Micromeritics MICRO-CIRRUS 3 Installation Instructions Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
M
-C
3 I
ICRO
IRRUS
NTERFACE
I
I
NSTALLATION
NSTRUCTIONS
004-42805-00
Oct 2022
(Rev A)

Advertisement

loading
Need help?

Need help?

Do you have a question about the MICRO-CIRRUS 3 and is the answer not in the manual?

Questions and answers

Summary of Contents for Micromeritics MICRO-CIRRUS 3

  • Page 1 ICRO IRRUS NTERFACE NSTALLATION NSTRUCTIONS 004-42805-00 Oct 2022 (Rev A)
  • Page 2 Copyright The software described in this manual is furnished under a license agreement and may be used or copied only in accordance with the terms of the agreement. ____________________________________________________________________________ Copyright © 2019 - 2022. Micromeritics Instrument Corporation. All rights reserved.
  • Page 3 The company has R&D and manufacturing sites in the USA, UK, and Spain, and direct sales and service operations throughout the Americas, Europe, and Asia. Micromeritics systems are the instruments-of-choice in more than 10,000 laboratories of the world’s most innovative companies and prestigious government and academic institutions.
  • Page 4 Norcross, GA / USA / 30093-2901 Phone: 1-770-662-3636 Fax: 1-770-662-3696 www.Micromeritics.com Instrument Service or Repair Phone: 1-770-662-3666 International: Contact your local distributor or call 1-770-662-3666 Service.Helpdesk@Micromeritics.com Micromeritics Application Support Support@Micromeritics.com Micro-Cirrus 3 Interface Installation Instructions 004-42805-00 (Rev A) — Oct 2022...
  • Page 5 CAUTION — Cautions contain information to help prevent actions that may damage the analyzer or components. WARNING — Warnings contain information to help prevent actions that may cause personal injury. Micro-Cirrus 3 Interface Installation Instructions 004-42805-00 (Rev A) — Oct 2022...
  • Page 6 General Safety ENERAL AFETY Do not modify this instrument without the authorization of Micromeritics Service Per- sonnel. Any piece of laboratory equipment can become dangerous to personnel when improperly operated or poorly maintained. All employees operating and maintaining Micromeritics instruments should be familiar with its operation and should be thoroughly trained and instructed on safety.
  • Page 7 Read the Material Safety Data Sheet (MSDS) and be aware of the hazards of mercury and know what to do in the event of a spill or an exposure incident Micro-Cirrus 3 Interface Installation Instructions 004-42805-00 (Rev A) — Oct 2022...
  • Page 8 6 Software Installation and Operation Preparation 6 - 1 Micromeritics Custom Recipe Installation 6 - 2 Set Up and Prepare for Operation 6 - 6 Bake the System 6 - 7 Micro-Cirrus 3 Interface Installation Instructions viii 004-42805-00 (Rev A) — Oct 2022...
  • Page 9 Calibrate detectors Scale the Micromeritics analyzer sample thermocouple signal Refer to the Micro-Cirrus 3 Interface User Guide [part number 004-42804-00] for details on operating the interface software. If connecting the Micromeritics Breakthrough Analyzer or an FR-series to the MKS Cirrus 3, refer to the user guide that shipped with the analyzer.
  • Page 10 ETWORK ONNECTION Micromeritics analyzers and MKS Cirrus 3 require separate Ethernet connections to a computer. An Ethernet switch can be used to connect both instruments to one Ethernet port on the computer, however, they must both be on the same subnet.
  • Page 11 2. Remove the 1/16 in. plug from the analyzer. A. 1/16 in. plug 3. Insert the ferrule into the opening where the 1/16 in. plug was removed. Micro-Cirrus 3 Interface Installation Instructions 2 - 1 004-42805-00 (Rev A) — Oct 2022...
  • Page 12 Slide reducing union onto the tip of the capillary tube 6. Use a 9/16 in. wrench to tighten the nut on the reducing union. Micro-Cirrus 3 Interface Installation Instructions 2 - 2 004-42805-00 (Rev A) — Oct 2022...
  • Page 13 1. Disconnect the 9-pin connector from the Valve/Fan port on the front of the analyzer. 2. Connect and tighten the 9-pin female connector on the interface cable to the 9-pin male con- nector disconnected in the previous step. Micro-Cirrus 3 Interface Installation Instructions 2 - 3 004-42805-00 (Rev A) — Oct 2022...
  • Page 14 6. Plug one end of the power cord into the connector on the rear panel of the mass spec- trometer and the other end into an appropriate power source. See the MKS Cirrus hardware manual for electrical specifications. Micro-Cirrus 3 Interface Installation Instructions 2 - 4 004-42805-00 (Rev A) — Oct 2022...
  • Page 15 3/8 in. open-end wrench 5/16 in. open-end wrench 7/16 in. open-end wrench 9/16 in. open-end wrench The mass spectrometer connector is located on the side panel of the analyzer. Micro-Cirrus 3 Interface Installation Instructions 3 - 1 004-42805-00 (Rev A) — Oct 2022...
  • Page 16 B. TCD assembly C. Cold trap rotary valve 1. Remove the rear panel and the entire top panel of the analyzer to allow full access to the plumbing. Micro-Cirrus 3 Interface Installation Instructions 3 - 2 004-42805-00 (Rev A) — Oct 2022...
  • Page 17 C. Hexagonal fitting 5. Remove the two tubes that enter the ends of the TEE block. Remove the plug from the side of the TEE block. Micro-Cirrus 3 Interface Installation Instructions 3 - 3 004-42805-00 (Rev A) — Oct 2022...
  • Page 18 A. Remove two screws holding TEE block B. Remove two screws and remove cover plate 7. Remove the screw from the grooved channel. Remove the screw shown in the red circle. Micro-Cirrus 3 Interface Installation Instructions 3 - 4 004-42805-00 (Rev A) — Oct 2022...
  • Page 19 × 31 in. long] from the right side of the TEE to the hexagonal fitting located above the exhaust ports where the 1/8 in. tube was removed. A 1/8 in. to 1/16 in. reducing union is required. Micro-Cirrus 3 Interface Installation Instructions 3 - 5 004-42805-00 (Rev A) — Oct 2022...
  • Page 20 The insulation rings may be used to prevent damage to the capillary hose insulation. 15. Re-attach the side panel cover plate, with the capillary hose passing through into the heated zone. Micro-Cirrus 3 Interface Installation Instructions 3 - 6 004-42805-00 (Rev A) — Oct 2022...
  • Page 21 The tube must be bent so that the metal connectors of the capillary hose are inside the heated zone. The plumbing should now resemble the following photos: Micro-Cirrus 3 Interface Installation Instructions 3 - 7 004-42805-00 (Rev A) — Oct 2022...
  • Page 22 Connect AutoChem 2920 and 2950 Cables to the Mass Spectrometer on page 3 - 21 for instructions on connecting the cables from the mass spectrometer to the analyzer. Micro-Cirrus 3 Interface Installation Instructions 3 - 8 004-42805-00 (Rev A) — Oct 2022...
  • Page 23 20 °C. Removing the cover and insulation at the zone will speed the cool- ing process. 1. Open the top panel of the analyzer to allow access to the plumbing. Micro-Cirrus 3 Interface Installation Instructions 3 - 9 004-42805-00 (Rev A) — Oct 2022...
  • Page 24 If the tube is too long, either coil or zig-zag the tube to use the excess length. With the covers and insulation removed, the mass spectrometer TEE connection block may be accessed. Micro-Cirrus 3 Interface Installation Instructions 3 - 10 004-42805-00 (Rev A) — Oct 2022...
  • Page 25 The insulation rings may be used to prevent damage to the capillary hose insulation. 6. Re-attach the side panel cover plate, with the capillary hose passing through into the heated zone. Micro-Cirrus 3 Interface Installation Instructions 3 - 11 004-42805-00 (Rev A) — Oct 2022...
  • Page 26 The tube must be bent so that the metal connectors of the capillary hose are inside the heated zone. The plumbing should now resemble the following photos: Micro-Cirrus 3 Interface Installation Instructions 3 - 12 004-42805-00 (Rev A) — Oct 2022...
  • Page 27 Micro-Cirrus 3 Interface Installation Instructions 3 - 13 004-42805-00 (Rev A) — Oct 2022...
  • Page 28 The mass spectrometer connector is located on the side panel of the analyzer. A. Side panel cover plate B. Hard plastic center cap 1. Remove the top cover panel and the upper rear panel of the analyzer. Micro-Cirrus 3 Interface Installation Instructions 3 - 14 004-42805-00 (Rev A) — Oct 2022...
  • Page 29 4. Remove the side panel cover plate. Discard the insulation rings and the cover plate. Save the screws for later. A. Insulation B. Cover plate screw C. Cover plate 5. Remove the plug from the mass spectrometer TEE block. Micro-Cirrus 3 Interface Installation Instructions 3 - 15 004-42805-00 (Rev A) — Oct 2022...
  • Page 30 Secure with the locking nut [part number 004-28205-00, nylon locking nut, 6-32]. Do not tighten the nut completely. 8. Attach the new port plate to the analyzer using the screws saved from an earlier step. Micro-Cirrus 3 Interface Installation Instructions 3 - 16 004-42805-00 (Rev A) — Oct 2022...
  • Page 31 12. Insert the 1/4 in. tube at the end of the mass spectrometer hose into the reducing union. 13. Use a 9/16 in. wrench to tighten the nut on the reducing union. 14. Re-install the rear panel and the analyzer top panel. Micro-Cirrus 3 Interface Installation Instructions 3 - 17 004-42805-00 (Rev A) — Oct 2022...
  • Page 32 All other pins in the 15-pin connector are floating (not connected). Connect the metal shell of the connector to the chassis ground and cable shield to maintain shielding of the signals. Micro-Cirrus 3 Interface Installation Instructions 3 - 18 004-42805-00 (Rev A) — Oct 2022...
  • Page 33 Maximum reverse voltage = 3 VDC Nominal forward voltage = 1.3 VDC at 10 mA Minimum current required to be recognized by the 2950 analyzer = 1 mA Micro-Cirrus 3 Interface Installation Instructions 3 - 19 004-42805-00 (Rev A) — Oct 2022...
  • Page 34 Opto output 4 collector Opto output 4 emitter Opto input 1 anode (+) Opto input 1 cathode (-) Opto input 2 anode (+) Opto input 2 cathode (-) Micro-Cirrus 3 Interface Installation Instructions 3 - 20 004-42805-00 (Rev A) — Oct 2022...
  • Page 35 4. On the side panel of the AutoChem, attach the 15-pin and 25-pin connectors labeled AutoChem to their appropriate connections. Tighten the retaining screws. AutoChem 2920 and AutoChem 2950 side panel Micro-Cirrus 3 Interface Installation Instructions 3 - 21 004-42805-00 (Rev A) — Oct 2022...
  • Page 36 4. Loosen the knurled thumb screws to open the black plastic clamps. Open the clamps and remove the hard plastic center cap covering the Mass Spec port. Keep the clamps open at this time. A. Knurled thumb screws B. Plastic cap Micro-Cirrus 3 Interface Installation Instructions 3 - 22 004-42805-00 (Rev A) — Oct 2022...
  • Page 37 AutoChem III A. Knurled thumb screws B. Plastic cap 5. Remove the detector block cover by pulling the plungers out and lifting the cover. Micro-Cirrus 3 Interface Installation Instructions 3 - 23 004-42805-00 (Rev A) — Oct 2022...
  • Page 38 3 AutoChem 6. .Carefully remove the insulation. 7. Use a 1/4 in. wrench to remove the 1/16 in. stainless steel plug. Micro-Cirrus 3 Interface Installation Instructions 3 - 24 004-42805-00 (Rev A) — Oct 2022...
  • Page 39 A. Connect the 1/16 in. stainless steel tube to the mass spec hose. B. Connect the other end where the plug was removed. Micro-Cirrus 3 Interface Installation Instructions 3 - 25 004-42805-00 (Rev A) — Oct 2022...
  • Page 40 10. Replace the foam insulation and detector block cover. Ensure there is no gap between the foam and the mass spec hose. 11. Close the AutoChem III top cover. Micro-Cirrus 3 Interface Installation Instructions 3 - 26 004-42805-00 (Rev A) — Oct 2022...
  • Page 41 2. Connect the mass spectrometer hose to the mass spectrometer connector port on the back of the analyzer using ferrules and a 9/16 in. nut to secure the connection. Micro-Cirrus 3 Interface Installation Instructions 4 - 1 004-42805-00 (Rev A) — Oct 2022...
  • Page 42 Tighten the retaining screws. 3. On the rear panel of the analyzer, attach the 25-pin connector of the straight-thru cable to its appropriate connection. Tighten the retaining screws. Micro-Cirrus 3 Interface Installation Instructions 4 - 2 004-42805-00 (Rev A) — Oct 2022...
  • Page 43 1. Slide the mass spectrometer support bracket onto the bulkhead port on the left side of the analyzer. Bulkhead port with mass spectrometer support bracket 2. Secure the bracket to the port using the jam nut from the adapter kit. Micro-Cirrus 3 Interface Installation Instructions 5 - 1 004-42805-00 (Rev A) — Oct 2022...
  • Page 44 4. Insert the mass spectrometer tubing into the bulkhead port and secure the tubing by tightening the Swaging nut. A. Swaging nut assembly B. Mass spectrometer tubing Micro-Cirrus 3 Interface Installation Instructions 5 - 2 004-42805-00 (Rev A) — Oct 2022...
  • Page 45 Slide the reducing unit 1/4 in. nut onto the tip of the mass spectrometer capillary tube. Slide reducing union onto the tip of the capillary tube Micro-Cirrus 3 Interface Installation Instructions 5 - 3 004-42805-00 (Rev A) — Oct 2022...
  • Page 46 6. Insert the end of the capillary tube with the nut onto the end of the metal mass spectrometer tubing previously installed. 7. Tighten the reducing union so that it is secure on the metal mass spectrometer tubing. Micro-Cirrus 3 Interface Installation Instructions 5 - 4 004-42805-00 (Rev A) — Oct 2022...
  • Page 47 8. Use your hands to gently bend mass spectrometer tubing assembly into the slots of the sup- port bracket. Secure the assembly between the insulator and the mass spec tubing. Micro-Cirrus 3 Interface Installation Instructions 5 - 5 004-42805-00 (Rev A) — Oct 2022...
  • Page 48 2. Connect the 25 pin connector of the trigger cable to the Digital I/O port on the rear panel of the MKS Cirrus 3 [part number P07-60802-00 in the accessory kit]. Micro-Cirrus 3 Interface Installation Instructions 5 - 6 004-42805-00 (Rev A) — Oct 2022...
  • Page 49 MKS User Manuals disk. After installation of the Process Eye Professional software, a Micromeritics Custom Recipe user setup utility is used for installation of the Micromeritics disk Custom Recipe disk. Micro-Cirrus 3 Interface Installation Instructions 6 - 1 004-42805-00 (Rev A) —...
  • Page 50 USTOM ECIPE NSTALLATION 1. Insert the Micromeritics Custom Recipe installation media into the media drive. 2. Go to Start > All Programs > MKS RGA Applications > Tools > User Setup. 3. The Setup Wizard displays. Click Next. 4. On the Install Recipes window, click Have Disk.
  • Page 51 Next. 9. Verify the Setup Wizard has enough information to complete the installation, then click Finish. 10. On the Recipe Installation History window, click Close. Micro-Cirrus 3 Interface Installation Instructions 6 - 3 004-42805-00 (Rev A) — Oct 2022...
  • Page 52 12. On the RGA Device Manager window, locate your unit. Right-click and select Access. 13. On the Instrument Access window, click to complete installation. 14. Go to Start > All Programs > MKS RGA Applications > Process Eye Professional. Micro-Cirrus 3 Interface Installation Instructions 6 - 4 004-42805-00 (Rev A) — Oct 2022...
  • Page 53 F5 to display the Recipe Control menu. To install from the Windows Explorer display, minimize the Process Eye Professional window, then navigate to C:\Micromeritics\MKS\Microsoft Silverlight. After installation is complete, maximize the Process Eye Professional window and press F5 to display the Recipe Control menu.
  • Page 54 Whether or not the capillary needs to be heated depends on the application and the nature of the gases being sampled. The MKS Cirrus 3 is designed to allow the capillary heater to be run continuously. Micro-Cirrus 3 Interface Installation Instructions 6 - 6 004-42805-00 (Rev A) — Oct 2022...
  • Page 55 The MKS-Cirrus 3 is designed to allow continuous operation with the system heater set to Warm. Refer to the MKS Cirrus hardware manual for additional information on the Warm/Bake option. Micro-Cirrus 3 Interface Installation Instructions 6 - 7 004-42805-00 (Rev A) — Oct 2022...
