ActronAir Easyconnect

Installation and Setup Guide for

UltraSlim Ducted, Bulkhead Ducted

and Cassette Systems

Compatible with:

UltraSlim

Cassette

LRE-071AS CRE-053AS

LRE-100AS CRE-071AS

LRE-130AS CRE-100AS

LRE-170AS CRE-125AS

LRE-071CS CRE-140AS

LRE-100CS CRE-100CS

LRE-125CS CRE-125CS

LRE-140CS CRE-140CS

LRE-170CS

IMPORTANT NOTE:

Please read this manual carefully before installing or operating your air conditioning unit.

Mini Cassette

Bulkhead

MRE-035AS BRE-026BS

MRE-050AS BRE-035BS

MRE-035CS BRE-052BS

MRE-053CS BRE-071BS

BRE-026CS

BRE-035CS

BRE-050CS

BRE-070CS

Table of Contents

Need help?

Do you have a question about the Easyconnect WUK-CAC1 and is the answer not in the manual?

Questions and answers

Summary of Contents for ActronAir Easyconnect WUK-CAC1

Page 1 ActronAir Easyconnect Installation and Setup Guide for UltraSlim Ducted, Bulkhead Ducted and Cassette Systems Compatible with: UltraSlim Cassette Mini Cassette Bulkhead LRE-071AS CRE-053AS MRE-035AS BRE-026BS LRE-100AS CRE-071AS MRE-050AS BRE-035BS LRE-130AS CRE-100AS MRE-035CS BRE-052BS LRE-170AS CRE-125AS MRE-053CS BRE-071BS LRE-071CS CRE-140AS BRE-026CS...
Page 2: Table Of Contents
Installation Guide Easyconnect App Table of Contents 01. Speciﬁcation and Precautions ......3 02. Components ............4 03. Installation ............5 04. Download and Install the Easyconnect App ..10 05. Create an Account ..........10 06. Device Conﬁguration ......... 12 06.01. Amazon Alexa 06.02.
Page 3: Specification And Precautions
Easyconnect App and connected controllers. • ActronAir will not be liable for any issues and problems caused by network connections, Wi-Fi router and smart devices. Please contact the product supplier of these third party devices directly to get further assistance.
Page 4: Components
Installation Guide Easyconnect App 02. Components Name Shape Quantity Smart Port Receiver and CN2 Cable Extension Cable (6m) 4 Core Wire Control Cable Disposable Remote Controller (Easyconnect setup only) Easyconnect Wi-Fi USB QR Label Screw Wall Mounting Plug AAA Battery (1.5V) Installation Guide - Easyconnect App Document: 9590-4009 Ver.
Page 5: Installation
Installation Guide Easyconnect App 03. Installation Wi-Fi controller structure size figure: ( All dimensions are in mm unless specified). 36.8 Figure 4-1 Do not exceed supplied cable lengths between indoor unit and smart port. Extension of this length may create loss of communication between the PCB and/or wired control Wi-Fi Smart Port.
Page 6 Installation Guide Easyconnect App 1. Remove the backing plate from the Smart Port Receiver. Insert a screwdriver into the two slots in the lower part of the Smart Port Receiver and remove the backing plate. (See Figure 4-2) Slots Slots Figure 4-2 Fig 4-5 2.
Page 7: Installation Method
Screws (M4×20) Installation Guide Easyconnect App 3. Insert the supplied Easyconnect Wi-Fi USB into the port at the back of the Smart Port Receiver. (See Figure 4-4) 4. INSTALLATION METHOD Fig 4-7 Figure 4-4 （ 4. Connect the Smart Port: ①...
Page 8 Installation Guide Easyconnect App To main PCB CN3 Terminal (4 Core Wire Control Cable Connection) Figure 4-7 CN2 Cable To the Connected Wired Controller Figure 4-8 Installation Guide - Easyconnect App Document: 9590-4009 Ver. 6 230501...
Page 9 4. INSTALLATION METHOD Installation Guide Easyconnect App wire controller Extension cord smart port 4-core shielding wire Figure 4-9 The connective wires group-2 Fig 4-4 • Connection to indoor unit with no wired connection. Run the 6m Extension Cable (Supplied) from the Smart Port Receiver CN2 4.
Page 10: Download And Install The Easyconnect App
4-9) When under installation, reserve certain leng connecting wire for convenient to take down the s while during maintenance. Installation Guide Easyconnect App 5. Reattach the upper part to the PCB backing cover. Buckle the upper case after adjusting it, to avoid clamping the wiring during installation and clip it into place onto the backing plate mounted on the wall or ceiling.
Page 11 Installation Guide Easyconnect App 1. When the app is opened for the first 2. Tap on Create Account. time, it will ask permission for sending notifications. It is the discretion of the user to allow or disallow the permission. The user can change this permission at any time in the phone’s settings.
Page 12: Device Configuration
Installation Guide Easyconnect App 06. Device Configuration 06.01. Amazon Alexa Download Amazon Alexa from Once the Amazon Alexa app has google playstore or apple if you been installed on your device, haven’t done so already. Once open up the app. Click on the logged in, follow below steps “More”...
Page 13 Installation Guide Easyconnect App Search for “easyconnect” skill. Select Easyconnect” from the results list. Once you have selected A login prompt for easyconnect EasyConnect from the results list, will appear, login with your click on “Enable to Use” button Easyconnect app credentials. which will take you to the next step.
Page 14: Google Home
Installation Guide Easyconnect App Once logged in, the Amazon Alexa 10. Alexa will then start looking for App will confirm the successful devices to connect with. linking of your account. You can now close this window by clicking on “Done” on the top left hand corner.
Page 15 Installation Guide Easyconnect App Choose “easyconnect” and jump After logging in to your to the authorisation page of Easyconnect account, tap “Agree Easyconnect App. and Link”. You will be redirected to Google Home App and the device will be shown. Now you can use Google Home voice controller to control your devices.
Page 16: Smart Device (Easyconnect)
Installation Guide Easyconnect App 06.03. Smart Device (Easyconnect) NOTES • Ensure that the Android or iOS device can be automatically connected to the Wi-Fi network - you can adjust this in your phone settings. • To configure Easyconnect, a wireless remote controller must be used - a disposable control is supplied in the kit to setup the Wi-Fi.
Page 17 Installation Guide Easyconnect App 6. Select home Wi-Fi, enter the 7. Wait to connect to the network. password. 8. Device successfully detected. 9. You can choose an existing name or You can modify the default name. customize a new name. 06.03.02.
Page 18 Installation Guide Easyconnect App 3. Power the Air conditioner off from 4. Within 8 minutes of power being the power supply for 15 seconds, reset, press the LED button on the then back on again. remote control 7 times - this will initiate access point mode and allow your phone to link with the Easyconnect app setup process.
Page 19 Installation Guide Easyconnect App 5. The next step will direct you to connect your network - link to: net_ac_xxxx Default password is “12345678”. NOTE Android devices will allow you to scan the QR code provided with the Easyconnect module, this will bypass the manual setup - allowing for quicker configuration.
Page 20 Installation Guide Easyconnect App 7. Select your Wi-Fi name (SSID) and 8. When a Wi-Fi connection has been enter your router password to established between Easyconnect commence configuration. and the network - automatic setup will begin. • Once network configuration is successful, a success message notification will appear on the display screen.
Page 21: Operation And Control
Installation Guide Easyconnect App 07. Operation and Control 07.01. Amazon Alexa SUPPORTED VOICE COMMANDS Please use the name of your Air Conditioner as <device>. Function Utterance Power On “Alexa, turn <device> on.” “Alexa, turn <device> off.” Power Off Report power state “Alexa, is <device>...
Page 22: Google Home
Installation Guide Easyconnect App NOTE Some features may not be available depending on the model. Please refer to the product catalogue for applicable features 07.02. Google Home SUPPORTED VOICE COMMANDS Function Utterance Power On “Hey Google, turn on air conditioner” “Hey Google, turn off air conditioner”...
Page 23 Installation Guide Easyconnect App Function Utterance Fan Speed Medium “Hey Google, set air conditioner to medium speed.” Fan Speed High “Hey Google, set air conditioner to high speed.” Fan Speed Auto “Hey Google, set air conditioner to enhanced.” Report controller ambient “Hey Google, what is the temperature temperature on air conditioner?”...
Page 24: Smart Device (Easyconnect)
Installation Guide Easyconnect App 07.03. Smart Device (Easyconnect) 1. When opening the Easyconnect 2. After a moment, you are taken to App, you are greeted with this login your account screen, which will page. have your linked air conditioners. Multiple air conditioners can be controlled from the one account.
Page 25: Operating Functions
Installation Guide Easyconnect App 08. Operating Functions Clickwheel Use the clickwheel to adjust the system set temperature up/down. Vertical Swing Turns On/Off vertical louvre. Horizontal Swing Turns On/Off horizontal louvre. Turbo Sets turbo mode On/Off by pressing the lightning symbol when operating in heat and cool modes.
Page 26 Installation Guide Easyconnect App Appendix A Receiver Board for Ducted Units: Installation Guide - Easyconnect App Document: 9590-4009 Ver. 6 230501...
Page 27 THIS PAGE WAS INTENTIONALLY LEFT BLANK...
Page 28 ©Copyright 2020 Actron Engineering Pty Limited ABN 34 002767240. ®Registered Trade Marks of Actron Engineering Pty Limited. ActronAir is constantly seeking ways to improve the design of its products. Therefore, specifications are subject to change without notice. Installation Guide - Easyconnect App...
