DNH HPA-60 Manual

HEAD OFFICE, NORWAY
DNH AS
Phone................... + 47 35 98 56 00
Fax...................... + 47 35 98 56 10
E-mail........................ dnh@dnh.no
Web-Site................. www.dnh.no
ISO 9001 CERTIFIED
Sound pressure levels at 1W/1m
Remove hexagonal nut, lead cable through cable gland and connect cable to terminals.

Screw hexagonal nut back on and tighten cable gland.

To change the position of the loudspeaker please adjust the bracket (by loosening / tightening the screws) as

required.
Stainless steel bracket is available as an option.

For optimum performance, always use the correct voltage / power and operate within the frequency limits as

stated.
Do not open loudspeaker when energized.

This loudspeaker is supplied with a 2 year warranty against defective workmanship.

NB! Not available with transformer. Separate matching transformer can be delivered.
T:\Dataark\DOC-format\HORN\HPA60.doc
ENGLAND
DNH WW Ltd
Phone....... + 44 1908 275 000
Fax.............+ 44 1908 275 100
E-mail.............dnh@dnh.co.uk
Installation, Operation and Maintenance Procedures
DNH reserves the right to alter specifications without notice
GERMANY
DNH GmbH
Phone... + 49 040 6569 30-0
Fax....... + 49 040 6569 30-30
E-mail............... dnh@dnh.de
Specifications
Material / Color
Mounting
Termination
Weight w/transformer
IP-rating
Max. / min. amb. temp
Rated / max. power
SPL 1W/1m
SPL rated power
Effective freq. range
Dispersion (-6dB) 1kHz / 4kHz
Directivity factor, Q
Options
HPA-60
USA
DNH Speakers Inc
Phone........... + 1 484 494 5790
Fax.............. .+ 1 484 494 5793
E-mail..dnh@dnhspeakers.com
PA/alu.alloy / RAL 7035
Bracket
Inside screw terminal
1,9 kg
67
150 °C / -50 °C
60 W / 60 W
110 dB
126 dB
310 – 8000 Hz
115° / 30°
Impedances, colors, labels
Rev. 30.05.2012
