Summary of Contents for Vinotemp Brama BR-30SSGG
- Page 1 A P R O U D H E R I T A G E O F E X P E R I E N C E & Q U A L I T Y BRAMA FREESTANDING DUAL FUEL RANGE B R -30SSGG L I Q U E F I E D P E T R O L E U M C O N V E R S I O N...
-
Page 2: Product Registration
Product Registration Completing this product registration is the only way to guarantee you will be notified of substantive issues that arise concerning your product. Become a Member of the Vinotemp Family ® Complete this product registration with your e-mail address and receive special offers and updates on new products via e-mail. - Page 3 Instructions for Converting Range to Operate on Liquefied Petroleum Gas INSTALLATION AND SERVICES MUST BE PERFORMED BY A QUALIFIED INSTALLER IMPORTANT: SAVE INSTRUCTION MANUAL FOR THE LOCAL INSPECTOR’S USE. READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE This conversion kit must be installed by a qualified service technician in accordance with the manufacturer's instructions and all applicable codes and requirements of the authority having jurisdiction.
- Page 4 *Note: For operation at elevations above 2000ft., appliance rating shall be reduced at the rate of 4% for each 1000 ft. above sea level. IMPORTANT: After replacing the natural gas to LP orifices, be sure to keep the original factory installed natural gas orifices for future range conversion back to natural gas. The factory orifices are marked Tools Required for L.P.
- Page 5 Instructions for Converting Range to Operate on Liquefied Petroleum Gas 1. Convert the Pressure Regulator For 30 inch with 16,500BTU Broiler and all 36 inch gas range, please follow the below steps: Pull the range away from the cabinet wall. The gas regulator is located at the bottom right corner of the range.
- Page 6 Instructions for Converting Range to Operate on Liquefied Petroleum Gas 2. Convert Top Burner for LP / Propane Gas Save the natural gas orifices removed from the appliance for possible future conversion to natural gas. You should go accordingly to the following process to covert to Nature gas. Take extra care when handling steel parts.
- Page 7 4. Convert Broil Burner Orifice for 3. Convert Oven Burner Orifice for LP/Propane Gas LP/Propane Gas For all range except the 30 inch with 13,000BTU tube broil, please follow the next steps: Remove the (2) screws on the bottom of Remove back guard and back cover.
- Page 8 Instructions for Converting Range to Operate on Liquefied Petroleum Gas For 30 inch range with 13,000BTU broiler, please follow the converting steps below. 1. Remove the oven door and cooking grid. (See Fig.4a-1 and 4b-1) 2. Unscrew the oven baffle. (See Fig.4c-1) 3.
- Page 9 5. Convert Griddle Orifice for 6. Convert Gas Valves for LP/Propane Gas LP/Propane Gas Remove control knobs, bezel and control (For 36” ranges equipped with 4 top panel (Fig. 6a is for old style knobs and burners and a griddle) requires a 2mm Allen wrench) Remove back guard and back cover (See Using a flat screwdriver, replace main...
- Page 10 Instructions for Converting Range to Operate on Liquefied Petroleum Gas 7. Reconnect Gas and Electrical Supply 8. Air Shutter Oven Burner to Range The air shutter for the oven burner may need Leak testing of the appliance shall be adjustment, especially if the unit has been conducted according to the installation converted for use with LP/Propane gas.
- Page 11 7 3 2 S o u t h R a c e t r a c k R o a d , H e n d e r s o n , N e v a d a 8 9 0 1 5 i n f o @ v i n o t e m p .
-
Page 12: Terms And Conditions
Vinotemp. Any unauthorized defective return to Vinotemp will be rejected at the time of attempted delivery. Return freight costs for defective product is covered by Vinotemp within the first 90 days from date of sale. For defective Return Authorizations issued after the 90th day from date of sale, the purchaser assumes responsibility for any related freight costs within the product warranty term. - Page 13 If you use a service repair company without approval or parts not supplied by Vinotemp and your unit under warranty fails to work, we will repair your item provided you ship your unit prepaid to and from our facility in Henderson.
- Page 14 Composite wood: May contain formaldehyde. Galvanized metal and some of its constituents contain lead and/or other substances that are known to the State of California to cause cancer, birth defects and other reproductive harm. Products made of vinyl contain lead, Diethyl Hexyl Phthalate (DEHP), and/or other substances that are known to the State of California to cause cancer, birth defects and other reproductive harm.
- Page 15 card companies charge at the time of the chargeback. Cancelled orders using a Credit Card will have an additional fee of 3% deducted from the refund. Any disputes not resolved within 30 days from the invoice date will be reported to credit reporting agencies.
- Page 16 30 day period once they have been notified by Vinotemp through phone call, email, or letter that their unit is ready for pick up. If the item remains in the Vinotemp warehouse after 30 days but no longer than 60 days, the Purchaser will incur additional storage fees of 2%. After 60 days in storage, the item will become property of Vinotemp.
- Page 17 (“Purchaser”) hereby fully aggress to the following terms and conditions of the sale: 1. Freight: Vinotemp is not a freight, moving or installation company, if Freight is arranged for the Buyer, the Seller assumes no responsibility for the goods sold to the Purchaser once the goods have left the Seller’s premises, including, but not limited to, late delivery by the moving carrier, or for...
- Page 18 Unfinished wood is subject to warping; all wood surfaces must be sealed before placing cellar into service. Improper placement of the unit will void the warranty. By Vinotemp in writing, any 3rd party repair facility must be pre-approved before providing parts free of charge.
- Page 19 7. Purchaser understands and acknowledges that the goods sold here are wine coolers, appliances, cigar humidors, and/or other similar units which may house wine or cigars or other consumables. Purchaser assumes all risk of using these units, including risk of spoilage, humidity variations, temperature variations, leaks, fire, water damage, mold, mildew, dryness and similar perils that might occur.
-
Page 20: Service & Important Notice
Please do not place the unit within reach of children. For adult use only Vinotemp is a registered trademark of Vinotemp International. All products, features, and services are subject to change without notice. We cannot guarantee the accuracy of the contents of this document. We disclaim liability for errors, omissions, or future changes.
