Malabar PF53481-74P Owner's Manual

5 gallon fluid dispenser
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

MALABAR
AIRCRAFT MAINTENANCE & SUPPORT EQUIPMENT
READ
AND
SAVE
THIS
INSTRUCTION
MANUAL
INTERNATIONAL
OWNER'S MANUAL FOR MALABAR MODEL
PF53481-74P
5 GALLON FLUID DISPENSER
For Service & Spare
Parts, Please Contact:
OVER 65 YEARS OF SERVICE & EXPERIENCE
© 2002 Malabar International. All rights reserved. Permission to reproduce all or part of this material must be obtained from Malabar International.
* GENERAL DESCRIPTION
* OPERATION
* SERVICE
* PARTS BREAKDOWN
Malabar International
220 W. Los Angeles Avenue
Simi Valley, California 93065
Phone: (805) 581-0116
Fax: (805) 584-1624
E-mail: sales@malabar.com
Web site: http://www.malabar.com
Date: May 6, 2013

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PF53481-74P and is the answer not in the manual?

Questions and answers

Related Manuals for Malabar PF53481-74P

Summary of Contents for Malabar PF53481-74P

  • Page 1 Phone: (805) 581-0116 Fax: (805) 584-1624 E-mail: sales@malabar.com Web site: http://www.malabar.com OVER 65 YEARS OF SERVICE & EXPERIENCE © 2002 Malabar International. All rights reserved. Permission to reproduce all or part of this material must be obtained from Malabar International.
  • Page 2 Fluid tank color ---------------------------------------------- red GENERAL DESCRIPTION: The Malabar Model PF53481-74P is a 5 gallon fluid dispenser used to service various commercial aircraft. The hand pump dispenser consists of a reservoir, pump assembly, filter assembly and a fluid delivery hose.

  • Page 3: Operation

    OPERATION: 1. Remove dust plug from hose and connect the hose to the aircraft service point. 2. Use full steady pumping strokes when operating pump assembly during replenishing. 3. Disconnect the hose from the aircraft service point, replace the dust plug and store the unit in a dry, dust free location.
  • Page 4 SIMI VALLEY , CA FIGURE 1B FLUID DISPENSER SWIVEL FEMALE SAE THREAD 9/16-18UNC 37° FLARE (REF) FIGURE 1B PART OF REPAIR PARTS KIT FIGURE 1A PF53481-74P UNIT ASSEMBLY NO. QTY PART NO. PART NAME NO. QTY PART NO. PART NAME PF55836-1 FLUID TANK...

  • Page 5: Unit Assembly

    CG8960-2 MIL-PRF-5606 LANDING GEAR OIL MANUFACTURED BY MALABAR INTERNATIONAL MALABAR INTERNATIONAL SIMI VALLEY, CALIFORNIA CAPACITY MODEL SERIAL NO. CUST. NO. VIEW A-A VIEW B-B FIGURE 1B PF53481-74P UNIT ASSEMBLY NO. QTY PART NO. PART NAME NO. QTY PART NO. PART NAME...
  • Page 6 PART OF REPAIR PARTS KIT FIGURE 1C PF53481-74P UNIT ASSEMBLY NO. QTY PART NO. PART NAME NO. QTY PART NO. PART NAME PF53549 FILLPORT ASSEMBLY 10 329-007 HHCS, 1/4-28 x 21/32 LG PF53628 GASKET, FILLPORT 55925-329 O-RING 717-007 PLUG, 3/8 NPT...

  • Page 7: Pump Assembly

    PART OF REPAIR PARTS KIT FIGURE 2 PF55480-2 PUMP ASSEMBLY NO. QTY PART NO. PART NAME NO. QTY PART NO. PART NAME PF55466 PUMP BODY PF53600 SPRING PF53514 TUBE PF53518 PF53515 PLUNGER ROD 355-021 SELF LOCK NUT, 5/16-24 PF53594 VALVE ASSEMBLY 372-001 COTTER PIN, 3/32 x 3/4 LG PF53599...
  • Page 8 PF5-49PK REPAIR PARTS KIT QTY PART NO. PART NAME PF55456-3 HOSE ASSEMBLY 481-006 FILTER ELEMENT 55925-025 O-RING 55925-329 O-RING PF53602 PUMP GASKET PF53600 SPRING PF53518 355-021 SELF LOCK NUT, 5/16-24 372-001 COTTER PIN, 3/32 DIA x 3/4 LG AN5-12A HHCS, 5/16-24 x 1 11/32 LG 55925-218 O-RING 55925-210...
