  • Page 1 TS-R/ TSE-R/ TS/STS TSEU-A TSHP TSMP/ TSU/ TSHPU TJP/ TSU-R/ STSMP STSU TJP-U TSEU-R GEBRUIKERSHANDLEIDING Terrier veiligheidsplatenhijsklem OWNER’S MANUAL Terrier safety plate lifting clamp GEBRAUCHSANLEITUNG Terrier Sicherheits-Greifklemme MODE D’EMPLOI Pinces à tôles de sécurité pour plaques Terrier Productcode...

  • Page 2: Table Of Contents

    Additional info for owners of a TJP-U lifting clamp TEMPERATURE TS(U) user manual is valid with the addition of: The TJP-U lifting clamp is specifically de- The operating temperature of the Terrier lifting clamps lies between -40 °C(-40 °F) en 100 °C.

  • Page 3: Safety Precautions

    - Do not use the clamp if damaged; have the clamp repaired by Terrier Lifting Clamps B.V. LIFTING or another recognized mechanical repair and service center. If in doubt consult your sup- plier. - Verify whether the working load limit (W.L.L.) of the clamp is sufficient for the load crea- - Never lift more than one plate at a time.

  • Page 4: Disassembling/Assembling - Ts / Ts-R / Sts / Tse / Tse-R / Tshp

    - Open the clamp to its full extent. - Remove the tension spring (9); in the case of 0,75 TS, 1TS(E), 1,5 TS , 2 & 3 TSE first - Remove the tension spring (9); in the case of the 0,75 TSMP, 1TS(E)MP, 1,5TSMP, 2 & 3 remove the retaining pin in the cam assembly (10).

  • Page 5: Overhauling

    Revise clamp WARRANTY 5 YEAR Terrier Lifting Clamps B.V. provides a 5 year warranty on its lifting clamps. This warranty is applicable to the original end user of the lifting clamps. Only if the clamp has been inspected, checked and maintained by this instructions and by an official dealer. This warranty period of 5 years is valid from the day of purchase, and is liable to all conditions and measurements stated in this document.
  • Page 6 - The injudicious use of the clamp, and not succeeding all indications which are stated in the users manual. - When maintenance and/or revision has not been carried out by an authorised Terrier distributor. The producer is not responsible for incidental damage or damage due to wrong use of the lifting tools as well as from violation of this manual.
  • Page 7 BELASTINGSDIAGRAMMEN VEILIGE WERKLAST LOAD DIAGRAMS (WORKING LOAD LIMITS) LASTAUFNAHMEDIAGRAM (ZULÄSSIGE WINKEL UND TRAGFÄHIGKEITSREDUKTION) DIAGRAMMES: PLAN DE CHARGE max. max. 0° 0° 15° 15° 100% 45° 45° 90° 90° 0° 0° 100% 100% 45° 45° 45° 45° 90° 90° 90° 90°...
  • Page 8 Safety inspections by your own inspector Vom eigenen Sicherheitsbeauftragten durchzuführende Inspektionen Inspections de sécurité à executer par un inspecteur de sécurité interne Onderhoud door een erkend Terrier reparateur Maintenance by a official Terrier distributor Wartung durch einen anerkannten Terrier-Reparaturfachmann Entretien par un réparateur Terrier agree...
  • Page 9 WWW.TERRIERCLAMPS.COM Terrier Lifting Clamps B.V. Find us on Ohmweg 11 4338 PV Middelburg P.O. box 8119 4330 EC Middelburg Nederland youtube/terrier lifting clamps Tel : +31 118 - 65 17 17 Fax : +31 118 - 65 17 18 Email: terrier@terrierclamps.com...
