- Page 1 FLOW METERS INSTRUCTION MANUAL 1″, 2″ & 3″ FLOW METERS BANJO CORPORATION A Unit of IDEX Corporation 150 Banjo Drive, Crawfordsville, IN 47933 U.S.A. banjocorp.com | Telephone: (765) 362-7367...
- Page 2 Read these instructions and the instructions before operating the flow meter. The Banjo MFM flow meter series are full-bore, plastic-bodied electromagnetic flow meters designed for flow and usage monitoring applications in 1", 2" or 3" pipe. The polypropylene flow tube offers corrosion resistance to a wide range of chemicals.
- Page 3 Powder-coated die cast-aluminum Clamping flanges for ease electronics housing of installation Corrosion-resistant glass-filled polypropylene body Lightweight for easy handling 316 SS electrodes D IM E NS I ONS FM100 MFM100 " " 4 5/32 4 5/32 1" NPT 1" NPT "...
- Page 4 IN S T R UCT IONS: photoeye 1. When placing the flow meter in line, it is important to rotate the 2. There are 3 photoeyes located on the face of the flow meter. flow meter so that it is approximately at a 45-degree angle. (See Note: These are not buttons so you will not push them, instead, to figure 1) This will improve performance of the flow meter.
-
Page 5: Specifications
S P E C IF I CATI ONS Pipe Size 1" Full Port 2" Full Port 3" Full Port Fittings Flange Clamps/NPT Pipe Fittings Flange Clamps Flange Clamps 150 PSI (10.3 BAR) working pressure 150 PSI (10.3 BAR) working pressure 150 PSI (10.3 BAR) working pressure Pressure @ 70°F... -
Page 6: Installation Instructions
IN S TA L L ATION INSTRUCT I ON S: Position gasket at either end. Note: if hose is used, smooth bore is Place adapter against gasket, open screw clamps to clear flanges. recommended. Place screw clamps over both adapter and meter flanges and tighten screws. -
Page 7: Maintenance And Troubleshooting
Please see banjocorp.com for more information BANJO CORPORATION A Unit of IDEX Corporation 150 Banjo Drive Crawfordsville, IN 47933 U.S.A. Telephone: (765) 362-7367 Tech Sales: (888) 705-7020 Fax: (765) 362-0744 © Copyright 2021 Banjo Corporation. All Rights Reserved. banjocorp.com BJO_MAN_KK-101_1.5_2_3InchFlowMeterManual_Rev0921 #yellowhandle...
