- Page 1 Quanta Microsystems Inc. ZM100 operation manual-RF mode...
- Page 2 Quanta Microsystems, Inc. Subject: Rev: ZM100 operation manual-RF mode Revised Date: Doc No. OP_ZM100-1 2007/05/16 Page: 2 of 9 Reason for Release： Revision Effective Date Author Description of Changes 05/16/2007 Samuel Wang First draft QMI PROPERTY & CONFIDENTIAL!
- Page 3 Quanta Microsystems, Inc. Subject: Rev: ZM100 operation manual-RF mode Revised Date: Doc No. OP_ZM100-1 2007/05/16 Page: 3 of 9 Adaptor board connection and setup Power IN (+3.3Vdc) USB plug in: ― J_USB should be selected as USB PWR IN mode ―...
- Page 4 Quanta Microsystems, Inc. Subject: Rev: ZM100 operation manual-RF mode Revised Date: Doc No. OP_ZM100-1 2007/05/16 Page: 4 of 9 UART connection Use a D-SUB9 cable connects to PC com port Open OS hyper terminal as a com port used Set properties as following Fig 1.1 Hyper terminal COM port settings...
- Page 5 Quanta Microsystems, Inc. Subject: Rev: ZM100 operation manual-RF mode Revised Date: Doc No. OP_ZM100-1 2007/05/16 Page: 5 of 9 Fig 1.2 Hyper terminal Properties settings QMI PROPERTY & CONFIDENTIAL!
- Page 6 Quanta Microsystems, Inc. Subject: Rev: ZM100 operation manual-RF mode Revised Date: Doc No. OP_ZM100-1 2007/05/16 Page: 6 of 9 Fig 1.3 ASCII setup After finished above item, connect DUT and adaptor board by 6pin wire connection. Then it will be operating as RF test mode...
- Page 7 Quanta Microsystems, Inc. Subject: Rev: ZM100 operation manual-RF mode Revised Date: Doc No. 2007/05/16 Page: 7 of 9 OP_ZM100-1 RF test mode application Channel selection Set channel ― Select character “1,2,3….,f,g to set channel 1~16 QMI PROPERTY & CONFIDENTIAL!
- Page 8 Quanta Microsystems, Inc. Subject: Rev: ZM100 operation manual-RF mode Revised Date: Doc No. OP_ZM100-1 2007/05/16 Page: 8 of 9 Set output power ― Default power: -0.66dBm (select character “n”) QMI PROPERTY & CONFIDENTIAL!
- Page 9 Quanta Microsystems, Inc. Subject: Rev: ZM100 operation manual-RF mode Revised Date: Doc No. OP_ZM100-1 2007/05/16 Page: 9 of 9 Set operation mode ― Select character “v,w,x…r,s” for operation mode After you finished testing, you can select character “t” to go back to main manual.
- Page 10 Statements of FCC, IC, CE, Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 11 20 cm may be maintained between the antenna and users. The final end product must be labeled in a visible area with the following Contains: “FCC ID:T5U-ZM100”. Manual Information To the End User The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF module in the user’s manual of the end...
