HOW TO ASSEMBLE
1
A
A - Straighten the handle.
B - Align both holes by
rotating the board cam.
800-968-6245
•
INFO@CAMOFASTENERS.COM
2
B
Insert flathead screw from
the bottom of board cam.
CUSHIONED
NON-SLIP
HANDLE
BOARD CAM
•
WWW.CAMOFASTENERS.COM
How To Use the LEVER™
3
Use supplied hex key to
securely tighten the screw.
PIVOT PIN
JOIST ADJUSTMENT
JOIST CAM
KNOB
2-SIDED
STOP BLOCK
GRAND RAPIDS, MI 49519
WWW.NATIONALNAIL.COM
