Uptown Coil Spring Rocker
RXWD-25/156393
Assembly Instructions
Step 1: Remove protective wrapping first. Then lay all parts on floor and identify all parts packed in
carton against attached parts list.
Step 2: Insert threaded tube end of coil spring on both sides of the base through double loop channel
on both sides of the seat bucket(A). Secure attachment with hex nut (C ), spring waster (D ), and
washer (E) to end of threaded tube. Use Hex Wrench (J) to tighten the nut.
Step 3: Make sure all nuts are aligned properly and tightened sufficiently. Then place nut covers over
nuts
NOTE: IT IS USER'S RESPONSIBILITY TO MAKE SURE ALL PARTS ARE ASSEMBLED AND
TIGHTENED PROPERLY AND SECURELY.
Diagram 1
1 of 2
Advertisement
Subscribe to Our Youtube Channel
Summary of Contents for Woodward Uptown Coil Spring Rocker
- Page 1 Uptown Coil Spring Rocker RXWD-25/156393 Assembly Instructions Step 1: Remove protective wrapping first. Then lay all parts on floor and identify all parts packed in carton against attached parts list. Step 2: Insert threaded tube end of coil spring on both sides of the base through double loop channel on both sides of the seat bucket(A).
- Page 2 Diagram 2 PARTS LIST Part Name Part Image Part Name Part Image Seat Bucket Washer Base Nut Cover Hex Nut( M 5/16") Hex Wrench Spring Washer WOODARD Customer Service Hours 8:00am-5:00pm CST Monday to Friday Phone: (800) 877-2290 Fax: (800) 733-4257 PRINTED IN CHINA 2 of 2...
