- Page 1 A Complete Remote Controlled Caddy A Complete Remote Controlled Caddy USER MANUAL...
-
Page 2: Table Of Contents
Table of Content Packing List..........P3 Specification..........P4 Folding and Unfolding Cybercart..P5 Installing the Front Wheel/Wheel Lock.P6 Charging the Battery........P7 Inserting the Battery.........P7 Motherboard Housing......P8 Remote Controller........P9 Operating..........P10 Gyroscope and Keypad Lock....P11 Freewheel Mode and Parking Brake..P12 The App............P13 FCC Statement.........P14 Warranty............P15 For more information please call 1-302-488-0774 or visit our website at www.alphardgolf.com... -
Page 3: Packing List
Packing List Remote Control Smart Charger USB-C Cable w/ Magentic Belt Clip Wheelie Bars Battery Water/Sand Bottle Holder (pre-installed) (Bottle not included) Umbrella Holder Dual Cup Holder Phone Holder... -
Page 4: Specification
Specifications Weight: Cart 38lbs Folded Dimensions: 20"x17.7"x25" Motor: Max Output 180W each Radio: 2.4G RF Material: Aircraft grade aluminum... - Page 5 Unfolding/Folding of Cybercart Step 1: Unlock the handle latch, unfold the handle to your preferred height, and then lock the handle latch again to secure the position. Step 2: Lift the handle or the upper cradle (to extend the wheels) until a “click” sound indicating main hinge is locked in place.
-
Page 6: Installing The Front Wheel/Wheel Lock.p6
Installing the Front Wheel Insert the front wheel into the front wheel stud of the Cybercart until you hear a ‘click’ sound, indicating that the front wheel is locked in place. To remove it, press the button on the front wheel assembly. -
Page 7: Charging The Battery
Charging the Battery Note: Charge the battery for at least 5 hours before the first use. • Plug the charger connector onto the battery’s charging port. A red light will start blinking on the battery face panel indicating that charging is in progress. •... -
Page 8: Motherboard Housing
“Stop” can be challenging. operation light will button on the Click the gyro stay blinking, remote for 3 button on the indicating that the seconds. remote to turn it power is on and off. Cybercart is in operation mode. -
Page 9: Remote Controller
Remote Controller Keypad Lock Go/Speed Up Left Turn Right Turn Stop Back/Speed Down Gyro On/Off Power On/Off Charging the Remote: Plug the included USB-C cable onto the remote and the wall outlet. It takes around 1 hour to fully charge and screen will show “charge completed”... -
Page 10: Operating
Once the the cart to the left. The top speed is 6. button is released, the Press “Back/Speed Cybercart will stop. Down to slow down. Right: Left turn: Right turn: Press “Right Turn” After pressing... -
Page 11: Keypad Lock
Gyroscope The Gyroscope(Gyro) is ON by default. It monitors the terrains and tries to keep a straight heading. Steering the cart manually with the gyro ON can be challenging. Click the gyro button on the remote to turn it off. Keypad Lock Always use the keypad lock function when the cart is stationary to avoid mis-triggering buttons while remote is in... -
Page 12: Freewheel Mode
“STOP” button on remote for 3 seconds. To de-activate, press any button on the remote. Caution: Do not tow Cybercart behind vehicle or motor cart no matter it is in freewheel mode or not. It will damage the motherboard and motors, and the... -
Page 13: The App
Only one blue tooth device can be used at a time. To exit connection, user may press “STOP” key on the remote controller to cancel, and the remote controller can take over and control the Cybercart. -
Page 14: Fcc Statement
NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment. RF Exposure Cybercart Remote This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. Cybercart This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. -
Page 15: Warranty
Warranty Our all new Cybercart comes with a two year express limited warranty that covers any manufacturing defects that occur while operating the unit for its intended purpose as set forth in our manual. All other products, accessories, including the batteries, are covered under a one year express limited warranty. - Page 16 Check Out Our Range of Accessories at www.alphardgolf.com Follow Follow Sidekick Sidekick Seat Seat Storage Net Storage Net Clean Trunk Case Clean Trunk Case Sand Bottle Sand Bottle Pictures might not illustrate the actual products, and they are subject to final product details.
