Summary of Contents for Fanmaster IFA2-160-2
- Page 1 Industrial Fume Extractor IFA2-160-2 Operation and Maintenance Manual Fanmaster Pty Ltd...
-
Page 2: Table Of Contents
Content 1. Product Profile Page 1 2. Technical Data Page 1 3. How it Works Page 3 4. Operation Instructions Page 3 5. Safety Page 4 6. Service and Repair Page 4 7. Fault Finding Page 4 8. Parts List Page 5 9. -
Page 3: Product Profile
1. Product Profile The supplier of Fanmaster Pty Ltd is a professional company which specializes in air purification machines’ research & development, manufacturing, project design and installation. With advanced technology introduced from Germany, Sweden, and using many imported parts, our products are widely used in over 200 fields such as welding, foundry, metal cutting, grinding, wood processing, paper making, ceramics, tobacco, chemistry etc. - Page 4 Product Layout & Photo...
-
Page 5: How It Works
Suction arm with hood 3. How it Works Through installing the centrifugal fan and the flexible arm on triangle fixed bracket, to arrange the suction arm with hood near the source point of the smoke, again through the electronic control box operation button to start the fan, the fan inhales smoke through the flexible suction arm and discharge room outlet. -
Page 6: Safety
1) Please read the instruction manual carefully before using the fan, check whether voltage of power supply matching the system power voltage indicated in the instruction manual (3×415V/50Hz, voltage fluctuation±10%), insert the power plug into a specialized power socket. 2) After making sure the power supply is correct, turn the on-load switch to “on” to connect power supply. -
Page 7: Fault Finding
Regularly (one year) tighten the nut which connect fixing flange and the extractor’s upper housing, stainless steel clamp which connect fixing flange and positioning flange, to prevent leakage from affecting suction. 7. Fault finding Fault Reason of the fault Solving method 1) Power supply lack of phase or 1) Check power supply. -
Page 8: How To Adjust Arm
(4) If the spare parts have any breakage, it should change it in time to avoid the whole effect. (5) Only specialized workers can open the suction arm to avoid the unnecessary trouble. 11. Contact information Company: Fanmaster Pty Ltd 1/6-8 Yalgar Rd., Kirrawee NSW 2232, Sydney , Australia Address:... - Page 9 E－mail：sales@ fanmaster.com.au Website: www.fanmaster.com.au...
