BEFORE YOU BEGIN:
1. Identify all parts in the box against the "Parts" List.
2. Remove all protective material carefully and avoid cutting the surface of the furniture while removing
wrapped material.
Part
A
B
C
Assembly Instructions
Description
Qty
Part
Bolt
4
Flat Washer
8
Lock
4
Washer
D
E
Description
Qty
Nut
4
Nut Cap
4
Advertisement
Related Manuals for NASSAU DL13-7
Summary of Contents for NASSAU DL13-7
- Page 1 Assembly Instructions BEFORE YOU BEGIN: 1. Identify all parts in the box against the “Parts” List. 2. Remove all protective material carefully and avoid cutting the surface of the furniture while removing wrapped material. Part Description Part Description Bolt Flat Washer Nut Cap Lock Washer...
- Page 2 Assembly Instructions (FOR DL13-7) ATTENTION: 1. DO NOT use power tools or over-tighten hardware during assembly.* *Aluminum is soft metal, so over-tightening may strip threads or break the parts. 2. Please read these instructions carefully before assembling. 3. During assembly, place furniture against soft surfaces to avoid scratching the paint/ metal.
