USER MANUAL
Thank you for purchasing our products, please take some minutes to read this manual
before operating any of these laser projectors!
PR3000A-RGB
PR4000A-RGB
PR5000-RGB
PR5500-RGB
Notice
AVOID EYE OR SKIN EXPOSURE TO
DIRECT OR SCATTERED LIGHT
CLASS 4 LASER PRODUCT
PR7000-RGB
PR8000-RGB
Manufactured/ Certified by
Shenzhen Optlaser Technologies Co.,Ltd
PR9000-RGB
PR10000-RGB
www.optlaser.com
Advertisement
Table of Contents
Related Manuals for Opt PR3000A-RGB
Summary of Contents for Opt PR3000A-RGB
- Page 1 USER MANUAL Thank you for purchasing our products, please take some minutes to read this manual before operating any of these laser projectors! PR3000A-RGB PR7000-RGB PR9000-RGB PR4000A-RGB PR8000-RGB PR10000-RGB PR5000-RGB PR5500-RGB Manufactured/ Certified by Notice Shenzhen Optlaser Technologies Co.,Ltd AVOID EYE OR SKIN EXPOSURE TO www.optlaser.com...
-
Page 2: Table Of Contents
Content INTRODUCTION PACKING LIST UNPACKING INSTRUCTIONS GENERAL INFORMATION SAFETY NOTES LASER AND SAFETY NOTES 5, 6 LABELLING REFERENCE PROPER USAGE RIGGING 8, 9 OPERATIONS INTERLOCK DIAGRAM LCD Display Setting introduction PR4 SERIES INTRODUCTIONS of PR4 SERIES Specifications of PR4SERIES PR6 SERIES INTRODUCTIONS of PR6 SERIES Specifications of PR6 SERIES PR8 SERIES... -
Page 3: Introduction
INTRODUCTION Thank you for purchasing our products. To optimize the performance of your laser, please read these operating instructions carefully and familiarize yourself with the basic operations of this system. These instructions contain important safety information regarding the use and maintenance of this system as well. Please keep this manual with the unit, for future reference. -
Page 4: Safety Notes
SAFETY NOTES WARNING! These projectors are Class 4 laser products. It must never be used for audience-scanning applications. The output beam of the projector must always be at least 3 meters above the floor in the audience. See the Operating Instructions section for further information. Please read the following notes carefully! They include important safety information about the installation, usage, and maintenance of this product. -
Page 5: Laser And Safety Notes
LASER AND SAFETY NOTES STOP AND READ ALL THE LASER SAFETY NOTES BELOW Laser Light is different from any other light sources with which you may be familiar. The light from this product can cause eye and skin injury if not set up and used properly. Laser light is thousands of times more concentrated than light from any other kind of light source. -
Page 6: Labelling Reference
LABELLING REFERENCE LASER APERTURE... - Page 7 See the following reproductions of the product labels. All these labels must be intact and legible prior to be used on the projector. Hazard warning symbol Aperture label...
-
Page 8: Proper Usage
PROPER USAGE This product is for overhead mounting only. For safety purposes, this projector should be mounted on steady elevated platforms or sturdy overhead supports using suitable hanging clamps. In all cases, you must use safety cables. International laser safety regulations require that laser products must be operated in the fashion illustrated below, with a minimum of 3 meters (9.8 ft.) of vertical separation between the floor and the lowest laser light vertically. -
Page 9: Operations
OPERATIONS PD SERIES units come with diode-based only laser sources and all sources have beam correction ,thus have great beam show with analog FULL colors modulation. The PD SERIES units can be controlled over ILDA and have a bult-in memory with preset patterns ,also with SD-card slot for freely programs export onto it, that can be easily triggered through DMX. - Page 10 Several steps to start up the laser projector(s) 1. Use the included power cord to connect the laser device to a proper power outlet(AC100-240V, 50/60Hz) 2. Use one of the included keys( 2 sets included in the package, either one of them will work) to insert into the key-chassis and switch to the “ON”...
-
Page 11: Interlock Diagram
INTERLOCK CONNECTION DIAGRAM Green Red Yellow indicators Restart Ca ble to E-sto p box & laser projector Laser Projector #1 E STOP (Mus hroom sw itch ) Power In E-Stop Box Indicator(RED light-stay on-Emergency stop) Indicator(RED light-flash-Key switch off) Laser Projector #2 Indicator(YELLOW light-flash-cable disconnected) Indicator(GREEN light-stay on-laser ready emits) Indicator(RED&... -
Page 12: Lcd Display Setting Introduction
LCD Display Setting introduction Note: All the contents listed on the LCD display can be freely changed to the preferable status. The most important step is to “double-click” the menu knob to SAVE the preferred status when all selections/settings get done. (The other settings should be operated step by step as DMX setting reference as the guidance following) e.g. -
Page 13: Pr4 Series
PR4 SERIES Standard Verisons(without FB4 built-in) Front Size(mm) Rear Side Top view... -
Page 14: Introductions Of Pr4 Series
INTRODUCTIONS of PR4 SERIES (covered by masking plate) Laser aperture DO NOT look directly into this aperture once the masking plate gets loosen When this indicator is lit up the laser system is ready to emit the laser Laser Emission radiation as soon as it receives instructions from control software. -
Page 15: Specifications Of Pr4Series
Type of Laser Pure diode-based full colors(semiconductor diode laser systems) Class 4 Laser Classification 638nm 445nm Model λ 520nm PR3000A-RGB R/650mW+ G/800mW+ B/1500mW PR4000A-RGB R/1300mW+G/1000mW+ B/2000mW Laser Power(mW) PR5000-RGB R/1300mW+G/1200mW+ B/2500mW(465nm) PR5500-RGB R/1300mW+G/1200mW+ B/3000mW Except for the listed models, the PR4 also covers several other mono color projectors, such as 3W red, 5W green and 9W blue. -
Page 16: Pr6 Series
PR6 SERIES Standard Verisons(without FB4 built-in) 165.00 P US H IN /OU T MENU ILDA OUT IN TE R L OC K POWER: AC100~240V,50/60Hz FUSE Emission DMX IN DMX OUT Laser on 224.40... -
Page 17: Introductions Of Pr6 Series
INTRODUCTIONS of PR6 SERIES P US H IN /OU T MENU ILDA OUT IN TE R L OC K Emission Laser on POWER: AC100~240V,50/60Hz FUSE DMX IN DMX OUT (covered by masking plate) Laser aperture DO NOT look directly into this aperture once the masking plate gets loosen When this indicator is lit up the laser system is ready to emit the laser Laser Emission radiation as soon as it receives instructions from control software. -
Page 18: Specifications Of Pr6 Series
Specifications of PR6 SERIES Type of Laser Pure diode-based full colors(semiconductor diode laser systems) Class 4 Laser Classification Model 445nm 638nm 520nm PR7000-RGB R/2000mW+G/2000mW+B/3000mW PR8000-RGB Laser Power R/2000mW+G/3000mW+B/3000mW Scanning-system 40kpps ILDA@8° , Scan angle Max 60° Beam Size@aperture 3.5*6.5 mm <1.1 mRad Beam Divergence Modulation... -
Page 19: Pr8 Series
PR8 SERIES Standard Verisons(without FB4 built-in) Emission Laser on... -
Page 20: Introductions Of Pr8 Series
INTRODUCTIONS of PR8 SERIES 10 11 Emission Laser on (covered by masking plate) Laser aperture DO NOT look directly into this aperture once the masking plate gets loosen When this indicator is lit up the laser system is ready to emit the laser Laser Emission radiation as soon as it receives instructions from control software. -
Page 21: Specifications Of Pr8 Series
Specifications of PR8 SERIES Type of Laser Pure diode-based full colors(semiconductor diode laser systems) Class 4 Laser Classification Model 638nm λ 520nm PR10000-RGB R/3000mW+G/3000mW+B/4000mW Laser Power(mW) PR9000-RGB R/3000mW+G/3000mW+B/3000mW(465nm) Scanning-system 40kpps ILDA@8° , Scan angle Max 60° Beam Size@aperture 4.5*6.5 mm <1.1 mRad Beam Divergence Modulation... -
Page 22: Display Mode Introduction
Display mode introduction *Audio Mode(Sound mode): Preset programs triggered by sound, any proper sound will enable laser to output. *Auto Mode: The preset programs automatically display in Auto mode. *Prg Mode(SD playback in order): The preset/exported programs playback in sequence. Redact of the playlist please refer to SD Card Introduction. -
Page 23: Dmx Chart
DMX Chart CH Function Value Description Dimming 0-255 From the brightest to none. NONE 1-49 18 Channels mode Default （ ） Channels selection 50-99 33 Channels mode (bypassed) 100-149 47 Channels mode (bypassed) 150-255 6 Channels mode (bypassed) Graphics selection 0-255 Every value for one pattern 0-239... - Page 24 Original colors 8-15 White 16-23 24-31 Yellow 32-39 Green 40-47 Cyan 48-55 Blue 56-63 Violet Automatically changing among Red, Green and From slow to fast Blue 64-95 Colors Changing selection Automatically changing among cyan, yellow and From slow to fast violet 96-127 Automatically changing among White, Red,...
-
Page 25: Introductions Of Re-Alignments. Ref
INTRODUCTIONS OF RE-ALIGNMENTS. REF PR8 10W RGB. Laser combinations would be misaligned because of many external factors e.g. lasers got fallen from height, or shocking during transportation, long time of being used, etc. All of these factors would cause the well aligned lasers out of shape, misaligned. If there would be any necessary to re-do RGB alignments, there are many procedures to be completed in a high powered RGB laser module. -
Page 26: Maintenance Instruction
Maintenance Instruction The device is mostly installed in the location that there is dust, haze, and smoke, which are easily pollute the lens and decrease the output brightness; these particles also easily pollute the light case, fans, PCBA, block the heat dissipation, and reduce the stability of the electronic components;...
