- Page 1 Item No. 554FGRIDL36 OUTDOOR FOLDABLE 36” GRIDDLE User Manual + Retain this manual for future reference. + Unit must be kept clear of combustibles at all times.
-
Page 2: Table Of Contents
2 |User Manual TABLE OF CONTENTS Critical Information ................................3 Warning Statements ................................ 4 Initial Setup ..................................8 Assembly ..................................9 Cleaning ..................................12 Operation ..................................13 Storage Checklist................................14 Maintenance ................................... 14 Troubleshooting ................................15 shopbackyardpro.com... -
Page 3: Critical Information
User Manual | 3 CRITICAL INFORMATION • It is essential not to operate, light, or use this appliance within ten feet (3.05 meters) of walls, structures, or buildings to ensure safety and prevent potential hazards. • Always attend to this appliance while it is in operation to avoid accidents or damage. •... -
Page 4: Safety Warnings
4 |User Manual SAFETY WARNINGS GENERAL SAFETY: • Read the Manual: Thoroughly read and understand the manual before setting up, operating, or cleaning the griddle. • Instruction and Training: Instruct and train users in safe and correct griddle operation to prevent accidents and ensure consistent results. -
Page 5: Operational Safety
User Manual | 5 • No Foreign Objects: Do not insert foreign objects into the cylinder valve to prevent leaks or explosions. • Safe Handling: Do not drop or incorrectly handle cylinders. • Vehicle Transport: Never store cylinders in a hot car or trunk, as pressure can increase and release gas. •... - Page 6 6 |User Manual • Shelf Use: Failure to open side shelves while igniting the griddle’s burners or not waiting 5 minutes after turning the gas on before lighting the griddle may result in an explosive flame-up. • Food Safety: Always use a meat thermometer to ensure food is cooked to a safe temperature. •...
-
Page 7: Maintenance And Cleaning
User Manual | 7 MAINTENANCE AND CLEANING: • Clean and Maintain: Regularly clean and maintain the griddle according to the instructions to ensure safe and hygienic operation. • Leak Checks: Inspect and test for leaks before use, especially if assembled by someone else. Never operate the griddle if a gas leak is present. -
Page 8: Initial Setup
8 |User Manual INITIAL SETUP • WARNING: Improper installation, adjustment, alteration, service, or maintenance can cause injury, property damage, or death. Refer to this manual. For assistance or additional information, consult a qualified professional installer, service agency, or the gas supplier. •... -
Page 9: Assembly
User Manual | 9 ASSEMBLY NO. PARTS LIST NO. PARTS LIST HARDWARE INCLUDED Griddle Surface Control Knob Screw M6x14 Griddle Body Regulator NUT M6 Fireproof Board Left Cart Frame Wing Screw M6x16 Burner Locking Wheel Screw M6x12 Right Side Shelf Lower LP Gas Tank Support Lock Nut M8 Left Side Shelf... -
Page 10: Assembly Tips
10 |User Manual ASSEMBLY TIPS: 1. Choose an Assembly Area: Select a smooth surface free of cracks or openings to protect the components during assembly. 2. Organize Parts: Spread out all parts before beginning assembly. 3. Hand-Tighten Hardware: Initially tighten all hardware connections by hand. Before completing each step, go back and fully tighten all hardware. - Page 11 User Manual | 11 Attach bottom shelf. STEP 3 • Locate the lower shelf and position it between the legs of the frame. • Align the shelf with the attachment points on the lower part of the legs, as shown in the image. •...
-
Page 12: Cleaning
12 |User Manual CLEANING PREPARATION: • Empty the Grease Trap: Before cleaning, ensure the grease trap is empty and any food debris has been removed. • Disconnect the Gas Tank: For safety, always turn off the griddle and disconnect the gas supply before starting the cleaning process to reduce the risk of injury. -
Page 13: Operation
User Manual | 13 OPERATION Connect Tank: Check your tank before turning on the unit and make sure all connections are secure. If unit fails to light, make sure that the tank is sufficiently full. LIGHTING: 1. Use the Match Holder: Insert a lit match into the provided match holder. 2. -
Page 14: Storage Checklist
14 |User Manual STORAGE CHECKLIST • Clean the Griddle: Refer to the “Cleaning” section. • Season the Griddle: Follow the Seasoning Procedure in the “Cleaning” section. • Cool Down: Ensure the griddle is completely cool. • Turn Off: Turn off the griddle. •... -
Page 15: Troubleshooting
User Manual | 15 TROUBLESHOOTING PROBLEM ISSUE REMEDY Make sure the regulator is securely attached to the LP gas tank then turn the LP gas tank valve is closed. LP gas tank valve to the open position. LP gas tank is low or empty. Exchange, refill, or replace the LP gas tank.
