- Page 1 SFL090 INSTRUCTION MANUAL For 37-82" TV If you have any questions along the way, just message to us. We’re ready to help! USA-C1...
- Page 2 CAUTION: PLEASE READ ENTIRE MANUAL PRIOR TO USE AND SAVE THESE INSTRUCTIONS Before getting started, let’s check below lists to make sure it is just right for you! MAX:600mm/23.62" (MIN:150mm/5.91") Check your TV VESA is within No? This mount is NOT compatible. Min and Max size MAX:400mm/15.75"...
-
Page 3: Wall Plate
Dimensions TV INTERFACE WALL PLATE MAX:600mm/23.62" MIN:150mm/5.91" 609.6mm/24" 508mm/20" 406.4mm/16" 304.8mm/12" 203.2mm/8" MAX:400mm/15.75" 417mm/16.42" MIN:100mm/3.94" 164mm/6.46" 222mm/8.74" 661mm/26" SIDE VIEW 33mm/1.30"... -
Page 4: Parts And Hardware
Parts and Hardware WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact Customer Service. - Page 5 Parts and Hardware for STEP 2 Lag Bolt Washer Level M6x60mm TV Screws Spacers M4x12mm M4x30mm 10mm M8x22mm 2.5mm M6x15mm M6x35mm Concrete wall anchor (NOT INCLUDED) Contact us at telephone 1-800-558-5930 or message to us to have these additional pieces M8x25mm M8x45mm Concrete Wall Anchor...
- Page 6 Assemble Wall plate STEP 3 Screw driver Tighten Loosen Wall plate(Left) Wall plate...
-
Page 7: Step 1 Attach Brackets To Tv
STEP 1 Attach Brackets to TV 1-1 Select TV Screws... - Page 8 1-2 Figure out the suitable position of brackets HIGH MOUNTING HOLES LOW MOUNTING HOLES TV BRACKETS MUST BE LEVEL INSTALL UP/DOWN IF NEEDED...
- Page 9 1-4 Attach the TV Plate 1-3 Need Spacer? No, choose suitable screws and washers. Yes, choose suitable screws, washers and spacers.
- Page 10 STEP 2A Attach Wall Plate to Wall Wood Stud Option CAUTION: Avoid potential personal injury or property damage! ● Drywall covering the wall, must not exceed 5/8 in. (16 mm) ● Minimum wood stud size: common 2 x 4 in. (51 x 102 mm) nominal 1½ x 3½ in. (38 x 89 mm) ●...
- Page 11 3. Drill pilot holes using a 1/8 in. (3 mm) diameter drill bit. IMPORTANT: Pilot holes must be drilled to a depth of 2.5 in. (64 mm). Be sure to drill into the center of the studs. 4. Install wall plate using lag bolts .
- Page 12 STEP 2B Attach Wall Plate to Solid Concrete Wall CAUTION: Avoid potential personal injury or property damage! ● Mount the wall plate assembly unit directly onto the concrete surface ● Minimum solid concrete thickness: 8 in. (203 mm) 1. Position the mounting template on the wall at your desired height. Level the mounting template and mark the hole locations.
- Page 13 3. Insert anchors. CAUTION: Be sure the anchors are seated flush with the concrete surface. 4. Install wall plate using lag bolts . Tighten the lag bolts only until they are pulled firmly gainst the wall plate. CAUTION: Improper use could reduce the holding power of the lag bolt. DO NOT over-tighten the lag bolts.
- Page 14 STEP 3 Wall Plate Installation Integrity Test Before hanging TV, please try to pull the mount to make sure that it has been assembled on the wall tightly. 132 LBS (60 kg)
- Page 15 STEP 4 Hang and Secure TV to Wall Plate TV Brackets Pull down...
- Page 16 STEP 5 Take Down the TV from the Mount Pull down the straps...
