INSTALLATION INSTRUCTIONS
FOR
G205 AND G207 STICK GRIPS
G207
G205
Warning: Installation and use of Ray Allen Company products is the responsibility of the aircraft designer and builder. Use of Ray Allen products in any
application which will exceed their capability can cause failure leading to injury or death.
1
Advertisement
Summary of Contents for ray allen G205
- Page 1 G205 Warning: Installation and use of Ray Allen Company products is the responsibility of the aircraft designer and builder. Use of Ray Allen products in any application which will exceed their capability can cause failure leading to injury or death.
- Page 2 About the wires: Your Ray Allen stick grip comes to you with pre-cut and stripped, 26 gauge, 19 strand, teflon insulated wires. Each of these wire pieces are cut to specific lengths for specific connections. In the following instructions, you will be told which wire lengths should go where, eliminating any guess work on your part.
-
Page 3: About The Switches
#1 and #3 in the drawings). The single pole double throw switches in the G205 stick grip are each rated for 5 amps, so they can be wired directly to your Ray Allen servos. The PTT switch can be wired directly to your radio. - Page 4 WIRING STYLE 1 This wiring style will directly control Ray Allen trim servos using one stick grip. The wiring shown in the following diagrams can be completed with the seven pre-cut and stripped wire pieces included in your kit. The 20 ft. of wire (also included) can be cut into seven equal lengths and used to exit the grip and control stick.
- Page 5 *You want to install two stick grips and do not want to use relay decks. *You have Ray Allen rocker switches already installed and want to install a stick grip. With this wiring method a 4PDT switch is used to transfer control of the trim servos from one stick grip to the...
- Page 6 This single momentary contact actuates Ray Allen relays to control the trim servos. Begin the wiring by installing the pre-cut and stripped wire pieces shown in Figure 2A, then continue with the longer wires that you have cut, as shown in Figure 2B.
- Page 7 WIRING STYLE 2 (cont’d.) Figure 2C Pilot's Grip Copilot's Grip Switch Switch Switch Switch Switch Switch Switch Switch Switch Switch Radio See Relay Deck REL-1 instructions for Relay Deck wiring. Elevator Servo See Relay Deck REL-1 instructions for Relay Deck wiring.
-
Page 8: Final Assembly
4-40 screw recommended) Warning: Installation and use of Ray Allen Company products is the responsibility of the aircraft designer and builder. Use of Ray Allen products in any application which will exceed their capability can cause failure leading to injury or death.
