INSTALLATION, OPERATION AND

MAINTENANCE MANUAL

VACULOAD 1

RECOVERY UNIT

Table of Contents

Need help?

Do you have a question about the VACULOAD 1 and is the answer not in the manual?

Questions and answers

Summary of Contents for BLASTONE VACULOAD 1

Page 1 INSTALLATION, OPERATION AND MAINTENANCE MANUAL VACULOAD 1 RECOVERY UNIT...
Page 3: Manual Contents
MANUAL CONTENTS Safety Warnings Rules For Safe Operation Product Description Setup Operation Shutdown Fault Finding Maintenance Spare Parts Fill in your model and serial number in the blank spaces below. These can be used for reference whenever service or maintenance is required. Unit Serial Number Date Of Issue...
Page 4: Safety Warnings
SAFETY WARNINGS CAUTION • Do not attempt to operate this equipment without first reading and understanding the manual enclosed with this device. WARNING This recovery unit does not extract lead from the contaminated material. Therefore, lead may be present in the dust and fines extracted during the processing. Appropriate health and safety measures must taken to avoid exposure to lead contaminants.
Page 5 CAUTION • The products described and illustrated in this manual are intended for experienced and knowledgeable users of similar equipment used in the blasting industry. The important safety instructions appearing in this manual cover normal conditions and situations. No representations are made or intended as to the useful life, maintenance cycles, efficiency or performance of this product or combination of products.
Page 6: Rules For Safe Operation
RULES FOR SAFE OPERATION • Must disconnect supply air to unit before any maintenance is performed. • All personnel in the work area MUST use hearing protection and approved respiratory equipment. Operation of this equipment could expose operators to sound levels exceeding 100 db. •...
Page 7 • Fire damage notice. Do not operate if the vessel has been damaged by fire. If damaged, take out of service immediately and have it inspected and/or repaired at a qualified facility. • Inspect equipment regularly. Do not operate if the vessel has been damaged. Inspect the outside and inside of the pressure vessel regularly for corrosion and damage (i.e.
Page 8: Design Features
- virtually anywhere that waste cannot be easily removed. • The BlastOne Vacuload Series 1 Vacuum system consists of a single cartridge pulse-jet dust collector, with a single eductor vacuum pump mounted on a skid with forklift channels. The integral dust cartridge traps airborne dust, with all waste falling into the easily removed waste drum.
Page 9 COMPONENTS Reverse pulse valve Filter housing cantilever handle Reverse pulse manifold drain valve Reverse pulse manifold Waste drum Suction Inlet Air Inlet Filter housing Eductor Skid with integrated fork pockets...
Page 10 COMPONENTS Vacuum suction hose from Eductor, Filter strainer connected to filter housing Magnehelic gauge Controls plate Vacuum gauge Filter Housing Cantilever Pulse timer box Muffler...
Page 11: System Setup
1. Using a forklift, place the unit within the working distance of the vacuum hose and pickup tool. 2. Position the Interceptor Tank (if used) as close as possible to the Vacuload 1. 3. If an Interceptor is used, refer to the manual supplied for that item of equipment for set up information.
Page 12 VACUUMING BlastOne vacuum systems are designed to produce high vacuum and high air flow at the suction head. When vacuuming remember that it is air that is moving the material being vacuumed. Abrasives can be vacuumed vertically upwards and downwards just as easily as horizontally. Best results will be achieved by using plastic pipe (rather than hose) and keeping the pipe vertical to minimize friction against the wall of the pipe.
Page 13 SHUTDOWN SHUTDOWN WHEN VACUUMING IS COMPLETED FOR THE DAY: 1. Turn off air supply valve at the compressor (recommended). 2. Drain the moisture from the manifold using the drain ball valve. Leave the ball valve open until all air is expelled. 3.
Page 14: Fault Finding
FAULT FINDING FAULT POSSIBLE CAUSE REMEDY Check all hose connections for leaks. Adjust Insufficient air at inlet density controller (on pickup tool) to allow more air flow. Clogged vacuum hose Straighten out hose. The radius of any hose Sharp bends in vacuum hose should be greater than 10 times it’s diameter.
Page 15 FAULT POSSIBLE CAUSE REMEDY Check the nozzle to make sure it is High suction which Poor air/abrasive mixture in the not plugged with wet abrasive or any gradually diminishes pickup nozzle foreign object. Inaccurate gauge Check the gauge lines for breaks. This will cause the dust to cake on the filter preventing air from flowing Magnehelic gauge...
Page 16: Maintenance
MAINTENANCE The following suggested maintenance program should be implemented to ensure a long and effective unit life. Whenever servicing equipment, make sure all air lines are shut off and bled. Person(s) servicing equipment should wear a respirator, face shield and protective clothing. Daily ITEM INSPECTION...
Page 17: Spare Parts
SPARE PARTS SPARE PARTS ITEM PART NUMBER ITEM PART NUMBER Reverse pulse timer RCAC 20T 4002 Reverse pulse solenoid DM2229000 Ball valve (2”) FVBL050 Ball valve (1/2”) FVBL015 Eductor VC-201831100 Eductor nozzle (350) 2-5002 Filter cartridge Magnehelic gauge DF ULTC 4004K535 Muffler 2011-011P...
Page 18 4510 Bridgeway Avenue BLASTONE INTERNATIONAL (AUST) PTY LTD Columbus Ohio 43219 USA 57 Alexandra Place Murarrie Queensland 4172 Australia Toll Free 800 999 1881 Fax (614) 476 3002 PO Box 3385 Tingalpa DC Email sales@blastone.com Queensland 4172 Australia Website www.blastone.com...
