INSTALLATION
One Piece Concealed Toilet
With Toilet Seat
A
B
D
E
INSTALLATION TIPS
Luxart suggests using a locally licensed plumber for installation.
Need Help? Please call our toll-free customer service line at 1-225-295-4212 for additional assistance or service
If you have any questions or concerns regarding our warranty plan, please email: customerservice@1858brands.com
INCLUDED PARTS
A Plastic Toilet Seat
B Plastic Oval Side Caps
C Floor Bolts
C
D Wax Ring
E Push Button
LXS10017
LXS10018
x1
x2
x2
x1
x1
Revised: 1/14/2022
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Luxart ELLONIA LXS10017
Summary of Contents for Luxart ELLONIA LXS10017
- Page 1 E Push Button INSTALLATION TIPS Luxart suggests using a locally licensed plumber for installation. Need Help? Please call our toll-free customer service line at 1-225-295-4212 for additional assistance or service If you have any questions or concerns regarding our warranty plan, please email: customerservice@1858brands.com...
-
Page 2: Installation
LXS10017 LXS10018 Installation FIGURE 1 NOTE REGARDING WATER SUPPLY: Before installation ensure that the shut-off valve is greater than 7½" from the center of the drain to the center of the shut-off valve and less than or equal to 7" from the floor (FIGURE 1). Note: This is a true 12"... - Page 3 LXS10017 LXS10018 Installation FIGURE 5 6. Lower the toilet onto the floor bolts, so the floor bolts project through the mounting holes in the base of the toilet (FIGURE 5). Using a rocking motion, press the bowl down to position the toilet onto the flange and create a seal with the wax ring.
- Page 4 LXS10017 LXS10018 Installation 15. Install the quick removal metal hinge with expansion FIG UR E bolt provided onto the bowl through the seat holes. Tighten from the top of the bowl with a screwdriver (FIGURE 9). 16. Place the seat cover onto the bowl and align the quick removal mechanism with the metal hinge that is installed on the bowl.
- Page 5 LXS10017 LXS10018 Luxart® products will be covered by Foremost Groups, lnc.'s limited warranty. It is as follows: Foremost warrants its products to be free from defects in material (Vitreous China) and 1 year (Parts and Fittings) from the date of original purchaser.
