Dalton Z0312 User Instruction Manual

User Instruction Manual for Z0312 Smart Lock
Thank you for choosing the DALTON Z0312 Smart Lock. This manual provides guidance on how to install and
use the lock, and includes important safety and precautionary measures. Please read this manual carefully
before using the product to ensure proper operation and maximum safety.
1.
Safety and Precautions:
1. Read all instructions in their entirety to ensure that you have a complete understanding of the lock's features,
installation requirements, and operation procedures.
2. We highly recommend seeking the assistance of a professional installer to ensure proper installation.
3. Before installation, please ensure that the lock and lock body are selected correctly according to the door opening
direction. Failure to do so may result in improper function or damage to the lock.
4. Familiarize yourself with all warning and caution statements provided in this manual, as they are designed to
protect you and others from harm or injury.
5. It is important to remind all family members of the safety precautions associated with using the lock, including
keeping access to the back panel restricted and regularly checking the lock's settings to ensure they have not been
altered without your knowledge.
6. To prevent unauthorized access, it is recommended to protect your user codes and master code.
7. Dispose of used batteries in accordance with local laws and regulations to avoid environmental hazards.
CAUTION:
1. Keep the lock away from children to prevent any accidents.
2. Do not use any cleaning agents that contain corrosive chemicals to clean the lock. Use a soft cloth and mild
detergent instead.
3. Do not attempt to disassemble or modify the lock in any way. Contact the manufacturer for any repairs or
maintenance.
4. In case of emergency, use a backup mechanical key to unlock
Note: different door types have different accessories, please check
whether they match before starting the installation.
2.
Pre-installation Tools:
You will need:
Phillips screwdriver (You can use either a manual or electric screwdriver, but avoid using a power drill.)
Measuring Tape
Pencil
Level
PACKAGE CONTENTS LIST
A
DESCRIPTION QTY
PART
A Screw A 20MM
4
B
Screw B 20MM 1
B
C Screw C 6MM 1
Screw D 10MM 1
D
Screw E 45MM 3
E
C
Solenoid F 3
F
G Front Panel 1
H 1
Back Panel
D
I Mounting Plate 1
J Deadbolt Latch 1
K Strike Plate 1
E
L Cylinder 1
M 2
Back Up Keys
N
Cards 2
F
O Drilling Template 1
P Battery 4
3.
Door Preparation:
Check Dimensions
I
H
G
L
K
J
N O
M
To ensure a proper installation of the Smart
Lock, please follow these guidelines:
Verify the door status and ensure that the
door-frame is properly aligned with the
door.
Check that there are no obstructions
obstructing the door-frame.
Make sure there is enough space for the
deadbolt to extend into the door-frame
when the door is locked.
