- Page 1 User Guide Legion Pro 7i (16″,10)
- Page 2 • Setup Guide First Edition (February 2025) © Copyright Lenovo 2025. LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-...
-
Page 3: Table Of Contents
Windows Update ... . Call Lenovo ....Windows recovery options.. - Page 4 Appendix A. Notices and trademarks ....39 User Guide...
-
Page 5: About This Guide
About this guide • This guide applies to Lenovo product model(s) listed below. Illustrations in this guide may look slightly different from your product model. Model name Machine type (MT) – Legion Pro 7 16IAX10H 83F5 – Lenovo Legion Pro 7 16IAX10H •... - Page 6 User Guide...
-
Page 7: Chapter 1. Meet Your Computer
Chapter 1. Meet your computer Front view Figure 1. Legion Pro 7 16IAX10H—front view Description Microphones Camera Camera light Screen Microphones The microphones are the PC's built-in sound input devices. They capture your voice and ambient sound and convert them into digital form. Microphones are essential components when you use your PC for video conferencing or voice recording. -
Page 8: Screen
Table 1. Camera light status and description Camera light status Description The camera is activated. The camera is not activated. Screen The screen of the built-in display is where text, graphics, and videos are displayed. User Guide... -
Page 9: Top View
Top view Figure 2. Legion Pro 7 16IAX10H—top view Description Speakers Antennas (cannot be seen from the outside) Power button and power light Touchpad Keyboard Speakers The speakers are the PC's built-in sound output devices. Antennas The antennas transmit and receive radio waves to allow data to be transferred between your PC and a Wi-Fi network device or a Bluetooth device. -
Page 10: Touchpad
The touchpad also supports Windows multi-finger gestures, which provide shortcuts to frequently used apps and functions. Keyboard The keyboard is the primary input device for a PC, designed for typing characters. A Lenovo keyboard also includes shortcut keys that enhance productivity when interacting with the PC, applications, and the Windows operating system. -
Page 11: Left View
Left view Figure 3. Legion Pro 7 16IAX10H—left view Description Charging light Power connector HDMI connector ® Multi-purpose USB Type-C connector USB Standard-A connector (always-on) Charging light The charging light indicates whether the PC is plugged into an electrical outlet. When the PC is plugged into an electrical outlet, the color of the light indicates whether the battery is fully charged (or will shortly be fully charged). -
Page 12: Hdmi Connector
USB device connected to this type of connector even when the PC is powered off, in sleep mode, or in hibernation mode. The always-on function can be turned on and off in: • The PC's firmware setup utility, or • Lenovo Vantage User Guide... -
Page 13: Right View
Right view Figure 4. Legion Pro 7 16IAX10H—right view Description Combo audio jack USB Standard-A connector Camera switch Ethernet connector Combo audio jack The combo audio jack is used to connect single-plug headsets, headphones, or external speakers. USB Standard-A connector The USB Standard-A connector is used to connect storage or peripheral devices that follow the universal serial bus (USB) specification for data transfer and device interconnection. -
Page 14: Rear View
Rear view Figure 5. Legion Pro 7 16IAX10H—rear view Description Air vents (outlet) Air vents (outlet) The air vents allow hot air to be discharged out of the PC. Important: When the PC is operating, do not place it on a bed, sofa, carpet, or other flexible surfaces. -
Page 15: Bottom View
Bottom view Figure 6. Legion Pro 7 16IAX10H—bottom view Description Air vents (intake) Speakers Air vents (intake) The air vents allow air to be sucked inside of the PC to cool the internal components. Important: When the PC is operating, do not place it on a bed, sofa, carpet, or other flexible surfaces. -
Page 16: Features And Specifications
Features and specifications Dimensions Width 364.4 mm Depth 275.9 mm Thickness • 21.9 mm (thinnest part) • 26.7 mm (thickest part) ac power adapter Input 100 V ac–240 V ac, 50 Hz–60 Hz 20 V Output voltage Maximum output current 20 A Maximum output power 400 W... - Page 17 Display 16.0 inches Screen size (diagonal) Resolution 2560 × 1600 Supported refresh rates • 60 Hz and 165 Hz • 60 Hz and 240 Hz Connectors and slots USB Standard-A connector • Quantity: 3 • Maximum power output: 5 V, 0.9 A* •...
-
Page 18: Statement On Usb Transfer Rate
The actual maximum output resolution is dependent on the connected display device and the cable being used. Networking Ethernet 2.5 Gbps ® Wi-Fi Wi-Fi 7 Note: Different Wi-Fi standards may operate on different frequency bands. In some countries or regions, certain frequency bands may be prohibited for unlicensed use or may require specific conditions. - Page 19 over 10 seconds at a time. As such, it is recommended that users avoid prolonged direct contact with the bottom of the computer. Chapter 1 Meet your computer...
- Page 20 User Guide...
-
Page 21: Chapter 2. Explore Your Computer
Reset your PC while keeping your personal files. functioning properly for some time. Your PC won't start. Utilize Windows startup repair function. Your PC won't start and Use a recovery drive to restore Windows. cannot be repaired using Windows startup repair function. © Copyright Lenovo 2025... -
Page 22: Use Power Efficiently
Reset Windows Resetting Windows allows you to reinstall the operating system while retaining your personal files. This gives the operating system a fresh start and, in some cases, restores the PC's original performance. Select Settings ➙ System ➙ Recovery. Step 1. Step 2. -
Page 23: Rechargeable Battery Pack
You can charge the battery any time you want. The battery packs of Lenovo computers support multiple charging modes that are suitable for different power usage habits. You can switch the battery’s active charging mode in Lenovo Vantage or Lenovo PC Manager. -
Page 24: Using A Power Delivery Compliant Usb Type-C Charger With The Computer
If the battery pack of your computer supports overnight battery charging mode, it can be enabled in Lenovo Vantage or Lenovo PC Manager. -
Page 25: Set Power Button Behavior
Note: To wake the PC from sleep mode, press the power button or any key on the keyboard. System operation modes Lenovo has preset several modes in which your computer can operate. The maximum attainable performance, power consumption, and speed limit for the heat sink fan vary between the operation modes. -
Page 26: Connect To A Network
Plug the other end of the Ethernet cable into a network wall jack or a router. Note: If your computer does not include an Ethernet connector, you can purchase a USB-C to Ethernet adapter from Lenovo at https://www.lenovo.com/accessories User Guide... -
Page 27: Interact With Your Computer
Interact with your computer Shortcut keys A Lenovo keyboard usually includes the following shortcut keys that you can use to quickly access apps or adjust settings. • Functions keys (F1–F12) • Hotkeys • Combination keys using the fn key • Combination keys using the Windows logo key •... - Page 28 Figure 7. Locations of the fn lock key and the fn key A Lenovo keyboard usually contains hotkeys in the top row. These hotkeys share keys with the function keys (F1–F12) and other keys. For these dual-function keys, the characters denoting the primary functions are printed on top of the icons and the icons denoting the secondary functions.
- Page 29 Table 10. fn lock and dual-function keys fn lock fn lock Pressing the hotkey alone Pressing the hotkey while holding down (Esc) status the fn key Disabled Primary function Secondary function Enabled Secondary function Primary function Combination keys using the fn key The fn key can be used in combination with specific keys to adjust device settings or activate additional functions.
-
Page 30: Connect To An External Display
Takes a full-screen screenshot and saves it to a file The Copilot key The era of AI has arrived, and many Lenovo PCs now include a Copilot key on the keyboard. It is located either in the bottom or the top row of the keyboard and is marked with For Windows PCs with Copilot in Windows available and enabled, pressing the Copilot key opens Copilot in Windows. -
Page 31: Turn On Night Light
The displays of some Lenovo computers support dual refresh rates. For such a computer, you can manually switch its display to work at either the higher or lower refresh rate. For Windows operation systems, the manual settings are usually found in Settings ➙... -
Page 32: Touchpad Gestures
Touchpad gestures The touchpad is your PC's built-in pointing device. You can tap and swipe on the touchpad to navigate within the operating system and within apps. In addition, the Windows operating system also supports multi- finger gestures on the touchpad to enhance productivity while interacting with the operating system. Table 13. -
Page 33: Protect Your Privacy Using The Camera Switch
Table 13. Multi-finger touchpad gestures (continued) Gesture Function Swipe left or right with three fingers Switches between open apps Tap three fingers on the touchpad Opens Windows Search Tap four fingers on the touchpad Opens Notification Center Modify the default functions for touchpad gestures The functions for three-finger and four-finger touchpad gestures can be modified in Windows Settings. -
Page 34: Intelligent Features
• You may need to complete online update to the apps for the features to take effect. Smart Noise Cancelling Smart Noise Cancelling is a noise reduction feature available on some Lenovo product models. By filtering out input and output noises, Smart Noise Cancelling enhances your audio experience. -
Page 35: Super Resolution
• You can download the latest version of this app from Microsoft Store. Smart Connect Smart Connect is an app that can easily pair your PC with your Motorola smartphone and Lenovo tablet. With Smart Connect, you can: • Access mobile apps on your PC •... -
Page 36: Lenovo Ai Now
(F11) as a shortcut. Lenovo AI Now Lenovo AI Now is your personal and private AI assistant. It enables you to boost your productivity by building your personal knowledge library, helps you with inspiration, writing and summarizing, and provides troubleshooting and quick settings for your PC. -
Page 37: Set Passwords In The Firmware Setup Utility
Note: You should rarely need to use the setup utility for your daily PC usage. To view device information, you can use the utilities provided by the operating system or apps provided by Lenovo (Lenovo Vantage or Lenovo PC Manager). You can use the Novo button menu to temporarily change the order of boot devices. -
Page 38: Change Or Remove Administrator Password
Lenovo authorized service personnel cannot reset your password or recover data from the hard disk. You must take your computer to a Lenovo authorized service personnel to have the hard disk drive replaced. Proof of purchase is required and a fee will be charged for parts and service. -
Page 39: Change Or Remove Hard Disk Password
Step 1. Open the firmware setup utility. Step 2. Select Security ➙ Set Hard Disk Password and press enter. Note: If your computer model includes more than one secondary storage device, you can set separate password for each device. If you start the setup utility using the user password, you cannot set hard disk password. - Page 40 User Guide...
-
Page 41: Chapter 3. Help And Support
Why does my computer start automatically when I open the lid Your computer may have Flip to Start enabled. Many Lenovo notebook computers include a sensor that can detect the angle at which the lid is opened. When you open the lid, the sensor can detect this behavior. If Flip to Start is enabled, the computer will respond by starting up automatically. -
Page 42: What Is A Cru
Windows help information assistant. • Microsoft support Web site: https:// support.microsoft.com What is a CRU? Customer replaceable units (CRUs) are parts that can be upgraded or replaced by the customer. A Lenovo computer may contain the following types of CRUs: User Guide... -
Page 43: Crus For Your Product Model
If you intend to install a CRU, Lenovo will ship the CRU to you. You might be required to return the defective part that is replaced by the CRU. When return is required: (1) return instructions, a prepaid shipping label, and a container will be included with the replacement CRU;... -
Page 44: Lenovo Customer Support Center
• Lenovo hardware repair - If the problem is determined to be caused by Lenovo hardware under warranty, trained service personnel are available to provide the applicable level of service. -
Page 45: Appendix A. Notices And Trademarks
Lenovo representative for information on the products and services currently available in your area. Any reference to a Lenovo product, program, or service is not intended to state or imply that only that Lenovo product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any Lenovo intellectual property right may be used instead. - Page 46 Actual results may vary. Users of this document should verify the applicable data for their specific environment. This document is copyrighted by Lenovo and is not covered by any open source license, including any Linux agreement(s) which may accompany software included with this product. Lenovo may update this document at any time without notice.
