Installation Instructions
02684
EV-RAZOR-16M
02685
EV-RAZOR-16M-B
02686
EV-RAZOR-24M
02687
EV-RAZOR-24M-B
CONTENTS
1.
Welcome
2.
3.
4.
5.
6.
7.
8.
9.
1. WELCOME
Thank you for choosing this quality Ektor product.
This manual is intended to help you install this
product in a way that ensures the safety of yourself
and others. Whilst this Ektor product is designed
to be installed easily, we highly recommend you
take the time to read this manual thoroughly before
commencing installation. When installed correctly
and serviced regularly, this product will provide
hassle free operation for many years.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EV-RAZOR-16M and is the answer not in the manual?

Questions and answers

Summary of Contents for ektor EV-RAZOR-16M

  • Page 1: Table Of Contents

    30. Compliance standards 31. Technical support and troubleshooting 1. WELCOME Thank you for choosing this quality Ektor product. This manual is intended to help you install this product in a way that ensures the safety of yourself and others. Whilst this Ektor product is designed...
  • Page 2: Overview

    RAZOR INSTALLATION INSTRUCTIONS 2. OVERVIEW Ektor Generation III platform introduces you to a new era of emergency lighting control. With years in the making, the third generation platform builds on the Ektor product ranges’ increasing quality, reliability and performance. In choosing this Ektor product you can be comfortable that you have the best.
  • Page 3: Installation

    4. INSTALLATION The Ektor Razor is supplied semi-assembled for transit, components require to be disassembled prior to fitment in different configurations (refer to Section 5, pages 3-6, for mounting options). Remove the product from the box and inspect it for any damage. If you believe the product to be damaged or otherwise unsound, DO NOT install the product.
  • Page 4: Surface Mount

    RAZOR INSTALLATION INSTRUCTIONS Once the top has been mounted, the product can be re-assembled as shown in the figure below. Slide and lock on lugs NOTE: Depending on the orientation of the Razor fitment direction may be opposite as shown. Figure 3: Razor re-assembly diagram SURFACE MOUNT The surface mount cover must be fastened to the ceiling first.
  • Page 5: Rod Mount

    ROD MOUNT Refer to 01990 EV-RODMOUNT-WHT Installation guide included in rod mount kit. The product and rod MUST BE dry and clean before assembly to avoid joint contamination. Assemble the Razor as shown in the assembly instructions in Section 4 (page 3) of this manual. This will allow for the rod mount to be assembled with the Razor top cover.
  • Page 6: Inserting Decals

    RAZOR INSTALLATION INSTRUCTIONS Using pliers clamp the jack chain and thread through the Razor SM kit as shown in the Figure 6. Jack chain Cable NOTE: Once the cover has been chain mounted the Razor can be assembled. Ensure the cable is secured onto the jack chain and run up into ceiling (as shown in Figure 7).
  • Page 7: Replacing The Battery

    AS/NZS 2293 or an equivalent standard can have a positive effect on the battery performance as long as exceed 12 discharge cycles per year is not exceeded. 9. POWER AND BATTERY CHARGE The Ektor Generation III platform uses smart battery charging technology which reduces power consumption and increases battery life. Max charge voltage...
  • Page 8: Maintaining Your Razor Luminaire

    10. MAINTAINING YOUR RAZOR LUMINAIRE WARNING The Ektor Razor Emergency is connected to an unswitched active during normal operating conditions. When disconnected from the mains supply, the Razor is powered by a LiFePO4 battery operated inverter. Due to this, care should be taken when replacing the battery.
  • Page 9: Self Test / Standard Wiring / Central Battery System

    12. SELF TEST / STANDARD WIRING / CENTRAL BATTERY SYSTEM The Razor inverter can be used in an automatic self-test mode which reduces the need for a test switch timer. The self-test ability automatically disables if the unit is wired to DALI or the wireless daughterboard is attached. Additionally the third generation platform can be wired to a central battery system.
  • Page 10: Using The Inverter With A Sensor

    RAZOR INSTALLATION INSTRUCTIONS 15. USING THE INVERTER WITH A SENSOR A mains rated sensor can be wired with this product to turn ON/OFF the light in normal use. This does not affect operation in emergency mode. Mains rated sensor Figure 16: Inverter sensor wiring diagram 16.
  • Page 11: Changing The Cable Set

    EV-RAZOR-24M-DIFF-B 02992 Surface mount kit EV-RAZOR-LEDFIRE-SM-KIT 02981 Surface mount kit Black EV-RAZOR-LEDFIRE-SM-KIT-B 02982 Battery 1500mAh, 6.4V, 2 Cell, LiFePO4 EV-1500mAh-6.4V-LiFeP04 01302 Wi-Fi daughterboard compatible with Ektor devices ZC-WIFI 06118 Easy Commissioning Module - DALI compatible with Ektor devices ZC-ECM-DALI 05304...
  • Page 12: Non Maintained / Maintained Jumper

    RAZOR INSTALLATION INSTRUCTIONS 19. NON MAINTAINED / MAINTAINED JUMPER A user can select the mode of operation for the Razor inverter. If the inverter is using a switch input this is disregarded and not used. INDICATOR STATUS DESCRIPTION LED is only ON in NON MAINTAINED emergency LED is ON in normal and...
  • Page 13: Self Test Indicators Leds

    21. SELF TEST INDICATOR LEDS The table below shows the operation of the Razor status indicators: INDICATOR DESCRIPTION YELLOW Device is performing a duration test 2sec ON / 2sec OFF YELLOW Last duration test passed. The duration was met when last run. 4sec ON / 1sec OFF Test ran less than five days ago YELLOW...
  • Page 14: Product Specifications

    RAZOR INSTALLATION INSTRUCTIONS 23. PRODUCT SPECIFICATIONS RAZOR 24M 65mm 45mm 220mm 365mm 95mm RAZOR 16M 65mm 45mm 165mm 365mm 95mm Voltage 220~240V Viewing distance 24/16M Frequency Mounting type 50/60Hz Recessed Ambient temp. 0-40°C Wiring Flex & Plug Battery type LiFePO4 6.4V Battery supply current 750mA Class...
  • Page 15: Spacing Table

    26. TESTING PRECAUTIONS When the Ektor Emergency product is permanently connected to the mains supply you will need to allow 24 hours to charge its battery. Once the battery is fully charged you will need to conduct a manual discharge test as per the requirements of AS/NZS 2293 or other relevant standards.
  • Page 16: Problem Solving Procedure

    If you choose to expose the Ektor emergency products to such harsh operating conditions, Evolt may not honour any warranty on the life of the batteries or the dish. This Ektor emergency product is designed to undergo regular discharge tests but it is recommended that the intervals between consecutive tests are not less than two weeks.
  • Page 17: Warranty Information

    Australian Competition and Consumer Act and other Australian laws. Ektor products are warranted in Australia for a period of 12 months from the date of delivery of the product, provided that the products are properly stored, installed, used and maintained in accordance with the instructions contained within their manual.
  • Page 18: Compliance Standards

    RAZOR INSTALLATION INSTRUCTIONS 30. COMPLIANCE STANDARDS STANDARD TITLE Australian/ New Zealand AS/NZS 2293-3:2005+A1:2010 Emergency escape lighting and exit signs for buildings. Part 3: Emergency escape luminaires and exit signs. Standards AS/NZS 60598-2-22:2005 Luminaires Part 2.22: Particular requirements - Luminaires for emergency lighting (IEC 60598-2-22, Ed.
