The Collection By Michael Miller Celena MK3 Installation, Maintenance & User Instructions

Conventional flue log effect gas fire
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Celena MK3
CONVENTIONAL FLUE LOG EFFECT GAS FIRE
Installation, Maintenance & User Instructions
Hand these instructions to the user
Model No. DPRL**SN3 & DPRL**RN3 are only for use on Natural Gas
(G20) at a supply pressure of 20 mbar in G.B. / I.E.
** denotes cosmetic variant

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Celena MK3 and is the answer not in the manual?

Questions and answers

Related Manuals for The Collection By Michael Miller Celena MK3

Summary of Contents for The Collection By Michael Miller Celena MK3

  • Page 1 Celena MK3 CONVENTIONAL FLUE LOG EFFECT GAS FIRE Installation, Maintenance & User Instructions Hand these instructions to the user Model No. DPRL**SN3 & DPRL**RN3 are only for use on Natural Gas (G20) at a supply pressure of 20 mbar in G.B. / I.E.
  • Page 2 Information Requirements for Commission Regulation (EU) 2015/1188 Model Identifier DPRL**SN3 DPRL**RN3 Indirect Heating Functionality Direct Heat Output 4.0kW 4.1kW Indirect Heat Output Not Applicable Not Applicable Fuel Natural Gas Natural Gas (G20) (G20) NOx Emissions 130mg/kWh 130mg/kWh Nominal Heat Output 4.0kW 4.1kW Minimum Heat Output (Indicative, all models)

  • Page 3: Table Of Contents

    CONTENTS Section 1 Information and Requirements PAGE Appliance Information Conditions of Installation Flue and chimney suitability Fireplace / surround suitability Shelf position Chimney inspection Fire place opening / catchment space Chair bricks Metal flue boxes Fitting with direct flue connection 1.10 Spillage monitoring system Section 2...

  • Page 4: Information And Requirements

    SECTION 1 INFORMATION AND REQUIREMENTS APPLIANCE INFORMATION Model DPRL**SN3 DPRL**RN3 Gas Type Main injector (1 off) Size 1.80 Size 1.80 Pilot Type SIT NG 9055 ERTA-PG-82-330/2 Max. Gross Heat Input : 5.8kW 5.8kW Min. Gross Heat Input : 3.5kW 3.5kW Cold Pressure : 20.0 +/-1.0 mbar 20.0 +/-1.0 mbar Ignition :...

  • Page 5: Installation Requirements

    INSTALLATION REQUIREMENTS CONDITIONS OF INSTALLATION It is the law that all gas appliances are installed only by a GAS SAFE Registered Installer, in accordance with these installation instructions and the Gas Safety (Installation and Use) Regulations 1998 as amended. Failure to install appliances correctly could lead to prosecution.

  • Page 6: Fireplace / Surround Suitability

    FIREPLACE / SURROUND SUITABILITY The fire must must not be installed directly onto carpet or other combustible floor materials. If a heating appliance is fitted directly against a wall combustible material must be removed from behind it. Soft wall coverings such as blown vinyl, wall paper etc. could be affected by the rising hot air and scorching and/or discoloration may result.

  • Page 7: Fire Place Opening / Catchment Space

    certificated flue terminal or cowl suitable for the relevant flue type should be considered. A spillage test must always be carried out during commissioning of the appliance. FIRE PLACE OPENING 1.6.1 Fireplace Opening for Engine Only Applications The front opening of the fire place must be between 580mm and 600mm wide, between 580mm and 600mm high and 300mm deep.
  • Page 8 1.6.3 Fireplace Opening for Pablo, Boticelli & Angelo Surround Types - If fitting this fire with a surround supplied from “The Collection by Michael Miller” then the fireplace opening of width / height of 580mm minimum to 600mm maximum needs to be prepared at differing heights dependent upon which surround type is to be installed.

  • Page 9: Chair Bricks

    Table A - Installation Depth Requirements for The Collection Celena MK3 being installed into a brick built chimney, requiring 12.0 litres of debris collection volume (figure 4). Opening Width (mm) Minimum Depth Required (mm) 580-600mm 300mm Fig. 4 Depth Required...

  • Page 10: Spillage Monitoring System

    1.10 SPILLAGE MONITORING SYSTEM This appliance is fitted with an atmosphere sensing spillage monitoring system in the form of an oxygen sensing burner. This is designed to shut the fire off in the event of a partial or complete blockage of the flue causing a build up of combustion products in the room in which the fire is operated.

  • Page 11: Installation Of Fire

    SECTION 2 INSTALLATION OF FIRE UNPACKING THE FIRE Carefully lift the fire out of the carton. Remove the loose item packaging, check the contents as listed below :- NOTE : DO NOT UNDER ANY CIRCUMSTANCES USE THIS APPLIANCE IF THE GLASS PANEL IS BROKEN OR NOT SECURELY FIXED TO THE FIREBOX.
  • Page 12 2.2.1 Remove the front grill by lifting clear. On remote control models unplug the battery box at the white terminal block as shown below in figure 5. Fig. 5 Battery box Front grill 2.2.2 Remove the two off screws which secure the glass panel retaining bracket as shown below in figure 6, then tilt the glass panel forward to remove it.
  • Page 13 2.2.3 Store the glass panel in a safe place. 2.2.4 Re-assemble in reverse order when re-fitting the glass assembly. 2.2.5 DO NOT OPERATE THE FIRE WITHOUT THE GLASS PANEL IN POSITION OR NOT CORRECTLY LOCATED.
  • Page 14 2.2.6 Remove the front fuel-bed support grill by lifting clear as shown below in figure 7. Fig. 7 Front grill 2.2.7 Remove the rear fuel-bed support grill by firstly tilting towards the rear vertically to remove as shown below in figure 8. Fig.
  • Page 15 2.2.8 Remove the gas inlet cover plate by removing the 4 off screws as shown below in figure 9. Fig. 9 Gas supply cover plate 2.2.9 The burner unit is secured by 4 off screws as shown below in figure 10, remove the 4 off screws and lift the burner unit clear as shown overpage in figure 11.
  • Page 16 2.2.10 The burner can now be lifted clear as shown below in figure 11. Fig. 11 Burner unit removed by lifting vertically 2.2.11 The gas supply can be routed into the fire from the rear left, see figure 12 below for dimensional information regarding position and route of gas supply pipe.
  • Page 17 2.2.12 Store the removed burner components in a safe position. 2.2.13 The gas connection to the appliance should be made to the isolating / inlet elbow using 8mm rigid tubing. There must be no soldered joints within the firebox. Use the grommet supplied in the loose items pack to seal the knock-out removed from the firebox where the gas pipe enters the firebox.
  • Page 18 Fit the wallplugs provided and screw the fixing eyes securely into the rear of the fire opening. If the clearance at the rear of the fire is at the minimum specified for a precast flue application, it may be necessary to bend over the lower fixing eyes after screwing them fully in to the rear of a pre-cast starter block.
  • Page 19 The other firebox fixing method is as follows :- 2.2.24 In installations where the cable method is not suitable (e.g. loose masonary in rear of fire opening) the firebox can be secured to the opening using four screws and wall plugs (not provided). Below (figure 14) is a diagram to indicate the hole centre positions available on the firebox to facilitate the screw fixing to the fireplace / surround.

  • Page 20: Gas Tightness And Inlet Pressure

    GAS TIGHTNESS AND INLET PRESSURE 2.3.1 Remove the pressure test point screw from the inlet elbow and fit a manometer. 2.3.2 Turn on the main gas supply and carry out a gas tightness test. 2.3.3 See section 3.3/3.6 for full details of the operating method for the fire. The fire will then commence its ignition sequence and will light to high.

  • Page 21: Installing The Pablo Surround

    INSTALLING THE “PABLO” SURROUND 2.4.1 Unpack the surround from the wooden crate, check all parts are present as per figure 15 overpage and carefully store the components. 2.4.2 The underside of the hearth should be painted with a weak PVA (8 parts water to 1 part PVA).
  • Page 22 Fig. 15 - “Pablo” Surround Shelf Top Section L/H Leg L/H Infill Section Top Infill Section R/H Infill Section Stub Hearth R/H Leg Hearth Panel Bottom Infill Section NOTE : It is recommended Contents of Pablo surround :- that a spillage test is completed before fixing / 1 off hearth panel sealing the fire surround...

  • Page 23: Installing The Boticelli Surround

    INSTALLING THE “BOTICELLI” SURROUND 2.5.1 Unpack the surround from the wooden crate, check all parts are present as per figure 16 overpage and carefully store the components. 2.5.2 The underside of the hearth should be painted with a weak PVA (8 parts water to 1 part PVA).
  • Page 24 Fig. 16 - Boticelli Surround Shelf Top Section L/H Leg Shelf Top Infill Section Top Infill Section L/H Infill Section R/H Infill Section Stub Hearth R/H Leg Hearth Panel Bottom Infill Section NOTE : It is recommended Contents of Boticelli surround :- that a spillage test is completed before fixing / 1 off hearth panel...

  • Page 25: Installing The Angelo Surround

    INSTALLING THE “ANGELO” SURROUND 2.6.1 Unpack the surround from the wooden crate, check all parts are present as per figure 17 overpage and carefully store the components. 2.6.2 The underside of the hearth should be painted with a weak PVA (8 parts water to 1 part PVA).
  • Page 26 Fig. 17 - “Angelo” Surround Shelf Top Section Shelf Top Infill Section L/H Leg Top Infill Section L/H Infill Section R/H Infill Section Stub Hearth R/H Leg Hearth Bottom Infill Section Contents of Angelo surround :- 1 off hearth panel 1 off R/H leg 1 off L/H leg 1 off R/H infill section...

  • Page 27: Checking Mechanical Fixing Of All Surround Types

    2.10 CHECKING MECHANICAL FIXING OF SURROUND COMPONENTS 2.10.1 Ensure that the surround components as shown below are mechanically secured as indicated, this is required in accordance with the latest revision of BS 1251 : 2015 Open Fireplace Components. Fig. 18 - “Pablo” Surround Fig.

  • Page 28: Fitting The Fuel-Bed Logset

    FITTING THE FUEL-BED LOGSET 3.1.1 Position Log “A” benind the burner as shown below in figure 21 Fig. 21 Log “A” 3.1.2 Position 2 off charred log pieces as shown below in figure 22. Fig. 22 Charred Pieces...
  • Page 29 3.1.3 Position Log “B” onto the left hand burner as shown below in figure 23, using the slot in the bottom of the log as a guide for placement. Fig. 23 Log “B” 3.1.4 Position Log “C” onto the right hand burner as shown below in figure 24, using the slot in the bottom of the log as a guide for placement.
  • Page 30 3.1.5 Position the grey chippings across the front fuel-bed support as shown below in figure 25 Fig. 25 Grey Chips 3.1.6 Position the Embaglow onto the burner base as shown below in figure Fig. 26 DO NOT POSITION ANY EMBAGLOW MATERIAL IN CLOSE PROXIMITY TO THE PILOT ASSEMBLY Embaglow...
  • Page 31 3.1.7 Position the two off small charred pieces as shown below in figure 27. Fig. 27 Small Charred Pieces 3.1.8 Position Log “D” at the left hand side of the fuel-bed, locating onto cut- out on Log “B” to support it as shown below in figure 28. Fig.
  • Page 32 3.1.9 Position Log “E” at the right hand side of the fuel-bed, locating on cut out on Log “C” to support it as shown below in figure 29. Fig. 29 Log “E” 3.1.10 Position Log “F” at the front of the fuel-bed, as shown below in figure Fig.

  • Page 33: Fitting The Batteries - Remote Control Models

    FITTING THE BATTERIES - REMOTE CONTROL MODELS ONLY 3.2.1 The battery pack is located under the front grill as shown below in figure Fig. 31 Battery box location 3.2.2 Lift battery pack from its retaining bracket, remove rear cover (held in position by screw) and then fit 3 off AA batteries. Replace cover and then re-position battery pack within retaining bracket.

  • Page 34: Operation Of The Fire - Remote Control Models

    OPERATION OF THE FIRE - REMOTE CONTROL MODELS IMPORTANT : IF THE BURNER IS EXTINGUISHED FOR ANY REASON YOU MUST ENSURE THAT YOU WAIT A FULL FIVE MINUTES BEFORE ATTEMPTING TO RE-LIGHT THE FIRE. The product is controlled by the remote handset supplied with the fire. 3.3.1 SETTING THE TIME, DATE &...
  • Page 35 Fig. 33 24hr or 12 hr display, press the + or - buttons as shown to toggle between these two settings + button - button 3.3.1.4 When the 24hr or 12hr time display option has been chosen and you are ready to confirm the setting you want press the SET button on the handset to progress to setting the day of the week as shown overpage in figure 34.
  • Page 36 Fig. 34 Day of the week Hour and Minute display, press the + or - buttons as shown to toggle between these two settings and set the correct time of day. + button - button 3.3.1.7 As shown above in figure 34 the time on the handset can now be set by using the + and - buttons to change the hour to the correct hour then press SET to store and to move to setting the minute.
  • Page 37 Fig. 35 Celsius or Fahrenheit temperature display, press the + or - buttons as shown to toggle between these two settings and set the correct time of day. + button - button 3.3.1.9 The control is now ready for use with the burner. 3.3.1.10 If the handset is misplaced you can “page it”...

  • Page 38: Lighting The Fire - Remote Control Models

    LIGHTING THE FIRE - REMOTE CONTROL MODELS 3.4.1 Ensure valve power isolation switch is in the “on” position on the valve and that the time, date & temperature display settings as shown in section 3.3 have been completed. Hold the handset with one hand ensuring your hand is wrapped around the back and that your hand is in contact with both sides of the handset.
  • Page 39 Fig. 37 - “PILOT” displayed “PILOT” displayed on handset during ignition sequence (typically takes two seconds) Fig. 38 - “MAX” & large flame symbol displayed “MAX FLAME” displayed on handset when burner is lit to maximum rate...

  • Page 40: Lighting The Appliance - Remote Control Models

    LIGHTING THE APPLIANCE - REMOTE CONTROL MODELS  (CONTINUED) 3.4.3 To decrease the heat input level of the burner hold the handset as described in section 3.4.1 to unlock the keypad then press and release the - button. Pressing and releasing the - button will lower the heat input level one step at a time.

  • Page 41: Advanced Settings Menu Of The Remote Control

    3.4.6 If you are not intending to use the fire for a long period (i.e. over the summer months) the battery life can be extended by disconnecting the battery pack from the valve, see section 2.2.1 3.4.7 In the event of loss of the remote handset, as a backup the fire can be turned off by pressing the on/off switch located below the grill at the base of the fire.
  • Page 42 Fig. 40 MAN & Zzz symbols flashing illuminated Press mode button to scroll through to MAN & Zzz symbols, then press and release the set button to put the control into the manual snooze mode. 3.5.1.6 Pressing the set button again will now show you the snooze time period remaining.
  • Page 43 Fig. 41 Handset showing snooze time period remaining, this can be adjusted from 1 minute to 4:00 hrs by using the + & - buttons on the handset as indicated + button - button 3.5.1.8 To adjust the snooze period use the + and - buttons to increase or decrease the snooze period for any period between 1 minute and 4:00 hours.
  • Page 44 3.5.2 Thermostatic mode PLEASE NOTE : Thermostatic mode of this fire will only allow regulation of the room temperature by the fire when it has been already lit via manual operation of the handset. It will not allow the fire to light automatically due to low ambient room temperature and should therefore not be relied upon for frost protection purposes.
  • Page 45 3.5.2.4 If at any time the power button is operated during thermostat mode the control will cancel any thermostat operation and return the control to manual mode. IMPORTANT NOTE : Thermostat mode will not light the fire 3.5.2.5 automatically and will only regulate between the maximum and minimum burner setting.

  • Page 46: Operation Of The Fire - Slide Control Models

    OPERATION OF THE FIRE - SLIDE CONTROL MODELS IMPORTANT : IF THE BURNER IS EXTINGUISHED FOR ANY REASON YOU MUST ENSURE THAT YOU WAIT A FULL FIVE MINUTES BEFORE ATTEMPTING TO RE-LIGHT THE FIRE. 3.6.1 Turn on the isolation valve. The slide control lever is located at the bottom right hand side of the fire.
  • Page 47 3.6.3 After lighting, move control lever left to the high flame position as shown on the previous page in figure 44 and the burner will fully light. It is recommended that for the most efficient performance the fire is allowed to warm up for a few minutes with the the control lever set to high.

  • Page 48: Checking For Clearance Of Combustion Products

    CHECKING FOR CLEARANCE OF COMBUSTION PRODUCTS 3.7.1 Close all doors and windows in the room. 3.7.2 Light the fire and allow to run for approximately 5 minutes on high position. 3.7.3 After approximately 5 minutes hold a smoke match just inside and below the centre of the lower front edge of the top of the fire, as shown below in figure 45.

  • Page 49: Removal / Re-Fitting The Restrictor Baffle

    REMOVING / RE-FITTING THE FLUE RESTRICTOR BAFFLE 3.8.1 The restrictor baffle is secured with 2 off screws to the internal roof of the combustion chamber. 3.8.2 Remove the glass panel as detailed in section 2.2 and unscrew or re-fit the baffle from the internal roof of the combustion chamber as shown below in figure 46.

  • Page 50: Requirements To Fit A Carbon Monoxide Alarm

    3.10 REQUIREMENTS TO INSTALL A CARBON MONOXIDE ALARM In England, Approved Document J provides statutory guidance on meeting the requirements of the Building Regulations 2010 (as amended), specifically in matters concerning combustion appliances and fuel storage systems. From 1st October 2022, where a new or replacement fixed gas burning appliance (excluding gas appliances used solely for cooking) is installed in a dwelling, a Carbon Monoxide (CO) alarm should be provided in the room where the appliance is located.

  • Page 51: Maintenance

    SECTION 4 MAINTENANCE Servicing Notes Servicing should be carried out annually by a competent person such as a GAS SAFE registered engineer. This is a condition of the guarantee schemes. The service should include visually checking the chimney and fire opening for accumulations of debris and a smoke test to check for a positive up-draught in the chimney.

  • Page 52: Removal Of The Control Valve - Slide Control Models

    Removing the Gas Control Valve - Slide Control Models 4.3.1 Remove the burner assembly as detailed in section 4.1, 4.3.2 Unscrew the thermocouple nut from the slide valve, remove the main pipe, inlet pipe, pilot pipe from the slide valve. Disconnect the ignition microswitch wires.

  • Page 53: Removal Of The Battery Igniter - Slide Control Models

    Removing the Oxy-Pilot - Slide Control Models (Continued) 4.5.3 Unscrew and remove the two pozi-drive screws which secure the pilot assembly to the burner. Remove the pilot. 4.5.4 Re-assemble in reverse order and carry out a gas tightness test. Removing the Battery Ignitor - Slide Control Models 4.6.1 Remove the burner assembly as described in section 4.1 4.6.2...

  • Page 54: Replacing The Battery In The Fire - Slide Control Models

    Replacing the Battery - Slide Control Models 4.9.1 Unscrew Battery retaining cap situated at the front right of the fire and remove the battery 4.9.2 Replace in the reverse order using a 1.5V AA Alkaline Battery. 4.10 Checking for Flue Debris. 4.10.1 Remove the burner assembly as detailed in section 4.1 4.10.2...

  • Page 55: Spare Parts Shortlist

    4.11 Spare Parts List - All Models B-1039950 Glass Panel (All Models) B-19660 ODS Pilot assembly (Slide Control Model) B-43040 Battery Generator (Slide Control Model) B-34690 Ignition Wire (Slide Control Model) B-1044105 Complete Log Set (All Models) B-1044105A Log A (All Models) B-1044105B Log B (All Models) B-1044105C...

  • Page 56: Section Five - User Instructions

    SECTION FIVE - USER INSTRUCTIONS 5.1 INSTALLATION INFORMATION CONDITIONS OF INSTALLATION It is the law that all gas appliances are installed only by a competent (e.g. Registered) Installer, in accordance with the installation instructions and the Gas Safety (Installation and Use) Regulations 1998. Failure to install appliances correctly could lead to prosecution.

  • Page 57: Important Safety Information

    ABOUT YOUR NEW CELENA MK3 GAS FIRE The Collection by Michael Miller “Celena MK3” log effect gas fire incorporates a unique and highly developed fuel bed which gives the realism of a loose log layout combined with realistic flames and glow. The use of durable ceramic material in the construction of the fuelbed components ensures long and trouble free operation.

  • Page 58: Operating The Fire - Remote Control Models

    OPERATING THE FIRE AND USER CONTROLS - REMOTE CONTROL MODELS 5.3.1 Ensure valve power isolation switch is in the “on” position on the valve Hold the handset with one hand ensuring your hand is wrapped around the back and that your hand is in contact with both sides of the handset. The green light of the “unlock”...
  • Page 59 Fig. 2 - “PILOT” displayed “PILOT” displayed on handset during ignition sequence (typically takes two seconds) Fig. 3 - “MAX” & large flame symbol displayed “MAX FLAME” displayed on handset when burner is lit to maximum rate...
  • Page 60 OPERATING THE FIRE AND USER CONTROLS (CONTINUED) 5.3.3 To decrease the heat input level of the burner hold the handset as described in section 5.3.1 to unlock the keypad then press and release the - button. Pressing and releasing the - button will lower the heat input level one step at a time.
  • Page 61 5.3.6 If you are not intending to use the fire for a long period (i.e. over the summer months) the battery life can be extended by disconnecting the battery pack from the valve, see section 2.2.1 5.3.7 In the event of loss of the remote handset, as a backup the fire can be turned off by pressing the on/off switch located below the grill at the base of the fire.

  • Page 62: Setting The Time, Date And Temperature On The Remote Handset

    SETTING THE TIME, DATE & TEMPERATURE ON THE REMOTE HANDSET 5.4.1 Fit the 2 off AA batteries to the handset by removing the cover on the rear of the handset and inserting the batteries, ensure the correct +/- polarity is observed. Following insertion of the batteries the screen displayed will be as shown below in figure 6.
  • Page 63 Fig. 7 24hr or 12 hr display, press the + or - buttons as shown to toggle between these two settings + button - button 5.4.4 When the 24hr or 12hr time display option has been chosen and you are ready to confirm the setting you want press the SET button on the handset to progress to setting the day of the week as shown overpage in figure 8.
  • Page 64 Fig. 8 Hour and Minute display, press the + or - buttons as shown to toggle between these two settings and set the correct time of day. + button - button 5.4.7 As shown above in figure 8 the time on the handset can now be set by using the + and - buttons to change the hour to the correct hour then press SET to store and to move to setting the minute.
  • Page 65 Fig. 9 Celsius or Fahrenheit temperature display, press the + or - buttons as shown to toggle between these two settings and set the correct time of day. + button - button 5.4.9 The control is now ready for use with the burner. 5.4.10 If the handset is misplaced you can “page it”...

  • Page 66: Advanced Settings Of The Remote Control

    ADVANCED SETTINGS MENU OF THE REMOTE CONTROL 5.5.1 Snooze mode in manual operation 5.5.1.1 Snooze mode is a time period which can be set which will turn the fire automatically off after a certain time period has elapsed. 5.5.1.2 Hold the handset with one hand ensuring your hand is wrapped around the back and that your hand is in contact with both sides of the handset.
  • Page 67 5.5.1.6 Pressing the set button again will now show you the snooze time period remaining. The snooze time period can be adjusted by pressing the + or - buttons on the handset. This time period can be set ranging from 1 minute to 4:00 hours.
  • Page 68 5.5.2 Thermostatic mode PLEASE NOTE : Thermostatic mode of this fire will only allow regulation of the room temperature by the fire when it has been already lit via manual operation of the handset. It will not allow the fire to light automatically due to low ambient room temperature and should therefore not be relied upon for frost protection purposes.
  • Page 69 5.5.2.4 If at any time the power button is operated during thermostat mode the control will cancel any thermostat operation and return the control to manual mode. 5.5.2.5 IMPORTANT NOTE : Thermostat mode will not light the fire automatically and will only regulate between the maximum and minimum burner setting.

  • Page 70: Operating The Fire - Slide Control Models

    OPERATING THE FIRE AND USER CONTROLS - SLIDE CONTROL MODELS IMPORTANT : IF THE BURNER IS EXTINGUISHED FOR ANY REASON YOU MUST ENSURE THAT YOU WAIT A FULL FIVE MINUTES BEFORE ATTEMPTING TO RE-LIGHT THE FIRE. 5.6.1 Turn on the isolation valve. The slide control lever is located at the bottom right hand side of the fire.

  • Page 71: Changing The Batteries - Remote Control Models

    CHANGING THE BATTERIES - REMOTE CONTROL MODELS 5.7.1 Changing the Batteries in the Handset 5.7.1.1 Remove and re-fit the new 2 off AA batteries by removing the cover on the back of the handset. 5.7.2 Changing the Batteries in the Fire 5.7.2.1 The battery pack is located as shown below in figure 15.

  • Page 72: Changing The Battery - Slide Control Models

    CHANGING THE BATTERY - SLIDE CONTROL MODELS 5.8.1 ENSURE THE FIRE IS COOL BEFORE ATTEMPTING TO CHANGE  THE BATTERY. Remove the lower grill by lifting clear. Locate the battery holder / ignition generator unit at as shown below in figure 16 5.8.2 Unscrew the retaining cap, remove and replace the 1 off AA battery, then replace the retaining cap.

  • Page 73: Cleaning Instruction

    CLEANING INSTRUCTIONS Before attempting any cleaning operation ensure that the fire has been allowed to fully cool. 5.9.1 Cleaning the metal painted parts / optional trim These metal painted parts should only be cleaned using a clean, damp cloth. Abrasive cleaners, chemical cleaning agents or any type of polish must never be used as damage to the finish may result.

  • Page 74: Removal / Re-Fitting The Glass Panel

    5.10 REMOVING / REPLACING THE GLASS PANEL 5.10.1 Remove the trim (if fitted) and front grill as below in figure 17 by lifting clear. Fig. 17 Front grill 5.10.2 Remove the two off screws which secure the glass panel retaining bracket as shown below in figure 18, then tilt the glass panel forward to remove it.

  • Page 75: Removal & Re-Fitting The Fuel-Bed Logset

    5.11 REMOVAL & RE-FITTING THE FUEL-BED LOGSET 5.11.1 Position Log “A” behind the burner as shown below in figure 19. Fig. 19 Log “A” 5.11.2 Position 2 off charred log pieces as shown below in figure 20. Fig. 20 Charred Pieces...
  • Page 76 5.11.3 Position Log “B” onto the left hand burner as shown below in figure 21, using the slot in the bottom of the log as a guide for placement. Fig. 21 Log “B” 5.11.4 Position Log “C” onto the right hand burner as shown below in figure 22, using the slot in the bottom of the log as a guide for placement.
  • Page 77 5.11.5 Position the grey chippings across the front fuel-bed support as shown below in figure 23. Fig. 23 Grey Chips 5.11.6 Position the Embaglow onto the burner base as shown below in figure Fig. 24 DO NOT POSITION ANY EMBAGLOW MATERIAL IN CLOSE PROXIMITY TO THE PILOT ASSEMBLY Embaglow...
  • Page 78 5.11.7 Position the two off small charred pieces as shown below in figure 25. Fig. 25 Small Charred Pieces 5.11.8 Position Log “D” at the left hand side of the fuel-bed, locating onto cut out on Log “B” to support it as shown below in figure 26. Fig.
  • Page 79 5.11.9 Position Log “E” at the right hand side of the fuel-bed, locating onto cut out on Log “C” to support it as shown below in figure 27. Fig. 27 Log “E” 5.11.10 Position Log “F” at the front of the fuel-bed, as shown below in figure Fig.

  • Page 80: User Replaceable Parts

    5.12 USER REPLACEABLE PARTS LIST B-1039950 Glass Panel (All Models) B-1044105 Complete Log Set (All Models) B-1044105A Log A (All Models) B-1044105B Log B (All Models) B-1044105C Log C (All Models) B-1044105D Log D (All Models) B-1008055E Log E (All Models) B-1044105F Log F (All Models) B-1044512...
