XEB2-5-B-LM Series
Installation Instructions
READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
When using electrical equipment, basic safety precautions should always be followed including the following:
• DISCONNECT AC POWER SUPPLY BEFORE SERVICING.
• Installation and servicing of this equipment should be performed by qualified service personnel only.
• Ensure that the electrical wiring conforms to the National Electrical Code NEC® and local regulations
if applicable.
• Do not mount near gas or electrical heaters.
• Do not use outdoors.
• Equipment should be mounted in locations and at heights where it will not be readily subjected to tampering
by unauthorized personnel.
• The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.
• Any modification or use of non-original components will void the warranty and product liability.
• Do not use this equipment for other than intended use.
• Allow battery to charge for 24 hours before first use.
• For use with metal enclosed wiring systems.
10070239 REV 1 - 02/21
IMPORTANT SAFEGUARDS
SAVE THESE INSTRUCTIONS!
Technical Support ■ (623) 580-8943 ■ technicalsupport@barronltg.com
1
800-533-3948 www.barronltg.com
Advertisement
Summary of Contents for BARRON Exitronix XEB2-5-B-LM Series
- Page 1 XEB2-5-B-LM Series Installation Instructions IMPORTANT SAFEGUARDS READ AND FOLLOW ALL SAFETY INSTRUCTIONS. When using electrical equipment, basic safety precautions should always be followed including the following: • DISCONNECT AC POWER SUPPLY BEFORE SERVICING. • Installation and servicing of this equipment should be performed by qualified service personnel only. •...
- Page 2 XEB2-5-B-LM Series Installation Instructions Notes 1. This device is designed for indoor use. Do not use outdoors. 2. Prior to installation, battery connector must be open to prevent high voltage from being present on output leads (red & yellow). 3. This unit can operate commonly used linear and compact fluorescent lamps. Please refer to the “lamps list” label on the ballast for specific lamp information.
- Page 3 XEB2-5-B-LM Series Installation Instructions Installing the LED Combo Test Switch (LCTS) Fig. 1 - Recessed Troffer Fixture Recessed Troffer Fixture (Fig. 1) Select a convenient location with proper clearance in the ballast cover and drill or punch a 7/8" hole (1/2" knockout). Insert the 7/8"...
-
Page 4: Completing Installation
XEB2-5-B-LM Series Installation Instructions Labels Attach the appropriate labels adjacent to the LCTS. Annotate ‘Re-lamping’ label for lamp type and wattage. The ‘Caution’ and the ‘Re-lamping’ labels must be on the fixture in a readily visible location to anyone attempting to service the fixture. Completing Installation When the installation is complete, switch the AC power on and join the unit connector of the EMERGENCY BALLAST. - Page 5 XEB2-5-B-LM Series Installation Instructions Wire Diagrams for Lamp Emergency Operation Note: Emergency ballast and AC ballast must be fed from the same branch circuit Typical schematics only. May be used with other ballasts. Consult the factory for other wiring diagrams. Use the proper tap to cap unswitched AC lead.
- Page 6 XEB2-5-B-LM Series Installation Instructions Wire Diagrams for Lamp Emergency Operation (Continued) For 2 Lamp Fixture (Fig. 9 - 13) Fig. 11 - Serves Sequence Instant Start Ballast Fig. 12 - Instant Start Electronic Ballast Fig. 13 - Circline Rapid Start Ballast For 3 Lamp Fixture (Fig.
- Page 7 XEB2-5-B-LM Series Installation Instructions Wire Diagrams for Lamp Emergency Operation (Continued) For 4 Lamp Fixture (Fig. 17 & 18) Fig. 16 - Instant Start Ballast Fig. 17 - Rapid Start Ballast Emergency Only (Fig. 18) Fig. 18 - One (1) Lamp Without AC Ballast 10070239 REV 1 - 02/21 800-533-3948 www.barronltg.com...
