INSTRUCTION
Version 12.02.2020
RBG LEONIS
Optionally: can be programmed as single room controller
WITH FREE EASY-TO-CONFIGURE
PC-SOFTWARE
DOWNLOAD:
http://www.eap-electric.at/de/produkte/automationstechnik-
buskomponenten/raumbedien-und-regelgeraete/product/rbg-
leonis-2/
ATTENTION USE ALWAYS LATEST VERSION!
EAP electric GmbH
A-2460 Bruck/Leitha Florianistraße 4
Tel
+43/2162/67910
Fax
+43/2162/67910/10
E-mail
office@eap-electric.at
Web
www.eap-electric.at
Seite 1 von 16
Advertisement
Summary of Contents for EAP RBG LEONIS
- Page 1 AUTOMATIONSTECHNIK • SENSOR • REGELTECHNIK • ANTRIEBSTECHNIK _________________________________________________________________________________________ INSTRUCTION Version 12.02.2020 RBG LEONIS Optionally: can be programmed as single room controller WITH FREE EASY-TO-CONFIGURE PC-SOFTWARE DOWNLOAD: http://www.eap-electric.at/de/produkte/automationstechnik- buskomponenten/raumbedien-und-regelgeraete/product/rbg- leonis-2/ ATTENTION USE ALWAYS LATEST VERSION! EAP electric GmbH A-2460 Bruck/Leitha Florianistraße 4...
- Page 2 RH +T (optional CO2) sensor. The room control unit can be used as slave version or as single room controller (with customer specific software from EAP on request). Application in the medical sector, building engineering and industry. Many functions are possible:...
- Page 3 It is recommended to load a suitable demo-configuration with „Load“ and to change it according to your own needs. Here you can see the general settings. A brief explanation to the respective parameters is shown at the bottom right. It looks like follows: EAP electric GmbH A-2460 Bruck/Leitha Florianistraße 4 +43/2162/67910...
- Page 4 The images can vary in size and must be in bitmap format. They are displayed correctly on the PC (only the frames, also at the text fields are not visible in the Leonis) EAP electric GmbH A-2460 Bruck/Leitha Florianistraße 4 +43/2162/67910...
- Page 5 Creation of graphic: In the screen area, right click, add icon or add text, as an example indexed text: off, manual, automatic: Insert the 3 required texts in the tab texts: EAP electric GmbH A-2460 Bruck/Leitha Florianistraße 4 +43/2162/67910 +43/2162/67910/10 E-mail office@eap-electric.at...
- Page 6 Please note, that indexed text 1 requires for placement and window width the index of the longest string. Therefore there is entered 2, later 0 as we want to start with Aus. EAP electric GmbH A-2460 Bruck/Leitha Florianistraße 4 +43/2162/67910...
- Page 7 The variables are mapped to holding registers, therefore the PLC can both read and change the values. The display then changes accordingly. EAP electric GmbH A-2460 Bruck/Leitha Florianistraße 4 +43/2162/67910...
- Page 8 Now delete the both not desired icons lamps on the left and on the right top. Simply press the icon with right click and delete. Now move the textfield to the desired position. After the index text 1 has been corrected to 0 it looks like follows: EAP electric GmbH A-2460 Bruck/Leitha Florianistraße 4 +43/2162/67910...
- Page 9 To do this, select icon type indexed and then select the both pictures via the drop down menu. Furthermore, a user variable must be assigned. Overall this looks like this: Icons drop down menu: EAP electric GmbH A-2460 Bruck/Leitha Florianistraße 4 +43/2162/67910...
- Page 10 Now the button has to be configured. Left click on the left third button and the corresponding menu appears. There must be set on/off. The limit values and the variable must also be set. It looks as follows: EAP electric GmbH A-2460 Bruck/Leitha Florianistraße 4 +43/2162/67910...
- Page 11 Then press write (often it needs to be pressed more than once, problem will be solved). The download takes some time, especially if many icons or standby/startup pictures are used, but the progress is displayed. This looks something like this: EAP electric GmbH A-2460 Bruck/Leitha Florianistraße 4 +43/2162/67910...
- Page 12 24 Bytes (12 register) for textstring 3 24 Bytes (12 register) for textstring 4 TEXT4_1 ..TEXT4_12 80…91 24 Bytes (12 register) für textstring 5 TEXT5_1 ..TEXT5_12 92…103 EAP electric GmbH A-2460 Bruck/Leitha Florianistraße 4 +43/2162/67910 +43/2162/67910/10 E-mail office@eap-electric.at www.eap-electric.at Seite 12 von 16...
- Page 13 If the font is green, Modbus is active (correct parameters incl. slave address). If there are no bus accesses, the font is back. At wrong modbus parameter (but not the slave address).the font is red EAP electric GmbH A-2460 Bruck/Leitha Florianistraße 4 +43/2162/67910...
- Page 14 The LEONIS is designed for mounting on concealed outlet and the assembly takes place with a mounting plate, screws and connection plug with plugable double-push-in terminals (preinstallation possible), which are included in the scope of delivery. EAP electric GmbH A-2460 Bruck/Leitha Florianistraße 4 +43/2162/67910...
- Page 15 "xx.x°C TP" with global color settings. Texts 13-18 will contain only numbers, without auxilary unit symbols(°C, F, %, etc.)! 13) Color_Text_Tist_C_Number: shows current (measured) temperature in "°C" with fixed format "xx.x" with adjustable color settings. EAP electric GmbH A-2460 Bruck/Leitha Florianistraße 4 +43/2162/67910 +43/2162/67910/10 E-mail office@eap-electric.at...
- Page 16 * - most text types have their duplicates with word "COLOR" in their names. These duplicates are the same as basic text types but with individually selectable text color and its background color. Configuration tool generates different configuration files for Leonis(*.cfg) and LeonisMaster(*.lcfg) devices, they are not compatible! EAP electric GmbH A-2460 Bruck/Leitha Florianistraße 4 +43/2162/67910 +43/2162/67910/10 E-mail office@eap-electric.at...
