Operating Instructions and Parts Manual
Please read and save these instructions. Read through this owner's manual carefully before using product. Protect
yourself and others by observing all safety information, warnings, and cautions. Failure to comply with instructions could
result in personal injury and/or damage to product or property. Please retain instructions for future reference.
Unpacking
After unpacking unit, inspect carefully for any
damage that may have occurred during transit.
Check for loose, missing, or damaged parts.
Shipping damage claim must be filed with
carrier.
Read These Instructions Before Assembly
Your spreader is designed to be operated at five miles per hour. Slower or faster speeds will change the spread
patterns. Wet spreading material will also change the spread pattern and flow rate. Clean your spreader thoroughly
after each use. Wash between the shut off plate and bottom of the hopper.
Ensure that the impeller is turning clockwise. Reversing the wiring leads will cause the impeller to turn counter
clockwise. Clean the impeller plate after each use. Spreading material stuck on the impeller blades will cause uneven
spreading.
Gears are permanently lubricated at the factory. Do not open or dirt may enter.
General Safety Information
Make sure you are appropriately dressed, including
sturdy footwear. Protect yourself by wearing gloves
and a dust mask when handling chemical lawn
products that contain pesticides and herbicides.
YTL838
Printed in China
05/11
125Lb. ATV Broadcast Spreader
Assembly
Before assembling this spreader, you need to have
the following tools:
1. A pair of pliers
2. Adjustable Wrenches
3. Phillips Screw Driver
10F639

Advertisement

loading
Need help?

Need help?

Do you have a question about the 10F639 and is the answer not in the manual?

Questions and answers

Summary of Contents for Westward 10F639

  • Page 1 Operating Instructions and Parts Manual 10F639 Please read and save these instructions. Read through this owner’s manual carefully before using product. Protect yourself and others by observing all safety information, warnings, and cautions. Failure to comply with instructions could result in personal injury and/or damage to product or property. Please retain instructions for future reference.
  • Page 2 Westward Operating Instructions and Parts Manual 10F639 125Lb. ATV Broadcast Spreader Parts in Carton...
  • Page 3 Westward Operating Instructions and Parts Manual 10F639 125Lb. ATV Broadcast Spreader STEP 1: Connect the hopper assembly and frame using 6 sets of M6x45 hex bolts, ø6 big washer and M6 nylon lock nuts. Do not tighten the nuts.
  • Page 4 Westward Operating Instructions and Parts Manual 10F639 125Lb. ATV Broadcast Spreader STEP 2: Attach the transom and deflector assembly Tighten all nuts in steps 1 and 2. to hopper using 2 sets of M6x50 hex bolts and M6 lock nuts.
  • Page 5: Wire Assembly

    Westward Operating Instructions and Parts Manual 10F639 125Lb. ATV Broadcast Spreader STEP 4: The motor switch needs to be in the OFF Turn the motor switch to the ON position and position before connecting to the battery. test to make sure the impeller rotates Connect the wire assembly to the motor clockwise.
  • Page 6: Using Your Spreader

    Westward Operating Instructions and Parts Manual 10F639 125Lb. ATV Broadcast Spreader Using Your Spreader 11. If spreading material accidentally deposited too heavily in a small area, soak the area thoroughly with a garden hose or READ ALL STEPS COMPLETELY BEFORE sprinkler to prevent burning of the lawn.
  • Page 7: Spreader Setting Instructions

    Westward Operating Instructions and Parts Manual 10F639 125Lb. ATV Broadcast Spreader Spreader Setting 3) Find the nearest intersecting point of these Instructions two numbers from Chart A. (this number equals the lbs. per 1000 sq. ft.) FOR MATERIALS THAT USE A TYPICAL 4) Use this number to find the nearest 5,000 Sq.
  • Page 8 Westward Operating Instructions and Parts Manual 10F639 125Lb. ATV Broadcast Spreader Chart B– Spreader Settings/Spread Widths • • • SMALL MEDIUM LARGE LBS/1,000 SPREADER PARTICLE PARTICLE PARTICLE SQ FT SETTING SPREAD SPREAD SPREAD 5-6 ft. 6-9 ft. 9-12 ft. 5-6 ft.
  • Page 9 24 hours a day – 365 days a year Please provide the following: - Model Number - Serial Number (if any) - Part description and number as shown on parts list Figure 1 – Repair Parts Illustration for Model 10F639...
  • Page 10 Westward Operating Instructions and Parts Manual 10F639 125Lb. ATV Broadcast Spreader Repair Parts List Reference Number Description Part Number Qty. Self-Plug Rivet Ø5X10 Hex Bolt M6x45 Big Washer Ø6 Hex Bolt M6x16 Hopper Shaft Housing Fixed Adjustable Plate TTYTL315177G Clamp Plate...
  • Page 11 Westward Operating Instructions and Parts Manual 10F639 125Lb. ATV Broadcast Spreader Flat Washer Ø5 U Bolt M8x50 TTYTL3151746G Pressure Plate Hex Nut M8 Rivet Ø5x13 Pan Head Screw M4x25 REPLACEMENT PARTS ARE NOT AVAILABLE FOR ITEMS THAT DO NOT HAVE A PART NUMBER LISTED THIS IS A STANDARD HARDWARE ITEM Manufactured for Grainger International, Inc.
  • Page 12 Instrucciones de Operación y Manual de Piezas 10F639 Por favor lea y guarde estas instrucciones. Lea este manual cuidadosamente antes de utilizar el producto. Protéjase a sí mismo y a los demás observando toda la información de seguridad, advertencias y precauciones. El incumplimiento de las instrucciones podría resultar en lesiones personales y / o daños al producto o a la propiedad.
  • Page 13 Instrucciones de Operación y Manual de Piezas de Westward 10F639 Esparcidor de Amplio Alcance de ATV de 125Lb. Piezas en Cartón...
  • Page 14 Instrucciones de Operación y Manual de Piezas de Westward 10F639 Esparcidor de Amplio Alcance de ATV de 125Lb. PASO 1: Conecte el conjunto de tolva y el bastidor con 6 juegos de tornillos hexagonales M6x45, arandela grande de ø6 y tuercas de...
  • Page 15 Instrucciones de Operación y Manual de Piezas de Westward 10F639 Esparcidor de Amplio Alcance de ATV de 125Lb. PASO 2: Fije el conjunto de travesaño y deflector a la 1. Apriete todas las tuercas de PASOS 1 y 2. tolva con 2 juegos de tornillos de cabeza hexagonal M6x50 y tuercas de bloqueo M6.
  • Page 16 Instrucciones de Operación y Manual de Piezas de Westward 10F639 Esparcidor de Amplio Alcance de ATV de 125Lb. PASO 4: El interruptor del motor tiene que estar en la Gire el interruptor del motor a la posición ON posición OFF antes de conectar a la batería.
  • Page 17 Instrucciones de Operación y Manual de Piezas de Westward 10F639 Esparcidor de Amplio Alcance de ATV de 125Lb. Usar Su Esparcidor 11. Si el material esparcido se deposita en exceso en un área pequeña por accidente, LEA TODOS LOS PASOS ANTES DE ARRANCAR deje en remoja el área a fondo con una...
  • Page 18 Instrucciones de Operación y Manual de Piezas de Westward 10F639 Esparcidor de Amplio Alcance de ATV de 125Lb. Instrucciones de 3) Busque el punto de intersección más configuración de cercano de estos dos números en el esparcidor Cuadro A. (este número es igual a la libra por cada 1000 pies cuadrados).
  • Page 19 Instrucciones de Operación y Manual de Piezas de Westward 10F639 Esparcidor de Amplio Alcance de ATV de 125Lb. Cuadro B– Configuraciones de Esparcidor/ Anchuras de Esparcimiento • • • LIBRAS/1.000 ESPARCIMIENTO ESPARCIMIENTO ESPARCIMIENTO PIES CONFIGURACIÓN DE PEQUEÑA DE PARTÍCULA DE GRANDE...
  • Page 20 Por favor proporcione los siguientes datos: - Número de Modelo - Número de Serie (si existe) - Descripción y número de piezas que aparecen en la lista de piezas Figura 1 – Ilustración de Piezas de Reparación para el Modelo 10F639...
  • Page 21 Instrucciones de Operación y Manual de Piezas de Westward 10F639 Esparcidor de Amplio Alcance de ATV de 125Lb. Lista de Piezas de Reparación Número de Referencia Descripción Número de Pieza Cantidad Remache Ø5X10 Perno Hexagonal M6x45 Arandela Grande Ø6 Perno Hexagonal M6x16...
  • Page 22 Instrucciones de Operación y Manual de Piezas de Westward 10F639 Esparcidor de Amplio Alcance de ATV de 125Lb. Arandela Plana Ø5 Perno U M8x50 TTYTL3151746G Placa de Prensa Tuerca Hexagonal M8 Remache Ø5X13 Tornillo de Cabeza Alomada M4x25 LAS PIEZAS DE REPUESTO NO ESTÁN DISPONIBLES PARA ÍTEMS QUE NO TIENEN UN NÚMERO EN LA LISTA ESTE ES UN ÍTEM DE FERRETERÍA ESTÁNDAR...
  • Page 23 Instructions d'Utilisation et Manuel de pièces 10F639 Veuillez lire et conserver ces instructions. Lire ce manuel attentivement avant d'utiliser ce produit. Veuillez vous protéger et protéger les autres en observant toutes les informations sur sécurité, les avertissements et mises en garde. Le non- respect des instructions peut entraîner des blessures et / ou endommager le produit ou des biens.
  • Page 24 Instructions d'Utilisation et Manuel de pièces Westward 10F639 Epandeur ATV capacité 125 livres Eléments dans le Carton...
  • Page 25 Instructions d'Utilisation et Manuel de pièces Westward 10F639 Epandeur ATV capacité 125 livres ETAPE 1 : Connecter l'assemblage de trémie et la charpente en utilisant 6 jeux des boulons à tête hexagonale M6x45, des rondelles grandes ø6 et des contre écrous en nylon...
  • Page 26 Instructions d'Utilisation et Manuel de pièces Westward 10F639 Epandeur ATV capacité 125 livres ETAPE 2 : Fixer le meneau et le déflecteur à Serrer tous les écrous dans les étapes 1 et 2. l'assemblage en utilisant 2 jeux des boulons à...
  • Page 27 Instructions d'Utilisation et Manuel de pièces Westward 10F639 Epandeur ATV capacité 125 livres ETAPE 4 : Le commutateur de moteur doit être en position ON, et le tester en vue de s'assurer position OFF avant de brancher à la batterie.
  • Page 28 Instructions d'Utilisation et Manuel de pièces Westward 10F639 Epandeur ATV capacité 125 livres Garder la plaque de pale à l'horizontale lors de l'utilisation de l'épandeur. L'inclinaison de Utilisation de votre l'épandeur se traduira par une couverture inégale. épandeur 10. Avant d'ouvrir la plaque de fermeture de commande de débit, veiller à...
  • Page 29 Instructions d'Utilisation et Manuel de pièces Westward 10F639 Epandeur ATV capacité 125 livres Instructions Réglage 3) Trouver le point entrecroisé le plus proche Epandeur de ces deux chiffres du Tableau A. (Ce nombre est égal à la quantité en livre pour POUR LES MATERIELS QUI UTILISENT UNE 1000 pieds carrés).
  • Page 30 Instructions d'Utilisation et Manuel de pièces Westward 10F639 Epandeur ATV capacité 125 livres Tableau B – Réglages Epandeur / Largeurs Epandage • • • EPANDAGE EPANDAGE EPANDAGE Livres/1 000 DE PETITES GROSSES PIEDS Réglages PARTICULE MOYENNES PARTICULE CARRES Epandeur PARTICULES...
  • Page 31 24 heures sur 24 – 7 jours sur 7 Veuillez fournir les renseignements suivants: - Numéro de modèle - Numéro de série (le cas échéant) - Description et numéro figurés dans la liste des pièces Figure 1 - Illustration Pièces de rechange pour le modèle 10F639...
  • Page 32 Instructions d'Utilisation et Manuel de pièces Westward 10F639 Epandeur ATV capacité 125 livres Listes des Pièces de rechange Référence Description Numéro de pièce Quantité Rivet Auto perceur Ø5X10 Boulon à tête hexagonale M6x45 Rondelle grande ø6 Boulon à tête hexagonale M6x16 Trémie...
  • Page 33 Instructions d'Utilisation et Manuel de pièces Westward 10F639 Epandeur ATV capacité 125 livres Rondelle plate Ø5 Boulon en U M8x50 TTYTL3151746G Plaque de Pression Ecrou hexagonal Rivet Ø5X13 Vis à tête cylindrique M4x25 LES PIECES DE RECHANGE NE SONT PAS DISPONIBLES POUR LES ARTICLES QUI NE DISPOSENT PAS de numéro de pièce indiqué.
