USER GUIDE
YOYOPower 4G Control
YOYOPower GSM Control
YOYOPower Slave Unit
Status Indicators
Power - OFF Power - ON
(Main Unit) Ready. Connected to mobile network
(Slave Unit) Ready. Connected to Main Unit
(Main Unit) Processing / No SIM
(Slave Unit) Searching for Main Unit
(Main Unit) Searching for mobile network
(Slave Unit) Not paired with Main Unit
(Main Unit) Ready for pairing
Factory Reset (10 seconds)
YOYOPower Features
Get current temperature. Set an SMS alert if the temperature
goes outside a given range. Requires temperature sensor
(supplied) to be plugged in. Optional accessory waterproof
sensor on 2m cable with extended range (-30˚C to +100˚C).
SMS status notifications including power loss, power
restored and low mobile signal. Notification when outlet
switched ON or OFF manually or by one of the automatic
control modes.
Master sets up devices and has full control. Up to 4 additional
Master
users can switch outlets ON or OFF and arm or disarm the alarm
+4 Users
using SMS or App. When Notification to Users is enabled, Users
also receive certain notifications.
X4
Add up to four Slave Units. These connect wirelessly to the Main
Unit and are operated by SMS or APP in the same way as the
Main Unit.
Up to six wireless alarm sensors (optional accessories) such as
smoke, door open, PIR & water sensor. Sensor activation is
X6
signalled by an alarm SMS. Choose whether a sensor always
sends an alarm or only when alarms are enabled (e.g. by sched-
ule). (YOYOPower 4G Control only)
Connect one or more wireless sirens with stroboscope. It sounds
and flashes for a minute whenever there is an alert from any
alarm sensor. (YOYOPower 4G Control only)
X2
Up to two optional wireless remote controls: Alarm on and off
buttons turn sensor alarms on and off. Panic button always
sends an alarm, even when sensor alarms are off. Button to
switch power on and off. (YOYOPower 4G Control only).
®
Main Unit
®
Main Unit
Easy set-up and control by SMS or APP (search for
SM
YOYOPower in the App Store or Google Play™).
Outlet ON/OFF button on side of unit plus ability
to switch by phone call from Master or User.
Control the outlet power by one of the three
automatic control modes: Schedule (time of day
and day of week), Delay Timer (1-720 minutes) or
Temperature (thermostat).
Get to know YOYOPower
Power ON/OFF Indicator
Status Indicator
Power Outlet
SIM Card Slot
Main Unit
Insert SIM card
Step 1: Prepare Main Unit
1. Plug in the temperature sensor to the socket on the side of YOYOPower, if required.
Use a standard 3.5mm stereo audio extension cable if you wish to locate the sensor
away from YOYOPower.
2. Unplug the unit and wait two minutes. YOYOPower uses a Mini (standard size) SIM.
Insert the SIM Card:
a. Hold the SIM card with the gold contacts facing upwards, as shown.
b. Insert the SIM gently until you feel a spring pressing back.
c. Insert a little further and the SIM clicks in to place.
To remove the SIM Card:
a. Gently press the SIM card with your fingernail until you hear a click.
b. The spring in the slot ejects the SIM a few millimetres.
c. Remove the SIM from the slot.
Note: The SIM PIN must be disabled. Use a mobile phone to check and, if necessary,
turn off SIM Lock.
Note: Check that the SIM card has credit.
Warning: Always be sure to unplug YOYOPower and wait 2 minutes before inserting
or removing the SIM card. Do not touch the gold contacts of the SIM Card.
Step 2: Set up Main Unit
1. Plug YOYOPower in to an outlet.
2. The status indicator flashes for approximately 60 seconds then changes to slow
fade (Ready) indicating that the mobile network has been found.
3. Register your mobile phone to be the Master that controls YOYOPower:
Install YOYOPower from the App Store
·
Open the YOYOPower app, tap + add Main Unit and enter the location (e.g.
·
Garage), the name of the controlled appliance (e.g. heater) and the Main Unit's
mobile number.
or
#00#
Send an SMS with text
·
4. Wait for the welcome SMS with the default password 1234 (Don't forget to change it!)
5. Change language to English by sending
6. Test by switching the outlet ON and OFF according the instructions below.
7. Plug in the appliance to be controlled via YOYOPower.
YOYOPower Main Unit is now operational
Outlet ON/OFF button
/ Factory Reset
Socket for
temperature sensor
Power Plug
Temperature Sensor
3.5mm stereo
type jack plug
Warning: Use Mini (standard size) SIM only.
Never insert a Micro or Nano sized SIM.
SM TM
or Google Play
to the Main Unit's mobile number.
#39#0#
