P&C GLIDE-36-REC-2 Quick Start Manual

GLIDE-36-REC-2
36" Built-In Glide-Out Range Hood
General Properties
• Slide-Out Hood - Powder Coating Dark Gray
• Reciruclating Mode
• Stainless Steel Handle (Can be replaced with
matching cabinetry)
• Rocker Switch – Light Switch on Right Side,
Fan Switch on Left Side
• 2 x Rectangle LED Lights with Smog Cover -
Color Temp: 3,200K
• 2 x Honeycomb Filters
Features
• 2 x Speed Adjustment
• AC Capacitor Motor
• Motor Power: 130 W
• Total Power: 132 W
• 300 CFM / 65 dBa
Handle Replacement Dimensions
• Width: 35 (898mm)
3/8"
• Height: 3 (80mm)
1/8"
Notes: Porter & Charles reserves the absolute and unrestricted right to change product materials and specifications, at any time, without notice.
Warranties: Please see the Use & Care manual or Porter & Charles website for a statement of limited warranty. For more information on our entire line of products, go to www.
porterandcharles.ca or call 905.829.3980
© Porter & Charles. All rights reserved.
Signature Features
Glide Out Hood
The glide out hood extends during use, and neatly tucks
away when not needed.
Two Speed Adjustments
Provides power level options to suit your cooking style.
LED Lighting Strip
LED lights illuminate the cooktop, increase visibility, and are
more energy efficient.
Technical Specifications
Product Dimensions (W/H/D)
• 35 / 8 / 11
3/8" 5/16" 1/16"
• 898mm / 211mm / 281mm
Cut Out Dimensions (W/H/D)
• min. 35 max. 36"/ 8
7/16" - 5/16"
• min. 900-max. 914mm / 211mm / 305mm
Weight
• Net Weight – TBA
• Gross Weight – TBA
Electrical Requirements
• 120 V / 60 Hz
• Supplied with a Canadian plug and 1m long cord.
/ min. 12"
