Indyme Solutions AP9100 Installation Instructions

Introduction
The AP9100 is a proprietary access point designed to support Indyme's wireless
help buttons and sensors. The wireless signals are relayed via the LAN to an
Indyme control unit for processing. The AP9100 is a Power over Ethernet (PoE)
device and works with any 802.3af and 802.3at compliant switch.
Programming Parameters
The AP9100 has been pre-programmed at the factory and labeled with
identification and network information. On-site programming is NOT required.
Clone Mode
Enables the Access Point to broadcast the Netcode to other Indyme wireless devices. All wireless
devices and access points must have the same Netcode to communicate.
With the AP9100 powered up:
Press and Hold the –VOL and +VOL buttons simultaneously for approximately 5 seconds
The RF LED will flash Red and Green indicating the AP is in Clone Mode
Follow the directions provided with your wireless device to obtain the Netcode information
When ready to exit Clone Mode momentarily press either –VOL or +VOL
The RF LED will return to a solid Green indicating that the AP is in standard operating mode
Installation
Generally floor plans will be provided for a specific installation with the optimal installation location(s)
marked.
Tools Needed
• Phillips screwdriver
• Wire cutters
• RJ45 Crimp Tool
• Cable, CAT5E RJ45/RJ45
Location Considerations
The AP9100 can be installed on the outer walls or in the ceiling as needed for the coverage required.
Plan the installation such that each AP has the clearest possible "line-of-sight" to the largest possible
expanse of the sales floor. Each AP will require PoE for network connectivity and power.
Indyme Solutions, Inc. 8295 Aero Place San Diego, CA 92123 USA
Technical Document
AP9100 Wireless Access Point
Installation Instructions
+1.858.268.0717 +1.800.829.6141
430776-00
Rev. A
Page 1 of 4
