HōM
Energy Manager
®
Programmable Thermostat
User's Manual
OHDRD1503-B
IT801
Look inside for a complete guide to the setup
and operation of your new thermostat.
Installed by: ___________________________________________
Date: _________________________________________________
Number of Thermostats: ________________________________
Notes: ________________________________________________
800.956.8825 • duke-energy.com/homenergymgr

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HoM Energy Manager IT801 and is the answer not in the manual?

Questions and answers

Related Manuals for Duke Energy HoM Energy Manager IT801

Summary of Contents for Duke Energy HoM Energy Manager IT801

  • Page 1 HōM Energy Manager ® Programmable Thermostat User’s Manual IT801 Look inside for a complete guide to the setup and operation of your new thermostat. Installed by: ___________________________________________ Date: _________________________________________________ Number of Thermostats: ________________________________ Notes: ________________________________________________ OHDRD1503-B 800.956.8825 • duke-energy.com/homenergymgr...

  • Page 2: Table Of Contents

    HōM Energy Manager Table of Contents Step 1: Getting Started ............................4-12 A. Thermostat Buttons and Indicators ......................4 B. Thermostat Display ..........................5-6 C. Set Clock ............................7-12 Step 2: Set Program Schedule ..........................13-16 Step 3: Main Menu and Thermostat Settings ....................... 17-21 A.
  • Page 3 HōM Energy Manager Your Duke Energy HōM Energy Manager thermostat controls your central air conditioning and heating system. The types of ® compatible systems include: Central Air Conditioners: Heat Pump:* Furnaces: Aux Heat: • Single-Stage • Single-Stage • Single-Stage Gas or Oil •...

  • Page 4: Step 1: Getting Started

    HōM Energy Manager Step 1: Getting Started A. Thermostat Buttons and Indicators Nightlight Enables or disables illumination. Provides nightlight function. Can be used to activate the LCD backlight. FAN Button Changes fan setting (Auto/On). SYSTEM Button Changes operating mode (Off, Cool, Heat, Aux Heat [displayed on heat pump units only] and Off).

  • Page 5: Thermostat Display

    HōM Energy Manager Step 1: Getting Started B. Thermostat Display ¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿ Set At HOLD Stage MoTu WeThFr Next Clock Select Utility Sched Timed Prev Cool Other Heat Morning Perm Auto Evening Menu Night Done Energy Un Occupied Messaging Display Displays current date, HVAC system status, conservation period status and Duke Energy-related messages.
  • Page 6 HōM Energy Manager Step 1: Getting Started B. Thermostat Display (continued) ¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿ Set At HOLD Stage MoTu WeThFr Next Clock Select Utility Sched Timed Prev Cool Other Heat Morning Perm Auto Evening Menu Night Done Energy Un Occupied Time-Of-Day Program Displays current programming interval setting.

  • Page 7: Set Clock

    HōM Energy Manager Step 1: Getting Started C. Set Clock 1. From the main operating screen, press the Menu button. 2. Press the Clock button. HōM Energy Manager Programmable Thermostat User’s Manual ®...
  • Page 8 HōM Energy Manager Step 1: Getting Started C. Set Clock 3. Time Zone will be flashing. Use the button to select the current time zone. 4. Press the Next button. HōM Energy Manager Programmable Thermostat User’s Manual ®...
  • Page 9 HōM Energy Manager Step 1: Getting Started C. Set Clock 5. Daylight Saving Time is flashing. Use the button to select ON or OFF. Press the Next button. 6. The curent HOUR is flashing. Use the button to select the current hour. The 12-hour clock cycles through AM and PM hours.
  • Page 10 HōM Energy Manager Step 1: Getting Started C. Set Clock 7. The current MINUTES is flashing. Use the button to select the current minutes. Press the Next button. 8. The current MONTH is flashing. Use the button to select the current month. Press the Next button. HōM Energy Manager Programmable Thermostat User’s Manual ®...
  • Page 11 HōM Energy Manager Step 1: Getting Started C. Set Clock 9. The current DATE is flashing. Use the button to select the current date. Press the Next button. 10. The current YEAR is flashing. Use the button to select the current year. HōM Energy Manager Programmable Thermostat User’s Manual ®...
  • Page 12 HōM Energy Manager Step 1: Getting Started C. Set Clock 11. Press Done when completed. HōM Energy Manager Programmable Thermostat User’s Manual ®...

  • Page 13: Step 2: Set Program Schedule

    HōM Energy Manager Step 2: Set Program Schedule 1. From the main operating screen, press the Menu button. 2. Press the Sched button. NOTE: Monday is displayed to indicate Monday’s Time of Day (TOD) schedule is selected. Heat is displayed to indicate that the heat mode programming is selected.
  • Page 14 HōM Energy Manager Step 2: Set Program Schedule 3. Time is flashing to indicate it is the value to be changed. Use the button to make your time selection. 4. To run the fan continuously during this TOD period, press the FAN button to change the setting from Auto to On. HōM Energy Manager Programmable Thermostat User’s Manual ®...
  • Page 15 HōM Energy Manager Step 2: Set Program Schedule 5. Press the Next button to advance to the setpoint for the TOD period. 6. The setpoint is flashing to indicate it is the value to be changed. Use the button to make your setpoint selection.
  • Page 16 HōM Energy Manager Step 2: Set Program Schedule 7. Press the Next button to advance to the next TOD period. 8. Repeat steps 3 through 7 for the remaining TOD periods for that day. 9. Once all TOD periods have been programmed for the first day, repeat steps 3 through 8 for the remaining days. 10.

  • Page 17: Step 3: Main Menu And Thermostat Settings

    HōM Energy Manager Step 3: Main Menu and Thermostat Settings The User Programming Menu table (next page) summarizes the configuration items that the homeowner can adjust, and it provides a convenient space to keep track of your settings. To enter the User Programming Menu: 1.

  • Page 18: Reset Filter Timer

    HōM Energy Manager Step 3: Main Menu and Thermostat Settings (continued) To disable the filter timer: 1. Press the Menu button. The 2. Press the Other button to Programming menu screen advance the menu screen to title will appear in the WI-FI SETTINGS menu.

  • Page 19: Lcd Backlight Settings Menu

    HōM Energy Manager Step 3: Main Menu and Thermostat Settings (continued) C. LCD Backlight Settings Menu This menu allows you to choose when the LCD backlight illuminates. To choose when the backlight illuminates: 1. Press the Menu button. The 2. Press the Other button to menu screen title will appear in advance the menu screen to the messaging area.

  • Page 20: Keypress Beep Confirmation Menu

    HōM Energy Manager Step 3: Main Menu and Thermostat Settings (continued) 3. Press the Next button to 4. Use the button to advance to the NIGHTLIGHT select from: screen. OFF (default) Always off. ON Always on. 5. Press Done. E. Keypress Beep Confirmation Menu This menu allows you to enable or disable an audio beep confirmation of every key press.

  • Page 21: Time-Of-Day (Tod) Recovery

    HōM Energy Manager Step 3: Main Menu and Thermostat Settings (continued) F. Time-of-Day (TOD) Recovery This feature turns your system on before the TOD programming time to attempt to reach the setpoint at the start of the TOD period. 1. Press the Menu button. The 2.

  • Page 22: Step 4: How To Set A Temperature "Hold

    HōM Energy Manager Step 4: How to Set a Temperature “Hold” You can override the thermostat’s programmed temperature setpoint at any time by choosing one of three types of hold operations, explained below. The type you choose determines when the hold will end and the thermostat returns to its programmed schedule.

  • Page 23: Permanent Hold

    HōM Energy Manager Step 4: How to Set a Temperature “Hold” (continued) 3. The current time display in the center of the screen will begin flashing. Press the button to set the time you want the temperature hold to end. You may adjust the time in 15-minute increments and set a timed temporary hold for up to 24 hours.

  • Page 24: Step 5: Using The Keypad Lock

    HōM Energy Manager Step 5: Using the Keypad Lock The HōM Energy Manager thermostat enables you to limit user access through its keypad lockout feature. This security ® prevents unwanted changes to the thermostat settings and programming. You may select your level of security from two types of lockouts: A.

  • Page 25: Full (Full) Lockout

    HōM Energy Manager Step 5: Using the Keypad Lock (continued) B. Full (FULL) Lockout Prevents any type of user activity through the keypad except for turning on the backlight (if it was previously enabled). The user cannot change program settings, mode of operation, fan mode of operation or set/end a hold. To set a full lockout: 1.

  • Page 26: Unlocking The Keypad

    HōM Energy Manager Step 5: Using the Keypad Lock (continued) C. Unlocking the Keypad 1. At the main operating screen, 2. The display will change to the press and hold the ENTER LOCK CODE screen buttons simultaneously with “5555” flashing. Enter your for 3 seconds.

  • Page 27: Troubleshooting

    HōM Energy Manager Troubleshooting Power Loss The HōM Energy Manager thermostat is designed to withstand a power loss without the need of a battery backup. The ® thermostat responds to a power loss as follows: • All Thermostat Settings and Schedule Programming are stored to permanent memory and retained throughout the power loss. •...
  • Page 28 HōM Energy Manager Troubleshooting (continued) No Heat Possible Cause Corrective Action Pilot light not lit. If it will not stay lit, call for service from your HVAC contractor. System switch not set to HEAT. Press the thermostat’s SYSTEM button one or more times to select HEAT and press to raise the temperature setpoint above room temperature.
  • Page 29 HōM Energy Manager Troubleshooting (continued) No Cool Possible Cause Corrective Action System switch not set to COOL. Press SYSTEM button to select COOL and press lower the temperature setpoint below room temperature. Outdoor unit disconnect or breaker tripped. Verify the outdoor unit disconnect or breaker has not been tripped.
  • Page 30 Notes __________________________________________________________________________________________________________ __________________________________________________________________________________________________________ __________________________________________________________________________________________________________ __________________________________________________________________________________________________________ __________________________________________________________________________________________________________ __________________________________________________________________________________________________________ __________________________________________________________________________________________________________ __________________________________________________________________________________________________________ __________________________________________________________________________________________________________ __________________________________________________________________________________________________________ __________________________________________________________________________________________________________ __________________________________________________________________________________________________________ __________________________________________________________________________________________________________ __________________________________________________________________________________________________________ __________________________________________________________________________________________________________ __________________________________________________________________________________________________________ __________________________________________________________________________________________________________ __________________________________________________________________________________________________________ __________________________________________________________________________________________________________ __________________________________________________________________________________________________________ __________________________________________________________________________________________________________ __________________________________________________________________________________________________________ __________________________________________________________________________________________________________ HōM Energy Manager Programmable Thermostat User’s Manual ®...
  • Page 31 Notes __________________________________________________________________________________________________________ __________________________________________________________________________________________________________ __________________________________________________________________________________________________________ __________________________________________________________________________________________________________ __________________________________________________________________________________________________________ __________________________________________________________________________________________________________ __________________________________________________________________________________________________________ __________________________________________________________________________________________________________ __________________________________________________________________________________________________________ __________________________________________________________________________________________________________ __________________________________________________________________________________________________________ __________________________________________________________________________________________________________ __________________________________________________________________________________________________________ __________________________________________________________________________________________________________ __________________________________________________________________________________________________________ __________________________________________________________________________________________________________ __________________________________________________________________________________________________________ __________________________________________________________________________________________________________ __________________________________________________________________________________________________________ __________________________________________________________________________________________________________ __________________________________________________________________________________________________________ __________________________________________________________________________________________________________ __________________________________________________________________________________________________________ HōM Energy Manager Programmable Thermostat User’s Manual ®...
  • Page 32 FCC Statements: Warning: Changes or modifications to this device not expressly approved by Comverge, Inc. could void the user’s authority to operate the equipment. RF Exposure: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body.
