08/2024
Harvia Kip Series
Installation
Requirements:
Phillips and Flat Head Screwdrivers
Cordless Drill
1 1/8" Drill bit
Wire Cutters
These are guidelines only,
All wiring should be installed according to the heater manufacturers instructions and by a
licensed electrician.
Do NOT use a G.F.I breaker
tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com
Advertisement
Summary of Contents for leisurecraft Harvia Kip Series
- Page 1 Cordless Drill 1 1/8” Drill bit Wire Cutters These are guidelines only, All wiring should be installed according to the heater manufacturers instructions and by a licensed electrician. Do NOT use a G.F.I breaker tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 2 Measure up from the floor 20” and make a mark. Measure 7 5/8” (19cm) on either side of the mark for the mounting screws. tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 3 5- 7” (13-18cm) above the floor. Locate a suitable location to drill a hole for the power cable. Use the 1 1/8” (29mm) drill bit to drill a hole through the wall. tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 4 Set it aside for now All wiring should be installed according to the heater manufacturers instructions and by a licensed electrician. Remove one of the grommets on the bottom of the heater and run the wires through. tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 5 Keep the temperature sensor outside of the heater. Remount the heater onto the screws To mount the temperature sensor, measure and mark the wall 14” (36cm) from the heater and 14” (36cm) from the ceiling. tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 6 Insert the sensor into the grooves on the housing ensuring it is snug. Fold the sides of the housing over each other. Cover any exposed sensor wiring with the included trim pieces. tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 7 , It is recommended to “break-in” the sauna before using it for the first time by turning on the heater to its highest setting and operate it for 1 hour. This is recommended to burn off any oils and impurities from manufacturing. tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 8 Center the guard around the heater and secure to wall with the preplaced screws. Ensure the guard is level and secure the other side. tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
