AP-W113Z
Outdoor Mobile Speaker
I.
Features
1. Ultra-large magnetic circuit high-sensitivity speaker with high penetrating power,low-frequency
shock and perfect medium-/high-frequency representation.
2. The latest decoding chips supporting stably playback of MP3 in up to 32GB USB/TF card.
3. FM radio reception - high-quality digital radio with automatic channel search and storage of up
to 30 channels.
4. 3. 5mm AUX audio input for each connection to a wide range of sound sources.
5. Built-in high-capacity battery for consecutive playback of up to 2 hours.
6. Connect the microphone, adjustable reverberation, voice and Karaoke function to present
outstanding performance.
7. Battery with built-in recharging protection to present a long and stable service life.
8. Built-in low battery and full recharging indication. Human-oriented use.
9. With belt/handle design for best choice of mobile speaker.
10. Microphone input recording to act as your personal business assistant.
11. With Bluetooth function.
II. Recording
Recording via External Microphone:
Connect a storage device (USB/TF card) and short press RECORD key to start recording for a time
depending on the storage capacity. During recording, tune the "-ECHO+" knob to the minimum. It
is noticeable that the microphone should be located a proper distance away from the speaker to
prevent any howl-round or noise.
Notes: This product starts recording from the time as displayed on the LED screen.
III. The bluetooth pairing operation and related parameters:
1.Power: switch the power to ON, press the key "MODE" to enter the mode of Bluetooth, the
display screen will show "BLUE".
2.Switch on the Bluetooth function of Mobile phone and searching , while the Mobile phone shows
"AP-W113Z", click the connect directly . mobile phone connection do not need password , if need
password , please input"0000" to go on pairing . After success pairing , the speaker will send out a
voice of prompt . it is success pairing between mobile phone and Bluetooth speaker.
3.Play the music of your mobile bphone directly and will give out beautiful voice from speaker.
User Manual
Advertisement
Related Manuals for Vocal-Star AP-W113Z
Summary of Contents for Vocal-Star AP-W113Z
- Page 1 2.Switch on the Bluetooth function of Mobile phone and searching , while the Mobile phone shows “AP-W113Z”, click the connect directly . mobile phone connection do not need password , if need password , please input”0000” to go on pairing . After success pairing , the speaker will send out a voice of prompt .
- Page 2 IV. Functional Operations and Features 1. LED Screen. 2. TF Port: Read audio files in MP3 format in TF card in capacity up to 32G (FAT32). 3. USB Port: Read audio files in MP3 format in USB storage device in capacity up to 32G (FAT32).
- Page 3 normal volume. /VOL+: In USB/TF card/Bluetooth reading status, short press it to go to the next song. In FM receiving status, short press it to select the next channel after a full station search has been executed. long press will increment the volume. 8.
- Page 4 following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement.
