VicTsing RS8426D3 Operation Instruction

I. Main Functions:
1. Six function keys: SET, ALARM, LCD, UP/CH, DOWN/CF, SNOOZE.
2. 12/24 hour selectable.
3. Day of the week in 7 languages.
4. °C/°F selectable
5. Indoor temperature range: 0℃--+50℃
6. Outdoor temperature range: -20℃ --60℃
7. Outdoor temperature with RF: up to 3 channels
8. Double alarm function
9. Snooze function, ring again after 5 minute later
10. DST function
11. LCD brightness adjustment
II. Key Function:
Function SET
Operation
Click Switch display
Hold enter into
time setting
Click Confirm the
Setting
Hold enter into
time setting
Click Confirm the
Setting
Hold enter into
time setting
III. Instruction of Operating
3.1 Normal states
1. Click "SET" key to alarm mode.
2. Hold "SET" key to enter into setting mode
3. Press "UP/CH" key to switch RF channel, sequence: CH1CH2CH3.
4. Hold "UP/CH" key to clear out all data of current channel
5. Click "DOWN/CF" key to switch between °C/°F
6. Hold "LCD" key for 2 seconds to adjust LCD brightness setting, total 8 levels.
7. Click "ALM" key to switch the alarm on/off
8. When alarm is ringing, click "SNOOZE" key once to enter into snooze state, the alarm will ring again after 5 minutes
3.2 Time setting
1. Hold "SET" key for 2 seconds to enter into time setting
2. The setting item will flash 1 HZ
3. The sequence of time setting: 12/24HROFF/SETHourMinuteLanguageYearMonthDateExit
4. Press "SET" key to confirm the setting.
5. Press "UP/CH" key one time, the setting will go forward one step; hold the key for 2 seconds, it will run forward by 8
RS8426D3 Operation Instruction
Up DOWN/CF
Switch RF °C/°F
channel switchable
Clear RF data
one step one step
forward backward
8steps/second 8steps/second
forward backward
one step One step
forward Backward
8steps/second 8steps/second
forward backward
SNOOZE
Backlight on
----- -----
-----
-----
-----
-----
ALARM LCD
On/ off alarm -----
----- Enter into LCD
Brightness setting
----- -----
----- -----
----- -----
----- -----
