AXIS SWITCH POSISwitch ® AX 5000 ® for POSIDRIVE MDS 5000 Mounting and Commissioning Guidelines Be sure to read and adhere to this mounting and commissioning instructions before mounting and commissioning! M A N A G E M E N T S Y S T E M certified by DQS according to DIN EN ISO 9001, DIN EN ISO 14001 Reg-No.
POSISwitch ® AX 5000 STÖBER ANTRIEBSTECHNIK 1. Notes on Safety NOTES ON SAFETY Before mounting and commissioning, be sure to read these mounting and commissioning instructions to prevent the occurrence of avoidable problems during commissioning and/or operation. ® ® POSISWITCH AX 5000 of the MDS family is a supplemental module for POSIDRIVE of the MDS family.
POSISwitch ® AX 5000 STÖBER ANTRIEBSTECHNIK 2. Technical Data TECHNICAL DATA Model key POSISwitch ® AX 5000/4 Designation Number of axes 5. Generation Electrical POSISwitch ® Device Type AX 5000/4 General ID no. 44573 Voltage 24 V ±20% (protected against polarity reversal) Current consumption <100 mA (without encoder and contactor)
POSISwitch ® AX 5000 STÖBER ANTRIEBSTECHNIK 3. Mechanical Installation MECHANICAL INSTALLATION This chapter gives you complete information on the subject of mechanical installation. Only specialized personnel qualified for this task may install, commission and control the device. Installation Location • Operate only in closed switching cabinet. •...
POSISwitch ® AX 5000 STÖBER ANTRIEBSTECHNIK 4. Electrical Installation ELECTRICAL INSTALLATION This chapter gives you complete information on the subject of electrical installation. Only specialized personnel qualified for this task may install, commission and control the device. This chapter gives you general information on EMC-suitable installation. These are only recommendations. Depending on the application, the ambient conditions and the legal requirements, measures in addition to the following recommendations may be necessary.
POSISwitch ® AX 5000 STÖBER ANTRIEBSTECHNIK 5. Connection Allocation CONNECTION ALLOCATION This section explains the position, designation and allocation of the terminals. Terminal Overview X500 Connection for the POSIDRIVE ® MDS 5000 Enc. 1 Enc. 2 Connection for Enc. 3 encoders 1 - 4 Enc.
Page 9
POSISwitch ® AX 5000 STÖBER ANTRIEBSTECHNIK 5. Connection Allocation X501 – voltage supply and relays Signal / Function Description Circuiting Voltage supply +24V Powers POSISwitch ® AX 5000 and the motor encoder Reference potential For voltage supply / PIN 1 Protective conductor Connection to housing Power for the relays...
Page 10
POSISwitch ® AX 5000 STÖBER ANTRIEBSTECHNIK 5. Connection Allocation Enc. 1; Enc. 2; Enc 3; Enc. 4 – connection for encoders 1 - 4 Signal / Function Description Circuiting Not connected Reference potential Digital ground Not connected Power supply 5 V Is jumpered internally with pin 12 Differential input / output DATA+...
POSISwitch ® AX 5000 STÖBER ANTRIEBSTECHNIK 6. Configuration CONFIGURATION This chapter describes the configuration of POSISwitch ® AX 5000. The user decides whether POSISwitch ® will be used in the configuration assistants during the step “inverter selection”. An appropriate selection is offered here (see figure). When POSISwitch ®...
