporation The Hi-Lo Limit section of any Form 3 instrument consists of the following: ( 1) an additional printed-circuit board on which are mounted the required circuit components for Hi-Lo Limit operation, (2) associated front-panel controls and indicators, and (3) a rear-panel connector where the Limit mode is selected and where Limit logic outputs can be obtained.

  • Page 35: Specifications

    "3000" Hi-Lo Limits Table 2. Specifications Individual red LED’s indicate if limits are vio- Limit Status Display: lated. Single green LED indicates no violations (analog signal within OK range). Coarse and Fine setting potentiometers provided for Limit Setting: each limit. Individual Push-to-Set buttons also provided. When button is pushed, limit is displayed in proper engineering units on Digital Indicator.
  • Page 36 Daytronic Corporation Figure 2. Limit Modes To activate the Both Limits High mode, jumper pin E to pin F at the supplied rear-panel Limit output connector. In this mode, the limits can also be set positive or negative, as long as the High limit is set some increment more positive than the Low limit.
  • Page 37 Typical wiring to these outputs to obtain a contact closure is shown in Figures 4 and 5. In Figure 4, wiring to a Daytronic 9399 Triac Controller is illustrated. Notice that while a variety of logic configurations can cause a contact closure, that current is always sinked by the 3300 instrument.
  • Page 38 Daytronic Corporation Figure 3. Fast/Slow Signal Solder-Drop Terminals An Output Disable is also provided at the Limit output connector (pin A). When pin A is jumpered to pin B (common), all logic outputs (true and complement) are held high (+5 volts). Table 3 gives a listing of the functions available at the Limit output connector and the corresponding pin numbers.

  • Page 39: Operation

    "3000" Hi-Lo Limits Table 3. Limit Output Connector Functions/Pin Nos. Pin Number Function Jumper Both Limits High Note: F to enable mode. Both Limits Low Jumper E to D to enable mode. No Low/OK/High connection to E enables mode. 3. OPERATION The only operation required is turning ON/OFF ac power and setting the desired limits.
  • Page 40 Daytronic Corporation Figure 4. Model 9399 Triac Controller Wiring...

  • Page 41: External Relay Driver Wiring

    "3000" Hi-Lo Limits Figure 5. External Relay Driver Wiring Before setting the Low and High limits, the user should refer to Limit Setting. Section 2 of this manual and become familiar with the limit mode in which the instrument is to be operated. Figure 2 illustrates the three operating modes by giving a graphic representation of typical limit settings.

  • Page 42: Front-Panel Description

    Daytronic Corporation The limits are now set and the appropriate LOW and HIGH status indicators will light when a violation of the limit occurs. The OK indi- cator will be lit when there is no violation. For the front-panel NOTE:...

  • Page 43: Block Diagram Description

    "3000" Hi-Lo Limits 4. BLOCK DIAGRAM DESCRIPTION The purpose of this section is to explain how the Limit circuits work by using a simplified block diagram. This section is not intended to provide a detailed explana- tion of electronic circuits for personnel untrained in electronic technology. How- ever, it provides an adequate overview of operation for those familiar with basic electronic circuit operation.
  • Page 44 Daytronic Corporation Limit mode selection is accomplished by connecting the Both Limits High line or the Both Limits Low line to the Limit Select line (-9 volts) at the Limit output connector. The unit is shipped with neither of these connections made, automati- cally enabling the Low/OK/High mode.

  • Page 45: Verification Of Normal Operation

    The user may also contact the factory Service Department or the local Daytronic Representative for assistance. Make certain that the desired limit mode has been properly selected and that the limits have been set according to the front-panel terminology.

  • Page 46: Block Diagram

    Figure 7. Block Diagram...
  • Page 47 Daytronic Corporation Adjust the Coarse and Fine Low Limit controls until the LOW indicator lights. Using the Fine control, backoff the limit until the LOW indicator extinguishes; then, readjust the Fine control until the indicator lights again. Press the Set Low Limit button. The Digital Indicator should have the same reading that was previously displayed for the Signal Conditioner output.

  • Page 48: Ma Current Output

    3000 “C” Option Instruction Manual, v. SB.2 Pub. No. 3000CM.2, Issued 10/96 3000 SERIES “C” Option 4-20 mA CURRENT OUTPUT INSTRUCTION MANUAL Daytronic Corporation Dayton, OH Tel (800) 668-4745 www.daytronic.com...
  • Page 49 1. General Description Operating in this mode, any 3000 Series instrument can transmit high-accuracy measurement data as process signals for supervisory monitoring and control. Each “C” unit produces two kinds of analog output simultaneously: (1) its normal voltage output and (2) a current output continuously proportional to the voltage signal to within ±0.05%.
  • Page 51 3000 “G” Option Instruction Manual, v. SB.2 Pub. No. 3000GM.2, Issued 10/96 Part No. 91637 3000 SERIES “G” Option DUAL GALVANIC ISOLATED OUTPUT INSTRUCTION MANUAL Daytronic Corporation Dayton, OH • Tel (800) 668-4745 www.daytronic.com...
  • Page 52 1. General Description With this optional circuit board, a Form 1 (“31XX”) or Form 2 (“32XX”) instrument can furnish two independent galvanic outputs, fully isolated not only from each other but also from the 3000 instru- ment's “common.” Each output is normally set at the factory for a full-scale range of 0-10 V-DC (±0.2%) when the data signal from the 3000 unit's conditioner card is at its standard 5-V level.
  • Page 53 Pinout for I/O Connectors (REAR VIEW) 9 10 Fig. 1 Rear-Panel Location of 3000G Galvanic 3000 "G Option" Board Output Board I/O Connector (20-pin) Pin 1 Pin 10 Pin A Pin L Conditioner Board I/O Connector (20-pin) G Option Board Fig.
  • Page 54 Fig. 3 Location of Internal G-Option Controls...
  • Page 56 3000 “P” Option Instruction Manual, v. SB.2 Pub. No. 3000PM.2, Issued 10/96 3000 SERIES “P” Option ANALOG PEAK CAPTURE INSTRUCTION MANUAL Daytronic Corporation Dayton, OH • Tel (800) 668-4745 www.daytronic.com...
  • Page 57 1. General Description With the installation of a special “P” version of the 3000 Series HI-LO LIMITS board (shown in Figure 2, below), real-time analog peak capture is possible for a Form 2 (“32XX”) or Form 3 (“33XX”) instrument, in addition to its normal “tracking” function. Controlled either by front-panel push buttons (Fig.
  • Page 58 2. Connections Pin assignments for the 3000P board's 20-pin I/O connector (shown in Fig. 1) are given in the following table.* Pin Number Function PEAK ANALOG SIGNAL Holds peak analog input value when in PEAK mode; follows analog input continuously when in TRACK mode TRACK Used for external peak reset control (see Fig.
  • Page 61 3000 “R” & “S” Options Instruction Manual, v. SB.2 Pub. No. 3000RSM.2, Issued 10/96 3000 SERIES “R” & “S” Options INTERNAL RELAY INSTRUCTION MANUAL Daytronic Corporation Dayton, OH • Tel (800) 668-4745 www.daytronic.com...
  • Page 62 1. General Description With this option, a Form 3 instrument can switch power for control action in all types of open-loop or ON-OFF closed-loop operations.* It may be used, for example, to actuate alarms or sorting devices, or to start up or shut down external processes. Both relay types are controlled directly by the unit's LIMIT VIOLATION outputs, as shown in Fig.
  • Page 63 Fig. 2 Relay Pin Connections for 33XX HI-LO “R” and “S” Options LIMITS BOARD WITH "R" OR Rear I/O Connector "S" OPTION Normally open; closed when LOW LIMIT is violated Normally closed; opened when LOW LIMIT is violated Normally open; closed when HIGH LIMIT is violated Normally closed;...
  • Page 66 Daytronic Corporation Dayton, OH • (800) 668-4745 www.daytronic.com...
