LED FLOODLIGHT 20W
POWLI23229
1 DOMAIN OF USE
Outdoor or indoor usage such as jobsite, garden, studio and workshop.
WARNING! Read this manual and general safety instructions
carefully before using the appliance, for your own safety. Your
power tool should only be passed on together with these
instructions.
2 WARNING

This Product is Class I and must be Earthed.

Always switch off mains supply before fitting.

Replace any broken or damaged glass as soon as possible.

Ensure all seals are intact and operational after fitting or maintenance.

Do not touch the lamp in use or just after use as there is a risk of being burnt.

Do not cover it with paper or cloth.

Take off from flammable materials.

Do not wash the lamp.

Do not use the lamp where the ambient temperature is over 45°C and less than -
25°C.

Keep with a secure distance, the light could cause damage to your eyes.
3 ASSEMBLY

Find a suitable location to install this product.

Prepare the mains wiring.

Use the mounting bracket to mark the hole centres for fixing.

Drill holes suitable to accept wall plugs. Insert wall plugs.

Ensure mounting bracket.

Terminate wiring. (Fig. 1)

Replace all covers.

Fit the floodlight to the mounting bracket with the screws,

Check seals, gaskets and cable gland operation before testing the luminaire.

Turn on power supply and test luminaire.
4 TECHNICAL DATA
Type
Power
Voltage/frequency
Floodlight facade material
Waterproof protection grade
life-span
Lumen
Color temperature
Copyright © 2016 VARO
POWLI23229
POWLI23229
20W
220–240V ~ 50Hz
tempered glass
IP65
>30.000 hours
1300
3000K
