- Page 1 PanelPC Hardware installation manual USER MANUAL...
- Page 2 Disclaimers This manual and other documents, including printed and electronic versions, are for reference only. ADP has done its best to ensure the accuracy and completeness of the information in this manual. This manual and other documents are provided on an "as-is" basis. However, ADP...
-
Page 3: Table Of Contents
CONTENTS ▌ Traditional Chinese Introduction to the ADP Panel PC Chapter 1 External composition Hardware component specifications Hardware connections and settings Chapter 2 Wall mount bracket Panel PC installation and cabling specifications Recommend installation locations for Panel PC Panel PC cabling system structure... -
Page 4: Service Provider
WELCOME Comprehensive space management and information service provider ADP Panel PC is committed to integrating the best technology and services with the service mechanisms required by space and developing smart space service terminals, all to provide users with all-round superior space management solutions. -
Page 5: Introduction To The Adp Panel Pc
Introduction to the ADP Panel PC Chapter External composition Camera and fill light Touchscreen Microphone NFC card reader LED indicator light strip... - Page 6 LED indicator lamp Speakers VESA Mount 75mm X Product 75mm label Anti-theft lock slot DC power input mini-USB USB 3.0 Restart button DIDO POE ethernet USB 2.0 ADB button port...
-
Page 7: Hardware Component Specifications
Hardware component specifications LCD panel specifications Dimensions 10-inch LED backlit panel Contrast 800:1 Brightness 350 nits Viewing angle -85° - 85° (horizontal); -85° - 85° (vertical) Touchscreen Capacitive touch monitor; supports multi-touch System specifications Processor Quad-Core ARM Cortex-A55 CPU 1.8 Hz Memory 16 GB LPDDR3 Storage device... -
Page 8: Hardware Connections And Settings
Hardware connections and settings Chapter Wall mount bracket Panel PC back bracket Wall mount bracket... - Page 9 Accessory bag and installation manual Hexalobular socket anti-theft screw Hardware installation manual...
-
Page 10: Panel Pc Installation And Cabling Specifications
Panel PC installation and cabling specifications Recommend installation locations for Panel PC Suitable height for installation based on average height: when installing the Panel PC, the lower edge of the device body should be 136cm above ground level; height can also be adjusted according to the customer's actual usage. -
Page 11: Reference For Matching Electric Lock Forms
Reference for matching electric lock forms Electric bolt lock Electric strike lock Model shear lock Electromagnetic lock Electric lock must be selected in accordance with the onsite door material and specifications. When choosing an electric lock, pay attention to the following: Door type: Opens in, opens out, opens both in and out, side-pull or sliding door, ... -
Page 12: Detailed Cabling Diagram Of Electric Lock/Output Button And Panel Pc
Detailed cabling diagram of electric lock/output button and Panel PC Electric lock Open door button 1: Electric lock DC 12V 2: Electric lock ground cable 3: Door status detection NO 4: Door status detection COM 5: Open door button detection NO 6: Open door button detection COM... -
Page 13: Panel Pc Back Bracket And Device Body Installation Diagram
Panel PC back bracket and device body installation diagram ① Step First decide whether the back bracket is to be placed in the middle, close to the left wall, or close to the right wall. You can determine the position of the back bracket based on the cabling direction. - Page 14 ② ③ Step Step Pull the rubber off of the bracket and cut the After arranging cabling through the back adhesive back. panel, confirm the horizontal position, then peel off the back adhesive and stick it to the wall. Get suitable self-tapping screws or screws that fit with the material of the wall (stud) and fasten to the wall.
- Page 15 ⑤ Step Drill a hole, and use a hammer to pry it open. Then use pliers to twist it open, and sand the sharp edges to avoid damaging the wire. Close to left wall Close to right wall...
- Page 16 ⑥ Step After arranging cabling through the back panel, confirm the horizontal position, then peel off the back adhesive and stick it to the wall. Get suitable self-tapping screws or screws that fit with the material of the wall (stud) and fasten to the wall.
- Page 17 ⑦ Step Take the rubber off of the back of the device. Connect the Ethernet cable and control cable, insert the tenon from top to bottom, and screw in the anti-theft screw at the bottom. Close to left/right wall installation complete. Close to left wall Wall surface Remove the...
-
Page 18: Appendix 1 Dio Activity Meter
DIO activity meter Appendix DIO activity meter Mode Figure Explanation Keep DO at Hi Press the button Release the button DI status DO status Keep DO at Lo Press the button Release the button DI status DO status DI ↓,DO=H 1. - Page 19 DI ↑, DO=L 1. This mode is applicable when door opening Press the button Release the button button connected to DI is Normal Open electric lock connected to DI status DO is unpowered to unlock. 2. When DI↑, start counting DO status X(s).
- Page 20 Thanks for using the Panel PC system For more information, service, and support See the following resources or use the following channels to obtain more information on Panel PC security, software, services, and support. AUO Display Plus website https://www.auodplus.com/en-global About FCC compliance FCC ID:2A639-P1000-R This device complies with part 15 of the FCC Rules.
