Sola AirMaster 100 Installation & Service Manual

Air to water heat pump
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Edition 1.0
2023-11-10
AirMaster 100
Air to Water Heat Pump
Installation & Service
Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AirMaster 100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Sola AirMaster 100

  • Page 1 Edition 1.0 2023-11-10 AirMaster 100 Air to Water Heat Pump Installation & Service Manual...

  • Page 2: Table Of Contents

    Installation requirements for R32 gas due to the flammability of the refrigerant ......26 Preparing refrigerant piping ......................30 5.4.1 Refrigerant piping requirements ....................30 5.4.2 Refrigerant pipe insulation ......................30 2/122 SOLA Table of contents Air/Water Heat Pump AirMaster100 About the documentation 7.3.2024...
  • Page 3 6.5.8 To connect the refrigerant piping to the outdoor unit..............55 6.5.9 To connect the refrigerant piping to the indoor unit ..............55 Checking the refrigerant piping ....................... 56 3/122 SOLA Table of contents Air/Water Heat Pump AirMaster100 About the documentation...
  • Page 4 7.1.3 To connect the PC cable to the HMI ....................77 7.1.4 Interface overwiev .......................... 78 7.1.5 To access the most used commands ....................83 7.1.6 Configuration examples ........................84 4/122 SOLA Table of contents Air/Water Heat Pump AirMaster100 About the documentation 7.3.2024...
  • Page 5 11.3.9 Symptom: Hot water does NOT reach the temperature (no tank installed) ........ 99 11.3.10 Symptom: Hot water does NOT reach the temperature (tank installed) ......... 100 11.4 Solving problems based on error codes ..................100 5/122 SOLA Table of contents Air/Water Heat Pump AirMaster100 About the documentation 7.3.2024...
  • Page 6 13.5.1 Indoor unit ..........................113 13.5.2 Outdoor unit ..........................115 13.6 Technical characteristics ........................ 117 13.7 Temperature chart......................... 121 13.7.1 For heating ..........................121 13.7.2 For cooling ..........................121 6/122 SOLA Table of contents Air/Water Heat Pump AirMaster100 About the documentation 7.3.2024...

  • Page 7: General Safety Precautions

    EXPLOSION DANGER: RISK OF Indicates a situation that may cause poisoning. POISONING WARNING: Indicates a situation that may cause damage of equipment or property. PROTECT AGAINST FROST 7/122 SOLA General safety precautions Air/Water Heat Pump AirMaster100 About the documentation 7.3.2024...

  • Page 8: For The Installer

    Only use accessories, optional equipment and spare parts made or approved by SOLA. WARNING Make sure installation, testing and applied materials comply with applicable legislation (on top of the instructions described in the SOLA documentation). CAUTION Wear adequate personal protective equipment (protective gloves, safety glasses,…) when installing, maintaining or servicing the...

  • Page 9: Installation Site

    Use a vacuum pump to evacuate the installation. After all the piping has been connected, make sure there is no gas NOTICE leak. Use nitrogen to perform a gas leak detection. 9/122 SOLA General safety precautions Air/Water Heat Pump AirMaster100 For the installer 7.3.2024...
  • Page 10 WARNING close the valve of the refrigerant tank immediately. If the valve is not closed immediately, remaining pressure might charge additional refrigerant. Possible consequence: Incorrect refrigerant amount. 10/122 SOLA General safety precautions Air/Water Heat Pump AirMaster100 For the installer 7.3.2024...

  • Page 11: Water

    ONLY use copper wires. Make sure the field wiring complies with the applicable legislation. All field wiring must be performed in accordance with the wiring diagram supplied with the product. 11/122 SOLA General safety precautions Air/Water Heat Pump AirMaster100 For the installer 7.3.2024...
  • Page 12 1 metre may not be sufficient. WARNING After finishing the electrical work, confirm that each electrical component and terminal inside the electrical components box is connected securely. 12/122 SOLA General safety precautions Air/Water Heat Pump AirMaster100 For the installer 7.3.2024...

  • Page 13: Local Legislation

    Power supply heater Indoor Outdoor unit unit AWM1002.075.XS6.A00.C11 230V~ 230V~ AWM1002.075.XS8.A00.C11 230V~ 230V~ AWM1002.075.XS10.A00.C11 230V~ 230V~ AWM1002.075.XS10.A00.C13 230V~ 400V~ AWM1002.075.XS12.A00.C13 230V~ 400V~ AWM1002.075.XS14.A00.C13 230V~ 400V~ AWM1002.075.XS16.A00.C13 230V~ 400V~ 13/122 SOLA General safety precautions Air/Water Heat Pump AirMaster100 For the installer 7.3.2024...

  • Page 14: About The Documentation

    • Format: Paper (in the box of the indoor unit) ▪ Comissioning manual: • Comissioning manual for heat pump controller • Format: Digital files on the SOLA homepage ▪ Catalog of hydraulic diagrams: • Catalog of available partitial hydraulic diagrams •...

  • Page 15: Installer's Guide

    • Format: Paper (in the box of the indoor unit) Latest revisions of the supplied documentation may be available on the SOLA website or via your dealer. The original documentation is written in English. All other languages are translations. Installer's guide...

  • Page 16: About The Box

    • Bring the packed unit as close as possible to its final installation position to prevent damage during transport. Outdoor unit 4.2.1 To unpack the outdoor unit Cut the packing tapes. 16/122 SOLA About the box Air/Water Heat Pump AirMaster100 Overview: About the box 7.3.2024...
  • Page 17 Remove the cardboard box by lifting it up. Remove 4 screws. Lift the outdoor unit. 17/122 SOLA About the box Air/Water Heat Pump AirMaster100 Outdoor unit 7.3.2024...

  • Page 18: Indoor Unit

    4.3 Indoor unit 4.3.1 To unpack the indoor unit Cut packing stripes Open cardbox Pick up the documentation and sensor and keep it 18/122 SOLA About the box Air/Water Heat Pump AirMaster100 Indoor unit 7.3.2024...
  • Page 19 Pick up the cardboard insert and place it next to it Extract cardboard protective corners 19/122 SOLA About the box Air/Water Heat Pump AirMaster100 Indoor unit 7.3.2024...
  • Page 20 Place the unit safely on the cardboard pad next to it (do not pull it out yourself, ask someone for help) At the bottom of the package you will find a metal mounting bracket for the indoor unit 20/122 SOLA About the box Air/Water Heat Pump AirMaster100 Indoor unit 7.3.2024...

  • Page 21: Preparation

    See "15.2 Dimensions and service space" for more detailed information about spacing guidelines NOTICE Do NOT stack the units on each other. Do NOT hang the unit on a ceiling. 21/122 SOLA Preparation Air/Water Heat Pump AirMaster100 Overview: Preparation 7.3.2024...
  • Page 22 Make sure the outdoor unit is NOT directly exposed to sea winds. This is to prevent corrosion caused by high levels of salt in the air, which might shorten the life of the unit. 22/122 SOLA Preparation Air/Water Heat Pump AirMaster100 Preparing installation site...
  • Page 23 ▪ Mind the service space requirements when installing the windbreaker. The outdoor unit is designed for outdoor installation only, and for ambient temperatures ranging 10~43°C in cooling mode and -20~25°C in heating mode. 23/122 SOLA Preparation Air/Water Heat Pump AirMaster100 Preparing installation site 7.3.2024...

  • Page 24: Additional Installation Site Requirements Of The Outdoor Unit In Cold Climates

    Maximum refrigerant piping length between indoor unit and 15 m outdoor unit Minimum refrigerant piping length between indoor unit and outdoor unit Maximum height difference between indoor unit and outdoor unit 24/122 SOLA Preparation Air/Water Heat Pump AirMaster100 Preparing installation site 7.3.2024...
  • Page 25 >5°C. • The indoor unit is designed for indoor installation only and for ambient temperatures ranging 5~35°C in cooling mode and 5~30°C in heating mode. 25/122 SOLA Preparation Air/Water Heat Pump AirMaster100 Preparing installation site 7.3.2024...

  • Page 26: Installation Requirements For R32 Gas Due To The Flammability Of The Refrigerant

    If the total refrigerant charge in the system is <1.84kg (i.e. if the piping length is <20m for 8/10kW), there are no additional minimum floor area requirement. 26/122 SOLA Preparation Air/Water Heat Pump AirMaster100 Installation requirements for R32 gas due to the flammability of the refrigerant 7.3.2024...
  • Page 27 A: Room where the indoor unit is installed. Room B and room A are adjacent rooms. The area of A plus B has to be greater than or equal to 4.5 m2. 27/122 SOLA Preparation Air/Water Heat Pump AirMaster100 Installation requirements for R32 gas due to the flammability of the refrigerant 7.3.2024...
  • Page 28 Aroom value from the table. If Aroom = 3m2, consider the value that corresponds to “Aroom = 3m2”. 28/122 SOLA Preparation Air/Water Heat Pump AirMaster100 Installation requirements for R32 gas due to the flammability of the refrigerant 7.3.2024...
  • Page 29 If dm =1.55kg, consider the value that corresponds to “dm =1.6kg”. 29/122 SOLA Preparation Air/Water Heat Pump AirMaster100 Installation requirements for R32 gas due to the flammability of the refrigerant 7.3.2024...

  • Page 30: Preparing Refrigerant Piping

    If the temperature is higher than 30°C and the humidity is higher than RH 80%, the thickness of the insulation materials should be at least 20 mm to prevent condensation on the surface of the insulation. 30/122 SOLA Preparation Air/Water Heat Pump AirMaster100 Preparing refrigerant piping...

  • Page 31: Preparing Water Piping

    You can find the minimum required water flow for indoor unit operation in the following table. In all cases, this flow needs to be guaranteed. When the flow is lower, the indoor unit will stop operation and display error. 31/122 SOLA Preparation Air/Water Heat Pump AirMaster100 Preparing water piping...
  • Page 32 Provide drain taps at all low points of the system in order to allow complete drainage of the water circuit. • Drainage – Pressure relief valve Provide adequate drainage of the pressure relief valve to avoid water contact with electrical parts. 32/122 SOLA Preparation Air/Water Heat Pump AirMaster100 Preparing water piping 7.3.2024...
  • Page 33 Immediately after installation, the domestic hot water tank must be flushed with fresh water. This procedure must be repeated at least once a day the first 5 consecutive days after installation. 33/122 SOLA Preparation Air/Water Heat Pump AirMaster100 Preparing water piping...

  • Page 34: Formula To Calculate The Expansion Vessel Pre-Pressure

    Hot water connection c) Shower d) Recirculation pump 5.5.2 Formula to calculate the expansion vessel pre-pressure The pre-pressure (Pg) of the vessel depends on the installation height difference (H): Pg=0.3+(H/10) (bar) 34/122 SOLA Preparation Air/Water Heat Pump AirMaster100 Preparing water piping 7.3.2024...

  • Page 35: To Check The Water Volume And Flow Rate

    Use the following graph to determine the maximum water volume for the calculated pre-pressure. Pre-pressure (bar) Maximum water volume (l) Maximum leaving water temperature of 55°C for underfloor heating applications Maximum leaving water temperature of 80°C for radiator applications 35/122 SOLA Preparation Air/Water Heat Pump AirMaster100 Preparing water piping 7.3.2024...

  • Page 36: Changing The Pre-Pressure Of The Expansion Vessel

    Changing the pre-pressure of the expansion vessel should be done by releasing or increasing nitrogen pressure through the schräder valve of the expansion vessel. 36/122 SOLA Preparation Air/Water Heat Pump AirMaster100 Preparing water piping 7.3.2024...

  • Page 37: To Check The Water Volume: Examples

    • Because 350 l is more than 205 l, the expansion vessel is too small for the installation. Therefore, install an extra vessel outside the installation. 37/122 SOLA Preparation Air/Water Heat Pump AirMaster100 Preparing water piping 7.3.2024...

  • Page 38: Preparing Electrical Wiring

    Consult with the electricity company acting as provider at the site where this equipment is to be installed to know whether it is appropriate to 38/122 SOLA Preparation Air/Water Heat Pump AirMaster100 Preparing electrical wiring 7.3.2024...

  • Page 39: Overview Of Electrical Connections For External Actuators And Sensors

    Heating and Cooling demands to external generators BX Input Temperature sensor NTC10k HX Input 0-10V or Digital input or Pulse counting. EX Input 230V Digital input 39/122 SOLA Preparation Air/Water Heat Pump AirMaster100 Preparing electrical wiring 7.3.2024...

  • Page 40: Installation

    This is a multifunctional input. How to configure function and function types described in Comissioning manual for controller. Use only approved sensors by SOLA. (g) This is a multifunctional input. How to configure function and function types described in Comissioning manual for controller.

  • Page 41: Opening The Units

    Do NOT leave the unit unattended when the covers is removed. ELECTROCUTION 6.2.2 To open the indoor unit Unscrew 3 srews on the top of indoor unit Remove the upper front panel as shown above. 41/122 SOLA Installation Air/Water Heat Pump AirMaster100 Opening the units 7.3.2024...
  • Page 42 Remove the lower front panel. Unscrew the 6 screws that secure the side panels. 42/122 SOLA Installation Air/Water Heat Pump AirMaster100 Opening the units 7.3.2024...
  • Page 43 Remove side panels. Unscrew 2 screws that secure the switchbox. 43/122 SOLA Installation Air/Water Heat Pump AirMaster100 Opening the units 7.3.2024...

  • Page 44: Mounting The Outdoor Unit

    See "Preparing installation site" in "5 Preparation". 6.3.2 Precautions when mounting the outdoor unit INFORMATION Also read the precautions and requirements in the following chapters: • General safety precautions • Preparation 44/122 SOLA Installation Air/Water Heat Pump AirMaster100 Mounting the outdoor unit 7.3.2024...

  • Page 45: To Provide The Installation Structure

    405 mm 445 mm If the unit is installed on brackets to the wall, in any case, provide at least 300 mm of free space below the unit. 45/122 SOLA Installation Air/Water Heat Pump AirMaster100 Mounting the outdoor unit 7.3.2024...

  • Page 46: To Install The Outdoor Unit

    (see the following illustration). NOTICE If the drain holes of the outdoor unit are blocked up, provide space of at least 300 mm below the outdoor unit. 46/122 SOLA Installation Air/Water Heat Pump AirMaster100 Mounting the outdoor unit 7.3.2024...

  • Page 47: Mounting The Indoor Unit

    6.4.2 Precautions when mounting the indoor unit INFORMATION Also read the precautions and requirements in the following sections: • General safety precautions • Preparation 47/122 SOLA Installation Air/Water Heat Pump AirMaster100 Mounting the indoor unit 7.3.2024...

  • Page 48: To Install The Indoor Unit

    1 Transfer the dimensions from the photo to the installation site of the indoor unit and follow the instructions 2 Fix the wall bracket to the wall with 2 M10 bolts. 3 Lift the unit. 48/122 SOLA Installation Air/Water Heat Pump AirMaster100 Mounting the indoor unit 7.3.2024...

  • Page 49: Connecting The Refrigerant Piping

    Using the stop valves 6.5.2 Precautions when connecting the refrigerant piping INFORMATION Also read the precautions and requirements in the following sections: • General safety precautions • Preparation 49/122 SOLA Installation Air/Water Heat Pump AirMaster100 Connecting the refrigerant piping 7.3.2024...
  • Page 50 Do NOT open the refrigerant stop valve before checking the refrigerant piping. When you need to charge additional refrigerant, it is recommended to open the refrigerant stop valve after charging. 50/122 SOLA Installation Air/Water Heat Pump AirMaster100 Connecting the refrigerant piping...

  • Page 51: Guidelines When Connecting The Refrigerant Piping

    (bending radius should be 30~40 mm or larger). 6.5.5 To flare the pipe end CAUTION Incomplete flaring may cause refrigerant gas leakage. Do NOT re-use flares. Use new flares to prevent refrigerant gas leakage. 51/122 SOLA Installation Air/Water Heat Pump AirMaster100 Connecting the refrigerant piping 7.3.2024...

  • Page 52: To Braze The Pipe End

    • Set the nitrogen pressure to 20 kPa (just enough so it can be felt on the skin) with a pressure-reducing valve. 52/122 SOLA Installation Air/Water Heat Pump AirMaster100 Connecting the refrigerant piping 7.3.2024...

  • Page 53: Using The Stop Valve And Service Port

    Torque wrench • When it is expected that the operating pressure will be low (e.g. when cooling will be performed while the outside air temperature is low), 53/122 SOLA Installation Air/Water Heat Pump AirMaster100 Connecting the refrigerant piping 7.3.2024...
  • Page 54 Schrader type valve. • After handling the service port, tighten the service port cap securely. For the tightening torque, refer to the table in section "To handle the stem cap". 54/122 SOLA Installation Air/Water Heat Pump AirMaster100 Connecting the refrigerant piping 7.3.2024...

  • Page 55: To Connect The Refrigerant Piping To The Outdoor Unit

    NOTICE It is recommended that the refrigerant piping between indoor and outdoor unit is installed in a ducting or the refrigerant piping is wrapped with finishing tape. 55/122 SOLA Installation Air/Water Heat Pump AirMaster100 Connecting the refrigerant piping 7.3.2024...

  • Page 56: Checking The Refrigerant Piping

    Do not use soap water, which may cause cracking of flare nuts (soap water may contain salt, which absorbs moisture that will freeze when the piping gets cold), and/or lead to corrosion of flared 56/122 SOLA Installation Air/Water Heat Pump AirMaster100 Checking the refrigerant piping...

  • Page 57: To Perform Vacuum Drying

    −0.1 MPa (−1 bar). You can also use a tool to measure the vacuum in 1 Vacuum the system until the pressure on the manifold indicates the refrigeration system. When the meter reads 500 microns, the vacuum has been performed correctly. 57/122 SOLA Installation Air/Water Heat Pump AirMaster100 Checking the refrigerant piping 7.3.2024...

  • Page 58: Charging Refrigerant

    1) Determining if and how much you have to charge additionally. 2) If necessary, charging additional refrigerant. 3) Filling in the fluorinated greenhouse gases label, and fixing it to the inside of the outdoor unit. 58/122 SOLA Installation Air/Water Heat Pump AirMaster100 Charging refrigerant 7.3.2024...

  • Page 59: Precautions When Charging Refrigerant

    Only use R32 as refrigerant. Other substances may cause explosions and accidents. • R32 contains fluorinated greenhouse gases. Its global warming potential (GWP) value is 675. Do NOT vent these gases into the atmosphere. 59/122 SOLA Installation Air/Water Heat Pump AirMaster100 Charging refrigerant 7.3.2024...

  • Page 60: To Fix The Fluorinated Greenhouse Gases Label

    × Total refrigerant charge [in kg] / 1000. 2 Fix the label on the inside of the outdoor unit near the gas and liquid stop valves. 60/122 SOLA Installation Air/Water Heat Pump AirMaster100 Charging refrigerant 7.3.2024...

  • Page 61: Connecting The Water Piping

    (for example via a bypass valve). This may trigger an error. 61/122 SOLA Installation Air/Water Heat Pump AirMaster100 Connecting the water piping...

  • Page 62: To Fill The Space Heating Circuit

    ±2 bar (with a minimum of 0.5 bar). 6 Purge air from the water circuit as much as possible. 7 Disconnect the water supply hose from the drain point. 62/122 SOLA Installation Air/Water Heat Pump AirMaster100 Connecting the water piping...

  • Page 63: To Insulate The Water Piping

    7 Connecting the additional I/O modules (if used) 8 Connecting the motorized valves. 9 Connecting the additional pumps (if used) 10 Connecting the additional sensors (if used). 11 Connecting the power consumption digital inputs. 63/122 SOLA Installation Air/Water Heat Pump AirMaster100 Connecting the electrical wiring 7.3.2024...

  • Page 64: Precautions When Connecting The Electrical Wiring

    Place the round crimp-style terminal on the wire up to the covered part and fasten the terminal with the appropriate tool. a Stranded conductor wire b Round crimp-style terminal 64/122 SOLA Installation Air/Water Heat Pump AirMaster100 Connecting the electrical wiring 7.3.2024...
  • Page 65 Connecting metod for spring therminals (Power supply therminal and indoor communication therminal): 1 insert screwdriver in unlocking hole 2 Insert wire in therminal 3 remove screwdriver 65/122 SOLA Installation Air/Water Heat Pump AirMaster100 Connecting the electrical wiring 7.3.2024...

  • Page 66: To Connect The Electrical Wiring On The Outdoor Unit

    3 Strip insulation (20 mm) from the wires. a Strip wire end to this point b Excessive strip length may cause electrical shock or leakage. 4 Connect the interconnection cable and power supply as follows: 66/122 SOLA Installation Air/Water Heat Pump AirMaster100 Connecting the electrical wiring 7.3.2024...
  • Page 67 Power Cable holder supply Connecting outdoor units with 3 phase power supply Power Ground supply Cable holder Communication cable to indoor 5 Install side panel. 67/122 SOLA Installation Air/Water Heat Pump AirMaster100 Connecting the electrical wiring 7.3.2024...

  • Page 68: To Connect The Electrical Wiring On The Indoor Unit

    Electric heater connection, Phase 1 or 3 electric heater Electric heater connection, protective earth See below of Electric heater connection, protective 230V power earth supply or 400V Electric heater connection, neutral power supply conductor 68/122 SOLA Installation Air/Water Heat Pump AirMaster100 Connecting the electrical wiring 7.3.2024...
  • Page 69 Power supply of indoor unit Mains connection, neutral conductor Mains connection, ground Communication + Communication to outdoor unit Communication - REF Shield CL+ BSB + Communication BSB - 69/122 SOLA Installation Air/Water Heat Pump AirMaster100 Connecting the electrical wiring 7.3.2024...

  • Page 70: To Connect Integrated Electrical Heater

    ■ Fuses max. 16 A ■ A low tariff and blocking by the energy supply organization are applied 230V electric heater power supply Briges PE N N N 70/122 SOLA Installation Air/Water Heat Pump AirMaster100 Connecting the electrical wiring 7.3.2024...

  • Page 71: To Connect Control Circuts

    Live conductor to QX3 Free Multifunctional output QX3 Multifunctional output QX4 Free Multifunctional output QX4 (inverse) Neutral conductor Multifunctional output QX5 Free Neutral conductor Triac output ZX6 Free Neutral conductor 71/122 SOLA Installation Air/Water Heat Pump AirMaster100 Connecting the electrical wiring 7.3.2024...
  • Page 72 First, plug the I/O module onto the spacer plate. Then, plug the spacer plate together with the I/O module onto the basic unit. 72/122 SOLA Installation Air/Water Heat Pump AirMaster100 Connecting the electrical wiring 7.3.2024...
  • Page 73 Use connecting ribbon cable to connect the I/O module to socket X100 of the basic unit. The connectors are coded. 73/122 SOLA Installation Air/Water Heat Pump AirMaster100 Connecting the electrical wiring 7.3.2024...
  • Page 74 Neutral conductor QX33 Multifunctional output QX33 Free Neutral conductor ZX34 Triac output ZX34 Free Neutral conductor QX35 Multifunctional output QX35 Free QX35 Multifunctional output QX35 (inverse) Neutral conductor X110 74/122 SOLA Installation Air/Water Heat Pump AirMaster100 Connecting the electrical wiring 7.3.2024...

  • Page 75: Finishing The Outdoor Unit Installation

    6.10.2 To close the outdoor unit 1 Close the front panel. NOTICE When closing the outdoor unit cover, make sure that the tightening torque does NOT exceed 4.1 N•m. 75/122 SOLA Installation Air/Water Heat Pump AirMaster100 Finishing the outdoor unit installation 7.3.2024...

  • Page 76: Finishing The Indoor Unit Installation

    2 Mount the front lower panel. 3 Mount the front upper panel. NOTICE When closing the indoor unit cover, make sure that the tightening torque does NOT exceed 4.1 N•m. 76/122 SOLA Air/Water Heat Pump AirMaster100 Finishing the indoor unit installation 7.3.2024...

  • Page 77: Configuration

    7.1.3 To connect the PC cable to the HMI 1 Connect mini USB cable to USB port of the computer 2 Open cover on HMI 3 Connect USB cable to HMI 77/122 SOLA Configuration Air/Water Heat Pump AirMaster100 Indoor unit 7.3.2024...

  • Page 78: Interface Overwiev

    Operating objects may have three display states: Not selected: The operating object is displayed normally, black on white background. Preselected: The operating object is framed. Selected: The operating object is inverted, white on black background. 78/122 SOLA Configuration Air/Water Heat Pump AirMaster100 Indoor unit 7.3.2024...
  • Page 79 Handling special events and situations • Adapt temperature temporarily. • Hot water 'recharging'. • Shut down building during extended absence. 79/122 SOLA Configuration Air/Water Heat Pump AirMaster100 Indoor unit 7.3.2024...
  • Page 80 Use the Info pages to quickly gain an overview of relevant data on the building or living zones. Pending controller messages (displayed by the symbols on the status bar) are displayed on these pages. 80/122 SOLA Configuration Air/Water Heat Pump AirMaster100 Indoor unit 7.3.2024...
  • Page 81 Temperature page. Access to heating and cooling. Ventilation page. Access to ventilation. Domestic hot water page. Access to hot water handling. Info pages: • Messages (errors, events) • Plant information 81/122 SOLA Configuration Air/Water Heat Pump AirMaster100 Indoor unit 7.3.2024...
  • Page 82 The lower level is displayed if the operating object consists of multiple levels (e.g. time program). Set value. Confirm the set value. The set operating object is again framed (preselected). Continue navigation 82/122 SOLA Configuration Air/Water Heat Pump AirMaster100 Indoor unit 7.3.2024...

  • Page 83: To Access The Most Used Commands

    • Heat pump controller, Partial diagram catalog • Heat pump controller, Comissioning Manual In the documents listed above, you will find the following information: 83/122 SOLA Configuration Air/Water Heat Pump AirMaster100 Indoor unit 7.3.2024...

  • Page 84: Configuration Examples

    Setting parameter 4783 with solar integration: • Go to (Setting Area). • Select full parameter list. • Select buffer tank parameter group. • Select parameter 4783 | Buffer with solar. • Select No. 84/122 SOLA Configuration Air/Water Heat Pump AirMaster100 Indoor unit 7.3.2024...
  • Page 85 • Select on Setting parameter 5715 heating circuit 2: • Go to (Setting Area) • Select full parameter list. • Select configuration. • Select parameter 5715 heating circuit 2 • Select on 85/122 SOLA Configuration Air/Water Heat Pump AirMaster100 Indoor unit 7.3.2024...

  • Page 86: Commissioning

    NEVER operate the unit without thermistors and/or pressure sensors/switches. Burning of the compressor might result. NOTICE Do NOT operate the unit until the refrigerant piping is complete (when operated this way, the compressor will break). 86/122 SOLA Commissioning Air/Water Heat Pump AirMaster100 Overview: Commissioning 7.3.2024...

  • Page 87: Checklist Before Commissioning

    The air purge valve is open (at least 2 turns). The pressure relief valve purges water when opened. The minimum water volume is guaranteed in all conditions. See "To check the water volume" in "5.4 Preparing water piping" 87/122 SOLA Commissioning Air/Water Heat Pump AirMaster100 Precautions when commissioning 7.3.2024...

  • Page 88: Checklist During Commissioning

    10 - 35 0,166-0,583 0,6 – 3 12 kW 10 - 50 0,166-0,833 0,6 – 3 14 kW 10 - 50 0,166-0,833 0,6 – 3 16 kW 10 - 50 0,166-0,833 88/122 SOLA Commissioning Air/Water Heat Pump AirMaster100 Checklist during commissioning 7.3.2024...

  • Page 89: Air Purge Function

    3 Select a mode and press ok. Example: Heating. Result: The test run starts. It stops automatically when done (±30 min). To stop it manually, select off, press ok. 89/122 SOLA Commissioning Air/Water Heat Pump AirMaster100 Checklist during commissioning 7.3.2024...

  • Page 90: To Perform An Io Test Run

    Triac output test (ZX6 modulated) By selecting a setting from output test ZX6, an appropriate signal is delivered. Line no. Operating line 7705 Mod setpoint ZX6 relay test 7708 Modulation signal ZX6 90/122 SOLA Commissioning Air/Water Heat Pump AirMaster100 Checklist during commissioning 7.3.2024...
  • Page 91 Shows the current input value and its type of signal. Input test EX1...EX4 Line no. Operating line 7911 Input EX1 7912 Input EX2 7913 Input EX3 7914 Input EX4 91/122 SOLA Commissioning Air/Water Heat Pump AirMaster100 Checklist during commissioning 7.3.2024...
  • Page 92 None ¦ Closed (ooo), Open (---) ¦ Pulse ¦ Frequency Hz ¦ Voltage V 7999 Input signal H33 7999 [Output signal H33] None ¦ Closed (ooo), Open (---) ¦ Pulse ¦ Frequency Hz ¦ Voltage V 92/122 SOLA Commissioning Air/Water Heat Pump AirMaster100 Checklist during commissioning 7.3.2024...

  • Page 93: Hand-Over To The User

    • Show the user what to do in relation to maintaining the unit. • Explain the user about energy saving tips as described in the operation manual. 93/122 SOLA Hand-over to the user Air/Water Heat Pump AirMaster100 Checklist during commissioning...

  • Page 94: Maintenance And Service

    Check the following at least once a year: • Water pressure • Water filter • Water pressure relief valve • Pressure relief valve of the domestic hot water tank • Switch box 94/122 SOLA Maintenance and service Air/Water Heat Pump AirMaster100 Overview: Maintenance and service 7.3.2024...

  • Page 95: Water Pressure

    To make sure this water originates from the tank, check after a tank heat up cycle. It is recommended to do this maintenance more frequently. 95/122 SOLA Maintenance and service Air/Water Heat Pump AirMaster100 Checklist for yearly maintenance of the indoor unit...

  • Page 96: Switch Box

    NOT be supplied through an external switching device, such as a timer, or connected to a circuit that is regularly turned ON and OFF by the utility. DANGER: RISK OF BURNING 96/122 SOLA Troubleshooting Air/Water Heat Pump AirMaster100 Overview: Troubleshooting 7.3.2024...

  • Page 97: Solving Problems Based On Symptoms

    ▪ The water pressure is >1 bar. inlet is too low ▪ The expansion vessel is NOT broken. ▪ The pre-pressure setting of the expansion vessel is correct 97/122 SOLA Troubleshooting Air/Water Heat Pump AirMaster100 Solving problems based on symptoms 7.3.2024...

  • Page 98: Symptom: The Pressure Relief Valve Opens

    Failing or blocked pressure relief Flush and clean the complete tank valve. including the piping between pressure relief valve and the cold water inlet. Replace the pressure relief valve. 98/122 SOLA Troubleshooting Air/Water Heat Pump AirMaster100 Solving problems based on symptoms 7.3.2024...

  • Page 99: Symptom: Tank Disinfection Function Is Not Completed Correctly

    ▪ The flow is too low. To The domestic hot water temperature fluctuates between hot and cold. guarantee comfort, a minimum water flow of 5 l/min is recommended. 99/122 SOLA Troubleshooting Air/Water Heat Pump AirMaster100 Solving problems based on symptoms 7.3.2024...

  • Page 100: Symptom: Hot Water Does Not Reach The Temperature (Tank Installed)

    Error codes are assigned priorities. As of priority 5 (also priorities 5...9, alarm messages are sent out that are used for remote monitoring (OCI). The alarm relay is also set. 100/122 SOLA Troubleshooting Air/Water Heat Pump AirMaster100 Solving problems based on error codes...

  • Page 101: Disposal

    (<−10°C)), close the liquid stop valve with a hexagonal wrench. 4 Check with the manifold if the vacuum is reached. 5 After 2-3 minutes, close the gas stop valve and stop pump down mode. 101/122 SOLA Disposal Air/Water Heat Pump AirMaster100 Overview: Disposal 7.3.2024...

  • Page 102: To Start Pump Down Mode

    5°C (see temperature read out of the indoor unit). You can achieve this, for example, by activating all fans of the fan coil units. 102/122 SOLA Air/Water Heat Pump AirMaster100 To start pump down mode 7.3.2024...

  • Page 103: Technical Data

    • Dimensions and service space • Components • Piping diagram • Wiring diagram 13.2 Dimensions and service space 13.2.1 Dimensions and service space: Outdoor unit 6kW, 8 kW: 103/122 SOLA Technical data Air/Water Heat Pump AirMaster100 Overview: Technical data 7.3.2024...
  • Page 104 10 kW, 12kW: 14kW, 16kW: 104/122 SOLA Technical data Air/Water Heat Pump AirMaster100 Dimensions and service space 7.3.2024...

  • Page 105: Dimensions And Service Space: Indoor Unit

    13.2.2 Dimensions and service space: Indoor unit 105/122 SOLA Technical data Air/Water Heat Pump AirMaster100 Dimensions and service space 7.3.2024...

  • Page 106: Components

    13.3 Components 13.3.1 Indoor unit 106/122 SOLA Technical data Air/Water Heat Pump AirMaster100 Components 7.3.2024...
  • Page 107 E – air vent valve F – electric heater G – pressure sensor H – expansion tank I – flow meter J – pressure relief valve K – water connection L – refrigeration connection 107/122 SOLA Technical data Air/Water Heat Pump AirMaster100 Components 7.3.2024...

  • Page 108: Outdoor Unit

    Right rear panel Service valves (refrigerating part) Compressor Valve plate Expansion valve Gas-liquid separator Electronic four-way valve Right handle/cable entry Heat exchanger Top cover Fan engine holder Axial fan Rear protective grille 108/122 SOLA Technical data Air/Water Heat Pump AirMaster100 Components 7.3.2024...
  • Page 109 Valve plate Expansion valve Gas-liquid separator Four-way valve Right handle/cable entry Heat exchanger Top cover Fan motor holder Fan motor Axial fan Fan protective grille Electrical box cover Electrical box 109/122 SOLA Technical data Air/Water Heat Pump AirMaster100 Components 7.3.2024...
  • Page 110 Four-way valve Right handle/cable entry Heat exchanger Top cover Right front panel Right rear panel Reactor Rear protective grille Reactor box cover Waterproof reactor box Reactor Electrical box cover Electrical box 110/122 SOLA Technical data Air/Water Heat Pump AirMaster100 Components 7.3.2024...

  • Page 111: Piping Diagram

    13.4 Piping diagram 13.4.1 Outdoor unit: 111/122 SOLA Technical data Air/Water Heat Pump AirMaster100 Piping diagram 7.3.2024...

  • Page 112: Indoor Unit

    13.4.2 Indoor unit 112/122 SOLA Technical data Air/Water Heat Pump AirMaster100 Piping diagram 7.3.2024...

  • Page 113: Wiring Diagram

    13.5 Wiring diagram 13.5.1 Indoor unit Overview of control system Communication board A5 113/122 SOLA Technical data Air/Water Heat Pump AirMaster100 Wiring diagram 7.3.2024...
  • Page 114 114/122 SOLA Technical data Air/Water Heat Pump AirMaster100 Wiring diagram 7.3.2024...

  • Page 115: Outdoor Unit

    13.5.2 Outdoor unit Types: AWM1002.075.XS6.A00.C11, AWM1002.075.XS8.A00.C11, AWM1002.075.XS10.A00.C11 115/122 SOLA Technical data Air/Water Heat Pump AirMaster100 Wiring diagram 7.3.2024...
  • Page 116 Types: AWM1002.075.XS10.A00.C13, AWM1002.075.XS12.A00.C13 AWM1002.075.XS14.A00.C13, AWM1002.075.XS16.A00.C13 116/122 SOLA Technical data Air/Water Heat Pump AirMaster100 Wiring diagram 7.3.2024...

  • Page 117: Technical Characteristics

    13.6 Technical characteristics For unit 6, 8, 10 and 10kW 117/122 SOLA Technical data Air/Water Heat Pump AirMaster100 Technical characteristics 7.3.2024...
  • Page 118 118/122 SOLA Technical data Air/Water Heat Pump AirMaster100 Technical characteristics 7.3.2024...
  • Page 119 For unit: 12,14 and 16kW 119/122 SOLA Technical data Air/Water Heat Pump AirMaster100 Technical characteristics 7.3.2024...
  • Page 120 120/122 SOLA Technical data Air/Water Heat Pump AirMaster100 Technical characteristics 7.3.2024...

  • Page 121: Temperature Chart

    13.7 Temperature chart 13.7.1 For heating 13.7.2 For cooling 121/122 SOLA Technical data Air/Water Heat Pump AirMaster100 Temperature chart 7.3.2024...
  • Page 122 W&H Electric Polska 38-300 Gorlice/Poland ul. Biecka 21a NIP: 7382165961 Tel: 530959386 www.sola.com.pl 122/122 SOLA Technical data Air/Water Heat Pump AirMaster100 Temperature chart 7.3.2024...

This manual is also suitable for:

Awm1002.075.xs6.a00.c11Awm1002.075.xs8.a00.c11Awm1002.075.xs10.a00.c11Awm1002.075.xs10.a00.c13Awm1002.075.xs12.a00.c13Awm1002.075.xs14.a00.c13 ... Show all

Table of Contents
