- Page 1 MP_PS User Manual Remote Unit Model No: PS-R22207 MP_PS MID POWER Digital Radios 37dBm per Band...
-
Page 2: Revision History
Sunwave. The information furnished herein is believed to be accurate and reliable. However, no responsibility is assumed by Sunwave for its use or any infringements of patents or other rights of third parties resulting from its use. -
Page 3: Table Of Contents
Wall Installation (Side on the Wall) ..........................31 MP_PS Wall Mounting Dimension Spacing ........................37 Pole Installation ................................38 Rack Installation ................................39 MP_PS Wall Mounting Dimension Spacing ........................44 Optical Connection ................................45 Contact us today: www.sunwave.com cf_support@sunwave.com © Sunwave MP_PS_User Manual | 3 of 46... - Page 4 Mid POWER Digital Radio Optical Transceiver Module .............................. 45 Single Port Bidirectional SFP Transceiver ........................45 Dual Port SFP Transceiver ............................. 45 Optical Indicator ................................46 Contact us today: www.sunwave.com cf_support@sunwave.com © Sunwave MP_PS_User Manual | 4 of 46...
-
Page 5: Preface
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. Contact us today: www.sunwave.com cf_support@sunwave.com © Sunwave MP_PS_User Manual | 5 of 46... -
Page 6: Site Considerations
Maximum humidity: 85% AU Operating Temperature range: -10°C to +50°C MP-PS Operating Temperature range: -40°C to +50°C Storage Temperature range: -40°C to +70°C Contact us today: www.sunwave.com cf_support@sunwave.com © Sunwave MP_PS_User Manual | 6 of 46... -
Page 7: Warning Marks
ALWAYS disconnect all lines and power connections before servicing or disassembling this equipment. NEVER touch the surface after power on the devices. For performance and safety reasons, NEVER disassemble and remodel the devices. Contact us today: www.sunwave.com cf_support@sunwave.com © Sunwave MP_PS_User Manual | 7 of 46... -
Page 8: Installation Preparation
Immediately contact the transportation carrier and notify them of the damage. File a claim with the carrier once you determine the extent of any damage. Return it to SUNWAVE’s nearest RMA facility and contact SUNWAVE for RMA processing. Unpacking the Device If the container appears to be in satisfactory condition: Ensure both user and supplier representatives are in attendance during shipment inspection. -
Page 9: Verifying The Contents
Verify that the contents and quantities agree with the Delivery Packing List. Check the device model against the Delivery Packing List. Notify SUNWAVE immediately if any discrepancies are discovered, to verify whether the complete and correct shipment has been received. -
Page 10: Installation Tools
FAN Cooling: You can mount the fan between the bottom of the device and any other. Maintain 2U clearance between the bottom of the device and any other. Contact us today: www.sunwave.com cf_support@sunwave.com © Sunwave MP_PS_User Manual | 10 of 46... -
Page 11: Installing The Access Unit (Au)
Mid POWER Digital Radio Installing the Access Unit (AU) Contact us today: www.sunwave.com cf_support@sunwave.com © Sunwave MP_PS_User Manual | 11 of 46... -
Page 12: Accessories List
Attach the 19" mounting brackets at the front of the AU, using 4 screws M3×6 per bracket and the Phillips screwdriver. Observe the orientation of the brackets. Contact us today: www.sunwave.com cf_support@sunwave.com © Sunwave MP_PS_User Manual | 12 of 46... - Page 13 Mid POWER Digital Radio Contact us today: www.sunwave.com cf_support@sunwave.com © Sunwave MP_PS_User Manual | 13 of 46...
- Page 14 Mid POWER Digital Radio Recommended attaching the sliding rails to rack. (Not included in delivery). Contact us today: www.sunwave.com cf_support@sunwave.com © Sunwave MP_PS_User Manual | 14 of 46...
- Page 15 Mid POWER Digital Radio Place the AU in the rack and secure the AU using 2 screws M6×16 on both sides and the Phillips screwdriver. Contact us today: www.sunwave.com cf_support@sunwave.com © Sunwave MP_PS_User Manual | 15 of 46...
- Page 16 (44mm) of free space below each unit with fan occupied in the middle. Otherwise, the device temperature may rise and affect the service life of the device. Contact us today: www.sunwave.com cf_support@sunwave.com © Sunwave MP_PS_User Manual | 16 of 46...
- Page 17 Mid POWER Digital Radio Connect and lock the power cable at the AU rear side. Connect and screw the ground wire at the AU rear side. Contact us today: www.sunwave.com cf_support@sunwave.com © Sunwave MP_PS_User Manual | 17 of 46...
-
Page 18: Wall Installation
Rotate the handles 90°and attach them at the rear of the AU, using 4 screws M3×6 per bracket and the Phillips screwdriver. Observe the orientation of the brackets. Contact us today: www.sunwave.com cf_support@sunwave.com © Sunwave MP_PS_User Manual | 18 of 46... - Page 19 Mark 4 x ∅6.8mm drilling holes sites for the hanger to be attached to the wall. Drill 4 holes at the marked sites using percussion drill and embed 4×∅10 plastic expansion pipes. Note: H=70mm. Fasten the case with 4×M6 expansion bolt. Contact us today: www.sunwave.com cf_support@sunwave.com © Sunwave MP_PS_User Manual | 19 of 46...
- Page 20 Mid POWER Digital Radio Connect and lock the power cable at the AU rear side Connect and screw the ground wire at the AU rear side Contact us today: www.sunwave.com cf_support@sunwave.com © Sunwave MP_PS_User Manual | 20 of 46...
-
Page 21: Au Mounting Dimension Spacing
Mid POWER Digital Radio AU Mounting Dimension Spacing Contact us today: www.sunwave.com cf_support@sunwave.com © Sunwave MP_PS_User Manual | 21 of 46... -
Page 22: Rf Connection
Module 4 Duplexer Interface QMA Female Module 3 Duplexer Interface QMA Female Module 2 Duplexer Interface QMA Female Module 1 Duplexer Interface QMA Female Electric Power Line Interface Grounding Contact us today: www.sunwave.com cf_support@sunwave.com © Sunwave MP_PS_User Manual | 22 of 46... -
Page 23: Installing The Remote Unit (Mp_Ps)
Mid POWER Digital Radio Installing the Remote Unit (MP_PS) MP_PS Accessories Contact us today: www.sunwave.com cf_support@sunwave.com © Sunwave MP_PS_User Manual | 23 of 46... -
Page 24: Wall Installation (Back On The Wall)
Attach and fasten the handle to the side of MP_PS with screws M6×14 using T5 Wrench. Attach and fasten the Bracket I to the back of MP_PS with screws M6×14 using T5 Wrench. Contact us today: www.sunwave.com cf_support@sunwave.com © Sunwave MP_PS_User Manual | 24 of 46... - Page 25 Attach the dowels, expansion screws or the like and fasten the Bracket II to the wall. Tips: use Bracket II as a reference to control each devices’ separation distance before hanging and locking MP_PS up. Contact us today: www.sunwave.com cf_support@sunwave.com © Sunwave MP_PS_User Manual | 25 of 46...
- Page 26 Mid POWER Digital Radio Hang the MP_PS on the mounting bracket II and fasten with nuts M10. Contact us today: www.sunwave.com cf_support@sunwave.com © Sunwave MP_PS_User Manual | 26 of 46...
- Page 27 Mid POWER Digital Radio Fasten the Bracket I and II with screws M6×14. Contact us today: www.sunwave.com cf_support@sunwave.com © Sunwave MP_PS_User Manual | 27 of 46...
- Page 28 Mid POWER Digital Radio Connect and lock the power cable Connect and screw the ground cable Contact us today: www.sunwave.com cf_support@sunwave.com © Sunwave MP_PS_User Manual | 28 of 46...
- Page 29 Mid POWER Digital Radio 10. Connect and tighten the waterproof network cable Contact us today: www.sunwave.com cf_support@sunwave.com © Sunwave MP_PS_User Manual | 29 of 46...
- Page 30 Mid POWER Digital Radio 11. Connect and tighten the waterproof optical fibre Contact us today: www.sunwave.com cf_support@sunwave.com © Sunwave MP_PS_User Manual | 30 of 46...
-
Page 31: Wall Installation (Side On The Wall)
Mid POWER Digital Radio Wall Installation (Side on the Wall) Contact us today: www.sunwave.com cf_support@sunwave.com © Sunwave MP_PS_User Manual | 31 of 46... - Page 32 Attach and fasten the handle to the side of MP_PS with screws M6×14 using T5 Wrench. Attach and fasten the Bracket I to the left side of MP_PS with screws M6×14 using T5 Wrench. Contact us today: www.sunwave.com cf_support@sunwave.com © Sunwave MP_PS_User Manual | 32 of 46...
- Page 33 Attach the dowels, expansion screws or the like and fasten the Bracket II to the wall. Tips: use Bracket II as a reference to control each devices’ separation distance before hanging and locking MP_PS up. Contact us today: www.sunwave.com cf_support@sunwave.com © Sunwave MP_PS_User Manual | 33 of 46...
- Page 34 Mid POWER Digital Radio Hang the MP_PS on the mounting bracket II and fasten with nuts M10. Contact us today: www.sunwave.com cf_support@sunwave.com © Sunwave MP_PS_User Manual | 34 of 46...
- Page 35 Mid POWER Digital Radio Fasten the Bracket I and II with screws M6×14. Contact us today: www.sunwave.com cf_support@sunwave.com © Sunwave MP_PS_User Manual | 35 of 46...
- Page 36 Mid POWER Digital Radio Connect and lock the power cable Connect and screw the ground cable Contact us today: www.sunwave.com cf_support@sunwave.com © Sunwave MP_PS_User Manual | 36 of 46...
-
Page 37: Mp_Ps Wall Mounting Dimension Spacing
Mid POWER Digital Radio MP_PS Wall Mounting Dimension Spacing Contact us today: www.sunwave.com cf_support@sunwave.com © Sunwave MP_PS_User Manual | 37 of 46... -
Page 38: Pole Installation
Hang the MP_PS on the mounting bracket and fasten with nuts M10. Connect the ground cable and power cable. Note: The diameter of Pole shall not be over 110mm or less than 55mm. Contact us today: www.sunwave.com cf_support@sunwave.com © Sunwave MP_PS_User Manual | 38 of 46... -
Page 39: Rack Installation
Mid POWER Digital Radio Rack Installation Contact us today: www.sunwave.com cf_support@sunwave.com © Sunwave MP_PS_User Manual | 39 of 46... - Page 40 Mid POWER Digital Radio Attach and fasten the Bracket III to the Standard 19’ Rack with screws Note: Please purchase Bracket III for rack installation separately. Contact us today: www.sunwave.com cf_support@sunwave.com © Sunwave MP_PS_User Manual | 40 of 46...
- Page 41 Attach and fasten the handle to the side of MP_PS with screws M6×14 using T5 Wrench. Attach and fasten the Bracket I to the back of MP_PS with screws M6×14 using T5 Wrench. Contact us today: www.sunwave.com cf_support@sunwave.com © Sunwave MP_PS_User Manual | 41 of 46...
- Page 42 Mid POWER Digital Radio Hang the MP_PS on the mounting bracket and fasten with nuts M10. Contact us today: www.sunwave.com cf_support@sunwave.com © Sunwave MP_PS_User Manual | 42 of 46...
- Page 43 Mid POWER Digital Radio Connect the ground cable and power cable. Connect and screw the ground cable Contact us today: www.sunwave.com cf_support@sunwave.com © Sunwave MP_PS_User Manual | 43 of 46...
-
Page 44: Mp_Ps Wall Mounting Dimension Spacing
Mid POWER Digital Radio MP_PS Wall Mounting Dimension Spacing Contact us today: www.sunwave.com cf_support@sunwave.com © Sunwave MP_PS_User Manual | 44 of 46... -
Page 45: Optical Connection
B. The optical receiver and transmitter terminals of the optical module can be determined by the triangular mark on the optical module. The triangular mark in the yellow box and the red and blue lines indicate the optical fibre connections. Contact us today: www.sunwave.com cf_support@sunwave.com © Sunwave MP_PS_User Manual | 45 of 46... - Page 46 Figure below. When the optical module is unplugged or not synchronized, the indicators are red as shown in the left pair of indicators. Check whether both indicators turn green after connecting one pair of optical modules. If the indicators are red, the terminal has not synchronized. Contact us today: www.sunwave.com cf_support@sunwave.com © Sunwave MP_PS_User Manual | 46 of 46...
