ST-1200
Link: https://help.tds.ai/installation-guide/st-1200/ Last Updated: January 14th, 2020
The installation kit contains a registration card, the ST-1200, one abrasive pad, one alcohol wipe, two 3M primer
sticks, five rivets, four self-tapping screws, four flanged button head machine screws, four well nuts, a packet of
dielectric grease and two spare locknuts.
Additional tools and supplies that you may need include a cordless drill, fine tip marker, 1/4" (7mm) and 11/64"
(4mm) drill bit, 8mm nut driver drill attachment, a 5/64" (1.98mm) hex key, clean rag, and an extension ladder.
Installation Overview
The following steps provide an overview of the installation process:
1.
Install preparation.
2.
Determine mounting location.
3.
Device installation.
4.
Verify the installation.
Installation Steps
1. Install preparation.
Locate a pen and the Registration Card.
1.
Complete the registration card by locating the thirteen-digit serial number on the bottom of the
device and copying the nine numerical digits onto the card.
Copyright ©2024 TDS
Page 1 of 5

Advertisement

loading
Need help?

Need help?

Do you have a question about the ST-1200 and is the answer not in the manual?

Questions and answers

Related Manuals for TDS ST-1200

Summary of Contents for TDS ST-1200

  • Page 1 Link: https://help.tds.ai/installation-guide/st-1200/ Last Updated: January 14th, 2020 The installation kit contains a registration card, the ST-1200, one abrasive pad, one alcohol wipe, two 3M primer sticks, five rivets, four self-tapping screws, four flanged button head machine screws, four well nuts, a packet of dielectric grease and two spare locknuts.
  • Page 2 ST-1200 Link: https://help.tds.ai/installation-guide/st-1200/ Last Updated: January 14th, 2020 Note. Be sure you write down the serial number (GT-12 S/N) Remove the red label, and magnet to activate the device. Copyright ©2024 TDS Page 2 of 5...

  • Page 3: Determine Mounting Location

    ST-1200 Link: https://help.tds.ai/installation-guide/st-1200/ Last Updated: January 14th, 2020 2. Determine mounting location. Identify a suitable mounting location that provides the ST-1200 with the best view of the sky for both GPS reception and solar charging. Note. The device should remain clear of any moving parts, not mounted to any removable panels or positioned where damage to the device could be caused by normal operation, cargo, or terrain.
  • Page 4 ST-1200 Link: https://help.tds.ai/installation-guide/st-1200/ Last Updated: January 14th, 2020 Identify and mark the four mounting hole locations. Remove the device and drill the holes. Insert the well nuts into the previously drilled holes. Place the device over the well nuts and fasten device to asset.

  • Page 5: Verify The Installation

    ST-1200 Link: https://help.tds.ai/installation-guide/st-1200/ Last Updated: January 14th, 2020 Place the device over the pilot holes and fasten the device to the asset. 4. Verify the installation. Open the web app: Verify GPS on your computer or smartphone, enter the following information and follow the prompts to register the device.
