Custom Dynamics ProGLOW PG-BTBOX-1 Installation Instructions

We thank you for purchasing the Custom Dynamics® ProGLOW™ Bluetooth Controller. Our products utilize
the latest technology and high quality components to ensure you the most reliable service. We offer one of the
best warranty programs in the industry and we back our products with excellent customer support, if you have
questions before or during installation of this product please call Custom Dynamics® at 1(800) 382-1388.
Part Numbers:
PG-BTBOX-1
Package Contents:
- ProGLOW™ Controller (1)
- Power Harness with Switch (1)
- 3M Tape (5)
- Isopropyl Alcohol Wipe (1)
Fits: Universal, 12VDC systems.
PG-BTBOX-1: ProGLOW™ 5v Bluetooth Controller
works with ProGLOW™ Color Changing LED Accent
Light Accessories only.
ATTENTION
Please read all Information below before Installation
Warning: Disconnect negative battery cable from battery; refer to owner's
manual. Failure to do so may result in electrical shock, injury, or fire. Secure
negative battery cable away from positive side of battery and all other posi-
tive voltage sources on vehicle.
Safety First: Always wear appropriate safety gear including safety glasses
when performing any electrical work. It is highly recommended that safety
glasses be worn throughout this installation process. Be sure vehicle is on
level surface, secure and cool.
Important: Controller should only be used with Custom Dynamics®
ProGLOW™ LED accent lights. This device and the LEDs used with it are
not compatible with other manufacture's products.
Important: This unit is rated for a 3 amp load. Never use a fuse greater
than 3 amps in the in-line fuse holder, using a larger fuse or bypassing the
fuse will void warranty.
Important: Maximum LEDs per channel is 150 in series connection, not to
exceed 3 amps.
Note: Controller App is Compatible with iPhone 5 (IOS10.0) and newer
equipped with Bluetooth 4.0 and with Android Phones Versions 4.2 and
newer with Bluetooth 4.0. Apps available for download from the following
sources:
- Google Play: https://play.google.com/store/apps
- iTunes: https://itunes.apple.com/
Keyword Search: ProGLOW™
Important: Controller should be secured after installation in an area away
from heat, water, and any moving parts. We recommend the use of tie
wraps (sold separately) to secure wires from becoming cut, frayed, or
pinched. Custom Dynamics® is not liable for damage as a result of improp-
erly securing or failing to secure the controller.
Questions? Call us at: 1 (800) 382-1388
Custom Dynamics® ProGLOW™
Bluetooth Controller
Installation Instructions
Installation:
1. Connect the Red battery terminal of the Bluetooth Controller Pow-
er Harness and the Blue Battery Monitor wire from the controller to
the Positive terminal of the battery. Connect the Black battery ter-
minal of the Bluetooth Controller Power Harness to the Negative
battery terminal.
2. Check the switch on the Power Harness to confirm it is not illumi-
nated. If the switch on the Power Harness is illuminated, press the
switch button so the switch is not illuminated.
3. Plug the power harness into the ProGLOW™ Bluetooth Controller
power port.
4. (Optional Step) Connect the Black Brake Monitor wire on the Blue-
tooth Controller to the vehicle brake circuit to enable brake alert
mode. If not used, cap wire to prevent shorting. (Lights will change
to Solid Red when brake is engaged, then return to normal pro-
gram function when released.)
5. Refer to the diagram on Page 4 and Connect your ProGLOW™
LED accessories (Sold Separately) to the controller Channel ports
1-3.
6. Mount the ON/OFF switch on the Power Harness in a discrete
accessible location using the provided 3M tape. Clean the mount-
ing area and switch with the provided Isopropyl Alcohol Wipe and
allow to dry before applying the 3M tape.
7. Use the provided 3M tape to secure the ProGLOW™ Bluetooth
Controller in an area away from heat, water, and any moving
parts. Clean the mounting area and controller with the provided
Isopropyl Alcohol Wipe and allow to dry before applying the 3m
Tape.
8. Press the switch on the Power Harness, the LED Accessories
should now be illuminated and color cycling.
9. Download the ProGLOW™ Bluetooth App from either the Google
Play Store or the iPhone App Store depending on your smart
phone device.
