ercol
pimlico beds
10PIM 4000/10PIM 5000 double/kingsize beds
Thank you for purchasing this pimlico bed Please read the instructions carefully before use to ensure safe
and satisfactory operation of this product.
This item is HEAVY
Necessary Tools
Pre-assembly preparation
Please ensure instructions are read in full before attempting to assemble this product
Please check the pack contents before attempting to assemble this product. A full checklist of components
is given in this leaflet. If any components are missing, please contact the retailer from whom you bought
this product.
This product is HEAVY, it should be assembled as near as possible to the point of use. TAKE CARE
WHEN LIFTING to avoid personal injury and (or) damage to the product.
This product takes approximately 20 MINUTES to assemble with 2 PEOPLE.
The fittings pack contains SMALL ITEMS which should be KEPT AWAY FROM YOUNG
CHILDREN.
Advertisement
Related Manuals for feather & black pimlico bed 10PIM 4000
Summary of Contents for feather & black pimlico bed 10PIM 4000
- Page 1 ercol pimlico beds 10PIM 4000/10PIM 5000 double/kingsize beds Thank you for purchasing this pimlico bed Please read the instructions carefully before use to ensure safe and satisfactory operation of this product. This item is HEAVY Necessary Tools Pre-assembly preparation Please ensure instructions are read in full before attempting to assemble this product Please check the pack contents before attempting to assemble this product.
- Page 2 Fittings and parts checklist Headboard x 1 Spanner x 1 Footboard x 1 Central brackets x 2 Side rails x 2 allen key bolts x 2 Centre rail x 1 Nuts x 2 Slats double bed x 32 Screws x 12 Slats king size x 34 Ends for slats double x 64 Allen key x 1...
- Page 3 Step by step assembly instructions Step One 1. Push the 8 threads into the headboard and the footboard as shown below. Tighten the threads by hand ensuring that there is approximately half of the threads still showing. 2. Using the 12 x 20mm screws, attach the two brackets into the headboard and the footboard using the pre-drilled holes, tighten with a phillips screwdriver.
- Page 4 4. Making sure the holes in the centre rail are facing upwards, put the centre rail into the two brackets. Secure it in place using the 2 x 40mm bolts, and the 2 small nuts. 5. Push a plastic cap onto each end of a slat and with the peg facing downwards push the slat into the pre drilled holes as shown below.
-
