Quick Links
ITEMS INCLUDED
• Frame and Cross Bars
• Hardware Pack
• Paracord
*Model specific strut & bracket kits sold separately
*Note: It is recommended to assemble this product on the floor or a table large enough to properly support it.
STEP 1
Unfold canvas and lay flat on a clean flat surface with
textured side up so the fabric relaxes from shipping.
RedDot
Part #: 26-168 (84")
26-169 (120")
Topsail Installation Instructions
TOOLS NEEDED
• 4mm Allen Key
• #2 Phillips Screwdriver
• Scissors or Cutting Tool
• Side Cut Pliers
Advertisement
Summary of Contents for Reddot 26-168
- Page 1 RedDot Part #: 26-168 (84") 26-169 (120") Topsail Installation Instructions ITEMS INCLUDED TOOLS NEEDED • Frame and Cross Bars • 4mm Allen Key • Hardware Pack • #2 Phillips Screwdriver • Paracord • Scissors or Cutting Tool • Side Cut Pliers *Model specific strut &...
- Page 2 *NOTE: FOR ASSEMBLY OF 120" TOPSAIL, FOLLOW THE SAME STEPS WITH ADDITIONAL RAILS AND CENTER SUPPORTS INCLUDED IN KIT AS SHOWN IN FIG. 2. SEE PAGE 4 FOR COMPLETED RAIL ASSEMBLY.* FRONT STEP 2 FRONT Layout frame rails as shown in Fig. 1. A.
- Page 3 STEP 4 Slide the rear rails onto the tapered joints of the front rails as shown in Fig. 4. For 120" version, insert side rails between the front and rear rails as shown in Fig.5. Fig. 4 Fig. 5 STEP 5 Connect the rear U-shaped rear tube (G) as shown in Fig.
- Page 4 ASSEMBLE THE UNIONS FOR CENTER SUPPORTS STEP 6 Using the provided hardware, assemble the unions to the side rails as shown in Fig. 7. When assembling the unions make sure the notches line up before snugging the screw. See Fig. 8. !Do not tighten until the cross bar is installed! Notch Fig.
- Page 5 Fig. 9b Assembled 84" Top Assembled 120" Top...
- Page 6 ATTACH CANVAS TO FRAME STEP 8 Place the canvas on the top of the frame with the smooth side down and textured side up. See Fig. 10. Use the provided tie straps to temporarily secure the corners and the center as shown (this will make running the cord easier). *Note: Make sure the tie straps are pulled evenly to the center to ensure canvas is tight to frame.
- Page 7 STEP 9 Starting from the center of the rear of the frame, weave paracord through the slots in the canvas around the frame as shown in Fig. 11. Cut off the excess and tie the two ends together. Once the cord is secure, remove the tie straps as shown in Fig. 12. Fig.
-
Page 8: Installation Complete
INSTALLING THE TOPSAIL TO CART *Note: This top is designed to be used with the MadJax/GTW seat kits and struts.* STEP 10 Follow the instructions included in the strut kits, but make sure the rear brackets are placed on top of the rear struts instead of on the bottom as shown in Fig. 13. Bracket on top Rear Bracket for...
