Summary of Contents for ENEL JuiceBox 3.0 NA
- Page 1 JuiceBox 3.0 NA Wi-Fi / Bluetooth Module Manual ENGLISH...
-
Page 2: Block Diagram
Scope This document is applied to the Shielded Ultra Small Wi-Fi® 11b/g/n + Bluetooth® 5.1 Module, Model No. 1DX, of the manufacturer Murata Manufacturing Co. Ltd. Description Type 1DX is a module based on Infineon CYW4343W combo chipset which supports Wi-Fi® 802.11b/g/n + Bluetooth®... - Page 3 Pictures Figure 2 - Main Board (Wi-Fi/Bluetooth module encircled) Figure 3 - Wi-Fi/Bluetooth module (detail)
- Page 4 Dimensions Structure...
-
Page 5: Pin Layout
Pin Layout... -
Page 6: Antenna Check
Rating min. typ. max. unit Specification Temperature Range deg.C Specification Voltage VBAT VDDIO 1.71 1.8 or 3.3 3.63 Antenna Check The concrete contents of a check are the following three points: It is the same type as the antenna type of antenna specifications. Confirm the same size as the Gerber file. - Page 7 Radio Certification Information Enel X Way FCC ID: 2A5OV-LB1DX Enel X Way ISED ID: 28561-LB1DX Federal Communications Commission (FCC) compliance statements This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
-
Page 8: Industry Canada (Ic) Compliance Statements
Industry Canada (IC) compliance statements This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; (2) This device must accept any interference, including interference that may cause undesired operation of the device. -
Page 9: Fcc Compliance Statement
— Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. — Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by Enel X Way could void the user's authority to operate the equipment. FCC ID... -
Page 10: Compliance Statement
Formal notices required by the Industry Canada (“IC”) Compliance Statement This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: 1. This device may not cause interference. 2.
